Bosch Spare Parts for Rotary Hammer PBH 220 RE
€2.24
Tax included
Bosch Spare Parts for Rotary Hammer PBH 220 RE
We are BOSCH original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer PBH 220 RE - 0603336703.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Rotary Hammer PBH 220 RE
We are BOSCH original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer PBH 220 RE - 0603336703.
In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| Rotary Hammer PBH 220 RE/0603336703 | ||
| # | Part Num. | Description |
| 2 | 1614220115 | Field 230-240V |
| 3/60 | 1616610072 | Fan BLACK |
| 4 | 2607200209 | Switch |
| 6 | 2600703018 | Grommet Ø7,3-Ø8,6x76 MM |
| 7 | 1611035005 | Cable Clip |
| 9 | 1611110939 | Manufacturer's nameplate |
| 10 | 1611110940 | Reference Plate |
| 12 | 1617328026 | Suppression Filter |
| 13 | 1610905032 | Deep-Groove Ball Bearing 7x19x6 |
| 14 | 1610905048 | Deep-Groove Ball Bearing 9x24x7 |
| 16 | 1617000343 | Brush Holder |
| 18 | 1610522009 | Air-Deflector Ring |
| 22 | 1616317602 | Cylindrical Gear Z=50 |
| 24 | 1617000518 | Toothed Shaft Z=3/9 |
| 26 | 1618700062 | Hammer Piston |
| 27 | 1618710057 | Striker |
| 28 | 1613124040 | Striker Pin |
| 29 | 1613105012 | Piston Pin |
| 31 | 1615510003 | Protective Grille |
| 34 | 1610508008 | Protective Cap L=17 MM, SDS-PLUS |
| 35 | 1610206021 | Rubber Ring |
| 37 | 1610390017 | Damping Bushing |
| 38 | 1610102026 | Supporting Disc |
| 41 | 1610101011 | Shim washer 1,2 MM THICK |
| 42 | 1610202015 | Plain bearing |
| 43 | 1611098005 | Tab Washer |
| 44 | 1615820092 | Switching Element |
| 45 | 1614651014 | Switch Spring |
| 46 | 1614690002 | Driver Pin |
| 48 | 1611016003 | Holding Plate |
| 49 | 1612026035 | Switch Button RED |
| 60 | 1610910073 | Needle-Roller Bearing |
| 61 | 1610910098 | Needle bearing |
| 62 | 1610910074 | Needle bearing |
| 63 | 1610910064 | Needle bearing |
| 64 | 1610913010 | Needle-Roller Assembly |
| 65 | 1610591016 | Plain bearing |
| 67 | 1610905016 | Deep-Groove Ball Bearing |
| 70 | 1610283019 | Shaft Seal |
| 71 | 1610290029 | Scraper |
| 72 | 1610210068 | O-Ring 24,0x2,5 MM |
| 73 | 1610210187 | O-Ring |
| 74 | 1610210104 | O-Ring 11,0x3,5 MM |
| 75 | 1610210105 | O-Ring 18,0x3,5 MM |
| 76 | 1610210046 | O-Ring 10,5x2,7 MM |
| 77 | 1610210106 | O-Ring 60,0x3,0 MM |
| 80 | 1614634005 | Compression Spring |
| 81 | 1614611009 | Compression Spring |
| 83 | 1614611006 | Compression Spring |
| 85 | 1614601011 | Retaining ring |
| 86 | 1614601012 | Retaining ring |
| 87 | 2916540012 | Retaining ring DIN 7993-A22 |
| 88 | 1613200007 | Roller |
| 89 | 1903230013 | Ball DIN 5401-Ø7MM-III-ST |
| 90 | 1603435036 | Tapping Screw 4,8x78 MM, TORX T-20 |
| 91 | 2603490026 | Lens Head Screw 4x32 |
| 92 | 2603490023 | Torx Oval-Head Screw 4x20 |
| 93 | 2910211005 | Tapping Screw DIN 7971-ST2,9x9,5-F |
| 95 | 2603410001 | Socket head cap screw M3x6,5-4.8 |
| 96 | 2912401018 | Tapping Screw DIN7981-ST3,9x13-C-Z |
| 97 | 2603490021 | Torx Oval-Head Screw 4x12 |
| 100 | 2604465086 | Suppression Filter L=148 MM BLACK |
| 101 | 2604465097 | Suppression Filter L=126 MM WHITE |
| 102 | 2604448005 | Cable L=130 MM WHITE |
| 103 | 1614448017 | Connecting Cable L=55 MM WHITE |
| 104 | 2604448137 | Connecting Cable L=78 MM WHITE |
| 105 | 2604448170 | Earth Conductor |
| 110 | 1615132067 | Strap-Shaped Handle |
| 111 | 1618040070 | Bracket Holder |
| 112 | 1601118B75 | Reference Plate |
| 120/2 | 1612025019 | Auxiliary Handle M8 |
| 120/20 | 2915011007 | Hex Nut DIN 934-M6-8-A |
| 120/30 | 1613480007 | Wing Screw M6x(15)55 |
| 120/50 | 2608040014 | Clamping Plate M6 |
| 120/60 | 1613480008 | Wing Screw M6x20 MM |
| 121 | 1618040048 | index turning toolholder Ø43 MM |
| 122 | 1613490002 | T-Head Bolt M8x40 MM |
| 123 | 1611316006 | Clamping Band Ø43 MM |
| 651 | 2609005615 | Depth-Gauge |
| 656 | 2607000982 | Sales-Campaign Set |
| 656/1 | 1613523011 | Drill Chuck Shank 1/2", SDS-Plus |
| 656/3 | 1608571062 | Key Chuck R/L Ø13 MM, 1/2"-20 UNF |
| 656/4 | 2603421207 | Countersunk-Head Screw M6x27-KØ11 LEFTHAND THREADS |
| 656/8 | 2607950007 | Chuck Wrench SG2 |
| 754 | 2607000122 | Drill Holder |
| 2607018117 | Drill Holder | |
| 755 | 1618580000 | Angle Drill Head SDS-PLUS |
| 801 | 1617000498 | Motor Housing GREEN |
| 803 | 1614010703 | Armature With Fan 230-240V |
| 805 | 1614460026 | Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F |
| 808 | 1601106035 | Nameplate 26x42 MM |
| 816/04 | 1617014134 | Carbon-Brush Set |
| 819 | 1615806131 | Gear Housing GREEN |
| 820 | 1617000981 | Intermediate Flange |
| 821 | 1616490061 | Ratchet Sleeve SDS-PLUS |
| 821/01 | 1616490060 | Ratchet Sleeve SDS-PLUS |
| 822 | 2602025094 | Auxiliary Handle |
| 823 | 1616328042 | Gear Sleeve Z=26/6 |
| 824 | 1613060021 | Toothed Shaft Z=9 |
| 826 | 1617000517 | Toothed Shaft Z=3/9 |
| 830 | 1615819018 | Drive end shield |
| 832 | 1612026037 | Clamp Handle BLACK |
| 833 | 1617000163 | Protection Sleeve SDS-PLUS |
| 847 | 1617000348 | Guide Ring |
| 886 | 1614601024 | Retaining ring |
| 894 | 2603435015 | Recessed-Head Screw DIN 7981-ST3,5x9,5-F |
| 899 | 2607200231 | Change-Over Switch |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
