Bosch original spare parts for to replace broken parts for to fix UniversalChain35 1.8W Mains fed Corded 350mm Chainsaw 3600HB8100.
In the following table, look for the model of the Electric Chain Saw and the respective parts of the code.![]()
| Bosch UniversalChain35 1.8W Mains fed Corded 350mm Chainsaw Spare Parts | ||
|
#
|
Part Num.
|
Description |
|
1
|
160580669U
|
Housing |
|
2
|
16051082HW
|
Motor Housing |
|
4
|
160720035H
|
Switch |
|
5
|
2604460183
|
Power supply cord EU 0,4M 2 X 1,0MM H07 RN-F |
|
6
|
2609005766
|
Grommet |
|
7
|
2609004394
|
Suppression Filter |
|
13
|
2609001047
|
Spring |
|
14
|
2609006397
|
Torsion Spring |
|
15
|
1600A015GN
|
Lever |
|
33
|
2609001048
|
Compression Spring |
|
34
|
1600A015D0
|
Safety Switch |
|
35
|
160461202U
|
Compression Spring |
|
36
|
1600A015D1
|
Mounting Plate |
|
37
|
1600A015D2
|
Sprocket wheel |
|
38
|
2916650001
|
Spring retaining ring DIN 471-10X1MM-FST |
|
39
|
2609001086
|
Pipe |
|
40
|
2603490023 | Torx Oval-Head Screw 4X20 |
|
42
|
1600A015DE
|
Pipe |
|
43
|
1600A015DS
|
Switch Segment |
|
46
|
1600A015DJ
|
Sealing |
|
53
|
160513217Y
|
Handle |
|
54
|
1600A015CX
|
Protective Shield |
|
55
|
1600A01N9H
|
Oval-Head Screw |
|
56
|
2609110080
|
Torx Oval-Head Screw |
|
680
|
1600A028X6
|
Adjustment Knob |
|
683
|
1600A027C7
|
RSV Cap |
|
687
|
1600A01B1L
|
Chain Guard |
|
689
|
2609007364
|
Saw Chain AKE 35 |
|
690
|
1600A015H6
|
Guide Rail 350 MM |
|
803
|
1607000DW1
|
Motor |
|
808
|
160111A69M
|
Nameplate |
|
811
|
1607000DW5
|
Pump |
|
816
|
1607000DW4
|
Container |
|
818
|
1607000DW2
|
Drive Clutch |
|
829
|
1607000DW3
|
Linkage |
|
881
|
1607000EG1
|
Adjustment Device |
