Black&Decker CP5050 GM145 Spare Parts
Genuine Parts Black & Decker for piston Air Compressors and spare parts for to repair or replacement components for Air Compressor Black&Decker CP5050 GM145 1168517000 Spare Parts.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Black&Decker CP5050 GM145 Spare Parts
Genuine Parts Black & Decker for piston Air Compressors and spare parts for to repair or replacement components for Air Compressor Black&Decker CP5050 GM145 1168517000 Spare Parts.
In the following table, look for the type of the air compressor and the respective parts of the code .
| Black&Decker CP5050 GM145 1168517000 Spare Parts Pag.1 | ||
| # | Part Num. | Description |
| 1 | 4056400000 | Pressure switch kit |
| 1,01 | 7081090000 | Joint |
| 1,02 | 7088060000 | Joint |
| 1,03 | 7192430000 | Pre-set safety valve M1/4"-8.5 BAR |
| 1,04 | 7100640000 | Pressure reducer |
| 1,05 | 7110240000 | Pressure gauge |
| 1,06 | 7110300000 | Pressure Gauge Ø50-1/4" |
| 1,07 | 7130570000 | Universal Tap |
| 1,08 | 7250740000 | Pressure switch |
| 1,09 | 7326450000 | Infeed cable |
| 1,1 | 7023050000 | Locking nut |
| 2 | 4083130000 | Wheel Kit |
| 2,1 | x | Wheel pin |
| 2,2 | x | Nut |
| 2,3 | x | Wheel |
| 3 | x | Screw |
| 4 | 7090030000 | Plug |
| 5 | 7130160000 | Discarger tap |
| 6 | 7152330000 | Plastic Shroud |
| 7 | 7181060000 | Oil dipstick |
| 8 | 7190180000 | Check valve |
| 9 | 7230010000 | Rilsan tube Ø6X4 |
| 10 | 7231700000 | Infeed hose |
| 11 | 7360020000 | Rubber plug |
| 12 | 5153370008 | Tank |
| 13 | 9100930130 | Handle |
| 14 | 9109840000 | Pump unit |
| 9107370000 GM145 pump Unit Parts Pag.2 | ||
| SINGLE PHASE V.230/50Hz MONOFASE V.230/50Hz | ||
| # | Part Num. | Description |
| 1 | 7011220000 | Screw M6x40 |
| 1A | 9700010186 | Washer D6 |
| 2 | 7084040000 | Joint |
| 3 | 7458340000 | Plate |
| 4 | 7210010000 | Filtering element |
| 5 | 7210430000 | Intake filter Cover |
| 6 | 7012100000 | Screw ST4.2x19 |
| 7 | 7196010000 | START valve 1.5bar |
| 8 | 9101410070 | Head |
| 9 | 9101410080 | Gasket |
| 10 | 9100010240 | Valve plate |
| 11 | 9100010080 | Gasket 0.2mm |
| 12 | 9100010370 | Valve |
| 13 | 9101410090 | Gasket 0.5mm |
| 14 | 9101410060 | Cylinder Ф42 |
| 15 | 7020070000 | Nut M8 |
| 16 | 9100590060 | Gasket 1.5mm |
| 17 | 4080010000 | Piston ring Kit Ф42 |
| 18 | 9100580050 | Piston Ф42 |
| 19 | 9100580090 | Piston pin Ф12x34 |
| 20 | 7041010000 | Internal snapring D12 |
| 21 | 5050150008 | Con rod |
| 22 | 7640060000 | Rear Cover |
| 23 | 7060200000 | Bearing 6204 |
| 25 | 9101410050 | Counter weight |
| 26 | 9100030090 | Plastic shroud |
| 27 | 9700010061 | Oil dipstick |
| 28 | 9101410020 | Carter cover |
| 29 | 7012160000 | Screw M6x12 |
| 30 | 9700010187 | Screw M5x14 |
| 31 | 9700000016 | O-ring |
| 32 | 9100270150 | Oil seal d20xD47x7 |
| 33 | 9700001865 | Crankcase |
| 34 | 9700002512 | Rotor |
| 35 | 9700002515 | Stator 230V/50Hz |
| 36 | 7060010000 | Bearing 6203-2RS/2RZ |
| 37 | 7310320000 | Capacitor |
| 38 | 9700010188 | Nut M8 |
| 38A | 9700010184 | Washer D8 |
| 40 | 9700001900 | Tension rod M6x110 |
| 41 | 9100010200 | Fan |
| 42 | 9700002031 | Screw ST4.2x9.5 |
| 42A | 9700010183 | Washer D4 |
| 43 | 9100010050 | Stud bolt M8x36 |
| 100 | 4094470000 | Filter kit |
| 101 | 7459480000 | Valve plate kit |
| 102 | 4082390000 | Seal kit |
| 103 | 4190330000 | Conrod-Piston kit |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
CP5050 GM145 1168517000
5 Items
