Black&Decker BEHS03K Type 1 SDS Hammer Drill Parts
€3.08
Tax included
Black&Decker BEHS03K Type 1 SDS Hammer Drill Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Black&Decker BEHS03K-QS TYPE 1 SDS HAMMER DRILL Spare Parts.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Black&Decker BEHS03K Type 1 SDS Hammer Drill Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Black&Decker BEHS03K-QS TYPE 1 SDS HAMMER DRILL Spare Parts.
In the following table, look for the model of the hammer and the respective parts of the code.
| BEHS03K-QS Corded SDS Hammer Drill 1250W 3.7J Type 1 Spare Parts | ||
| # | Part Num. | Description |
| 1 | 1004774-16 | BOOT |
| 2 | 5140144-59 | CIRCLIP |
| 3 | 1004774-17 | COLLAR |
| 4 | 1004774-18 | SPRING |
| 5 | 1004774-19 | SPINDLE SA |
| 7 | 1004775-46 | O-RING |
| 8 | 1004775-47 | O-RING |
| 9 | 1004775-48 | O-RING |
| 12 | 1004775-49 | O-RING |
| 15 | 1004774-21 | SCREW |
| 16 | 1004774-22 | O-RING |
| 18 | 1004774-23 | WASHER |
| 19 | 1004774-24 | RING |
| 20 | 1004774-25 | BEARING |
| 21 | 1004774-26 | RING |
| 22 | 1004774-27 | BUSH |
| 23 | 1004774-28 | RING |
| 24 | 1004774-29 | TOOL HOLDER |
| 25 | 1004774-30 | SPRING |
| 26 | 1004774-31 | CLUTCH |
| 27 | 1004774-32 | CYLINDER |
| 28 | 1004774-33 | PIN |
| 29 | 1004774-34 | GEAR |
| 30 | 1004774-35 | WASHER |
| 31 | 1004774-36 | RING |
| 32 | 1004774-37 | CIRCLIP |
| 33 | 1004774-38 | BUSH |
| 34 | 1004774-39 | BAFFLE |
| 35 | 5140147-41 | PIN |
| 36 | 1004774-40 | PISTON |
| 39 | 1004774-42 | GEAR BOX |
| 40 | 1004774-43 | COVER |
| 41 | 1004774-44 | SEAL |
| 42 | 5140144-93 | O-RING |
| 43 | 1004774-45 | CRANKSHAFT |
| 44 | 1004774-46 | DAMPER |
| 45 | 1004774-47 | RING |
| 46 | 1004774-48 | WASHER |
| 47 | 1004774-49 | O-Ring |
| 48 | 1004774-50 | WASHER |
| 49 | 1004774-51 | SCREW |
| 50 | 1004774-52 | BEARING |
| 51 | 5140144-99 | CIRCLIP |
| 52 | 5140145-00 | CIRCLIP |
| 53 | 1004774-53 | SPRING |
| 54 | 1004774-54 | CLUTCH |
| 55 | 1004774-55 | GEAR |
| 56 | 1004774-56 | WASHER |
| 57 | 1004774-57 | RING |
| 58 | 1004774-58 | WASHER |
| 59 | 1004774-59 | BEARING |
| 67 | 1004774-61 | BEARING |
| 68 | 1004774-62 | GUIDE |
| 69 | 1004774-63 | STOP PLATE |
| 70 | 1004774-64 | SELECTOR FORK |
| 71 | 1004774-65 | SPRING |
| 72 | 1004774-66 | SELECTOR FORK |
| 73 | 1004774-67 | SEAL |
| 74 | 1004774-68 | COVER |
| 75 | 1004775-11 | BEARING |
| 77 | 5140145-15 | BEARING |
| 78 | 1004774-70 | FAN COVER |
| 79 | 1004774-71 | FIELD |
| 80 | 5140145-16 | SCREW |
| 81 | 1004774-72 | FIELD CASE |
| 82 | 1004774-73 | SCREW |
| 83 | 5140145-20 | BRUSH HOLDER |
| 84 | 5140145-23 | SPRING |
| 86 | 5140145-22 | SCREW |
| 87 | 1004774-75 | COVER |
| 88 | 1004774-76 | SCREW |
| 89 | 1004774-77 | DAMPER |
| 91 | 1004774-80 | POTENTIOMETER SA |
| 92 | 1004774-81 | TRIGGER |
| 93 | 1004774-82 | SWITCH |
| 94 | 1004774-83 | CAPACITOR |
| 96 | 1004774-84 | CORDCLAMP |
| 97 | 1004774-85 | CORD PROTECTOR |
| 98 | 1004774-87 | CORDSET |
| 101 | 1004774-90 | CIRCLIP |
| 103 | 1004774-91 | SPRING |
| 104 | 1004774-92 | BUTTON |
| 105 | 1004775-44 | WASHER |
| 501 | 1004775-04 | CLAMP |
| 502 | 1004775-05 | BOLT |
| 503 | 1004775-06 | LOCKING SCREW |
| 504 | 1004775-07 | BRACKET |
| 505 | 1004775-08 | NUT M6 |
| 506 | 1004775-09 | SIDE HANDLE |
| 507 | 1004775-10 | DEPTH ROD |
| 508 | 1004692-32 | CHUCK KEY |
| 509 | 1004692-33 | SPINDLE |
| 510 | 1004692-34 | ADAPTOR |
| 511 | 1004775-01 | KIT BOX |
| 512 | 1004775-02 | GREASE |
| 513 | 1004775-03 | GREASE |
| 801 | 1004774-19 | SPINDLE SA |
| 802 | 1004774-20 | HEAD SA |
| 803 | 1004774-41 | CON ROD SA |
| 804 | 1004774-60 | GEAR SA |
| 805 | 1004774-69 | ARMATURE SA |
| 806 | 1004774-74 | BRUSH PAIR SA (X 2) |
| 807 | 1004774-88 | LEVER SA |
| 808 | 1004774-94 | KNOB SA |
| 809 | 1004774-95 | HANDLE SA |
| 810 | 1004774-97 | CHUCK SA |
| 811 | 1004774-78 | SWITCH HANDLE |
