- Online only
Bosch Spare Parts for Chain Saw AKE 35-19 S
€1.79
Tax included
Bosch Spare Parts for Electric Chain Saw AKE 35-19 S
Bosch original spare parts for to replace broken parts for to fix Electric Chain Saw AKE 35-19 S - 3600H36E00.Fix Your Electric Chain Saw. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Electric Chain Saw AKE 35-19 S
Fix Your Electric Chain Saw AKE 35-19 S - 3600H36E00. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| Chain Saw AKE 35-19 S/3 600 H36 E00 | ||
| # | Part Num. | Description |
| 1 | 1605190228 | Motor Housing |
| 4 | 1607200193 | Switch |
| 5 | 1604460242 | Power supply cord EU 230V 0,55m 2 x 1,0mm H07 RN-F |
| 6 | 2609005766 | Grommet |
| 7 | 1602002008 | Lever |
| 9 | 1603231020 | Push-Button |
| 12 | 1607328028 | Suppression Filter |
| 21 | 1600390019 | Locking Bolt |
| 22 | 1604617008 | Compression Spring |
| 23 | 1604617015 | Compression Spring |
| 24 | 1605510315 | Protective Shield |
| 25 | 1601098008 | Spiked bumper |
| 27 | 1605133045 | Handle |
| 28 | 1600206038 | Intermediate Ring |
| 29 | 1600300096 | Bushing |
| 30 | 1602319019 | Pusher |
| 31 | 1604431003 | Connecting Cable |
| 32 | 1604431004 | Connecting Cable |
| 33 | 2916650001 | Spring retaining ring DIN 471-10x1MM-FSt |
| 35 | 1606100039 | Shaft |
| 36 | 1604650016 | Extension Spring |
| 37 | 1600205037 | Felt Washer |
| 38 | 2600917006 | Needle bearing |
| 43 | 1605405004 | Oil Reservoir |
| 44 | 1605437003 | Oil Pump |
| 46 | 1603023003 | Rod |
| 47 | 1600590014 | Swivelling Lever |
| 51 | 1604651013 | Clamp Spring |
| 52 | 2916080012 | Locking Washer DIN 6799-9-FSt |
| 53 | 1600328030 | Collar Disc |
| 54 | 1604652020 | Brake Band |
| 55 | 1600590019 | Lever Arm |
| 56 | 1600590016 | Spring Guide |
| 57 | 1600390018 | Lever Carrier |
| 60 | 1600590012 | Pressure Plate |
| 63 | 1604617017 | Compression Spring |
| 65 | 2914211528 | Oval-Head Screw 5x22 |
| 66 | 2914211528 | Oval-Head Screw 5x22 |
| 67 | 2914201506 | Oval-Head Screw 4x18 MM,TORX T20 |
| 68 | 2914201506 | Oval-Head Screw 4x18 MM,TORX T20 |
| 69 | 1600100038 | Friction Washer |
| 70 | 2910601325 | Tapping Screw 4,2x13 |
| 79 | 1601118K69 | Reference Plate |
| 80 | 1601118K62 | Manufacturer's nameplate AKE 35-19 S |
| 82 | 1601010009 | Seal Strip |
| 83 | 1601118A64 | Sticker |
| 653 | 1602317006 | Guide Rail 350 MM |
| 654 | 2609007364 | Saw Chain AKE 35 |
| 655 | 1601015035 | Adjusting Plate |
| 656 | 1603421003 | Countersunk-Head Screw |
| 802 | 1607000A62 | Alternating-Current Motor |
| 808 | 160111A3H3 | Nameplate |
| 810 | 1607014170 | Carbon-Brush Set |
| 818 | 2603410001 | Socket head cap screw M3x6,5-4.8 |
| 821 | 1607000A88 | Housing Section |
| 822 | 1607000884 | Housing Section |
| 823 | 1605133046 | Handle |
| 839 | 1607000A06 | Ring Gear |
| 840 | 1607000885 | Sprocket wheel |
| 842 | 1607431000 | Strainer |
| 843 | 1607000A47 | Reservoir Cap |
| 850 | 1605510329 | Chain Guard |
| 853 | 1605190190 | Dust-Protection Cover |
| 865 | 1607000A89 | Protective Cover |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch AKE 35-19 S 3600H36E00
11 Items
Data sheet
- SHIPPING IN:
- RESERVATION ONLY
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
