Compa-OMS Spare Parts for Portable Saws 305-3051 MAX 100
€3.48
Tax included
Compa-OMS Spare Parts for Portable Saws 305-3051 MAX 100
Fix Your Professional Mitre Saws 305 MAX 100 - 3051 MAX 100. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Compa-OMS Spare Parts for Portable Saws 305-3051 MAX 100
Fix Your Professional Mitre Saws 305 MAX 100 - 3051 MAX 100. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Professional Saws and their spare part.
| Professional Saws 305 MAX 100 3051 MAX 100 | |
| Part Num. | Description |
| 0118 | Washer Brass d.24x10,5x2 |
| 0188 | Knob TBP d.20 M6x15 iron |
| 0207 | Bearing 6201 2Z (CTK) (HCH) mm.12x32x10 |
| 0207QUALITY | Bearing 6201 ZZ (ERI) mm.12x32x10 |
| 0208QUALITY | Bearing 6203 ZZ mm.17x40x12 |
| 0214 | rubber grommet |
| 0215PULSANTE | Button 82L5 2 MORS.VERDE + PR. |
| 0216MONO | Cable VVF 3x1 + mt.2 sp.SHUKO FR. |
| 0222 | thrust 51100 |
| 0228 | Allen stops saw HEX SOCKET HEAD M10x25 SX Zn |
| 0283 | brake pad |
| 0284 | Spring 'CO.MEC 720 P.32'x brake |
| 0292/2300 | 25mF capacitor. V.400 2 cav.mm.250 |
| 0321/01 | Millimetric rule, riveting |
| 0330 | Removable lower protective plastic |
| 0335 | Return spring for superior protection and release levers |
| 0339 | Knob NPT d.32 M8x30 01TNO32D30 |
| 0345 | Lower guard upstairs NEW |
| 0348 | Knob d.20 M5 (01TBB20B) |
| 0355 | Push stick |
| 0357 | Dipstick raising shelf |
| 0360/01 LAV | Shelf extruded aluminum assembled |
| 0365GREZZO | Extruded upper bracket PR.14590 |
| 0366 | Foil blocking |
| 0386LAVORATO | Extruded support sq.tagl. and worked |
| 0395LAV | Upper Guide worked |
| 0805 | Bag suction C216 / G d.60 int. + hinge |
| 0806 | Clamp HOP9 d.40-70 |
| 0851 | Support for lots aspiration |
| 0911LAVORATO | Motor cover 250 WORKED |
| 0912 | Motor fan cover small polycarb. 250/300/2300 |
| 0913 | Fan motor small 250/300/2300 |
| 13030600 | Bearing (d.8x22x7) 608-2RS1 |
| 20010160 | Wing nut d.30 TNP32 M6x100 |
| 23010240 | X spring pin locking arm |
| 23010390 | Leaf spring X 2300/1 |
| 23010400 | Bush to get up lever cover 2300 |
| 23020012 LAV | Arm worked vers. "MAXIMA" |
| 23020020 | Arm Cover x 2300 |
| 23020040 | Spacer sleeve 2300/3000/3500 |
| 23020050 | Handle line x 2300 |
| 23020060 | Trigger Grip line x 2300 |
| 23020070 | Strain relief impugn.tipo x 2300 |
| 23020100 | Pin x wheel guard |
| 23020180 | tie M5x180 Zn |
| 23020210 | Biellino release NOT SELL AS |
| 23020232 | Short lever release 2300 |
| 23020250 | Arm spring Rod Tube |
| 23020300 | Cover version x 2301 |
| 23020320 | Screw fulcrum lever release TC M6 d.12x16,5 |
| 23020350 | Buffer standoff |
| 23020440 | Switch SCHURTER ABCWF00-U3-AZM02 X2300 / 250 |
| 23020490 | Long lever release |
| 23020610 | Plast protection. motor 90x120 |
| 23020620 | Rosetta spingimolla |
| 23020630 | Pin adjustment spring |
| 23020640 | Spring holder rod |
| 23020660 | Spring spacer arm stand up 2300 |
| 23020691 | Plate reinforces spring 2300 NEW |
| 23020695 | Spacer reinforcement spring 2300 |
| 23020720 | Spacer bushing shelter spring |
| 23020801 LAV | Carter motor mount 2300 MAX.LAVORATO |
| 23020843 | Drive pulley x MAXIMA (new vers.) |
| 23020854 | Driven pulley x MAXIMA (new vers.) |
| 23020861 | Driven shaft MAXIMA |
| 23020870 | Washer stops pulley MAXIMA |
| 23020880 | Locking washer saw WORKED |
| 23020890 | Washer stops saw |
| 23020900 LAV | Sliding Blade Guard |
| 23020901 | Extension spring nr.9 |
| 23020910 | Ring for internal protection |
| 23020920 | conveyor maxima |
| 23020930 | Get up lever guard maxima |
| 23020941 LAV | Support arm WORKED 305 MAX 100 |
| 23020960 | Ring compensator AN32x10 MAXIMA |
| 23021030 | spacer |
| 23021071 | Plate interposed maxima |
| 23021081 | Belt line MAXIMA - HP255 5MHP15 |
| 23030030 | Saw guard upstairs (spare: 23,030,030 COM |
| 23030040 | Rear rod x superior protection (ric.23030030 C |
| 23030050 | riving knife |
| 23030260 | gearbox |
| 23030270 | Lid box |
| 23030280 | rack |
| 23030290 | cogwheel |
| 23030311 | Adjusting knob 01THP50 with pin |
| 23030330 | Column guide plan |
| 800043-00LAV | Basement worked X PARTS: KIT001006! |
| 800044-00LAV | Turntable worked |
| 800052-00LAV | Hose handle worked |
| 800053-00LAV | Arm selector degrees worked |
| 800055-00LAV | Sector grooved worked |
| 800057-01 | Plastic catch |
| 800057-02 | rod d.10x300 |
| 800058-00 | binoculars |
| 800078-00 | lever |
| 800086-00 | Cap for tube |
| 800099-00 | Spring compression DM8.7 DF1.8 H38.5 |
| 800127-00 | fork M6 |
| 800213-01 | selector |
| 800214-00 | tie M6 |
| 800245-00 | nameplate index |
| 800257-00 | graduated plate |
| 800289-02 | thrust 51114 |
| 800293-02 | Thrust AXF 3552 |
| 800507-00 | rod d.12x400 |
| 800668-00LAV | Right bracket machined |
| 800669-00LAV | Bracket Left worked |
| 800686-00 | Locking pawl |
| 800963-00 | OBSOLETE! Knob M6x15 SOST.DA COD.0188 |
| 801333-00 | support base |
| KIT001003 | Group stand TC14 |
| KIT002001 | Group selection handle degrees |
| KIT23020810 | Crankshaft + rotor x mod.MAXIMA |
| KITLEVE2300 | Linkage mounted x release 2300/3000/1 |
| KITMOT2300MON | Motor 2300 mono (Paccco St. + Lawyer. + Car |
