Annovi Reverberi Parts for Pressure Washer AR555 - 12356
We are Annovi Reverberi original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer Blue Clean AR555 - 12356.
In the following tables, look for the spare part and its respective code.
| Annovi Reverberi Pressure Washer Blue Clean AR 555 - 12356 | ||
| AR 555 - 12356 - CASING Pag.1 |
||
| # | Part Num. | Description |
| 1 | 2180425 | Blue casing |
| 2 | 1460340 | Conveyor |
| 4 | 390440 | Nut |
| 5 | 1263020 | Clamp |
| 6 | 2320250 | Plate |
| 7 | 2180040 | Handle |
| 8 | 2180060 | Knob |
| 9 | 2180090 | Grille |
| 10 | 1261560 | Screw |
| 11 | 2180300 | Washer |
| 12 | 1343510 | Screw |
| 13 | 2180050 | Accessories carrier |
| 14 | 2320310 | Screw |
| 16 | 2180080 | Axle |
| 17 | 2180142 | Wheel |
| 18 | 1680880 | Washer |
| 19 | 1680890 | Washer |
| 20 | 2180360 | Base |
| 21 | 1270960 | Detergent hose |
| 22 | 40008 | Tank |
| 23 | 2320260 | Fitting |
| 27 | 2180330 | Rubber foot |
| 28 | 2000110 | Screw |
| 30 | 2180740 | Ring nut |
| 31 | 2000240 | O-ring |
| 32 | 1682420 | Plug |
| 33 | 2189004 | Base assembly |
| 555 - 12356 - PUMP Pag.2 |
||
| 1 | 2101000 | Screw |
| 2 | 2100610 | Fitting |
| 3 | 550350 | O-ring |
| 4 | 2123 | O-ring + head |
| 5 | 850850 | Screw |
| 6 | 2020481 | Seat |
| 7 | 394280 | O-ring |
| 8 | 2109051 | Valve |
| 9 | 880840 | O-ring |
| 10 | 2200140 | Water seal |
| 11 | 2320080 | Ring |
| 12 | 770590 | O-ring |
| 13 | 2320070 | Bushing |
| 14 | 1683500 | Oil seal |
| 15 | 2020120 | Piston guide |
| 16 | 2200210 | Screw |
| 17 | 2020150 | Spring |
| 18 | 2020130 | Piston |
| 19 | 2020140 | Ring |
| 20 | 1680680 | O-ring |
| 21 | 1260760 | Screw |
| 22 | 2021570 | Bearing |
| 23 | 2180720 | Elbow |
| 24 | 1140690 | Clamp |
| 25 | 2180730 | Supply pipe |
| 27 | 550460 | Elbow |
| 28 | 550450 | Ring nut |
| 29 | 2000520 | O-ring |
| 30 | 2329409 | Pump assembly |
| 31 | 1470830 | Fitting |
| A | 2577 | Valve kit |
| B | 2734 | Piston kit |
| D | 2791 | Seal kit |
| 555 - 12356 - DELIVERY FITTING Pag.3 |
||
| 1 | 1981770 | Plug |
| 2 | 1981780 | Knob |
| 3 | 1060120 | Nut |
| 4 | 392840 | Screw |
| 5 | 1980390 | Insert |
| 6 | 1080070 | Pin |
| 7 | 1343000 | Wobble plate |
| 8 | 1460190 | Spring |
| 9 | 1343450 | Wobble plate |
| 10 | 600180 | O-ring |
| 11 | 2021900 | Piston |
| 12 | 1080190 | O-ring |
| 13 | 2021960 | Fork |
| 14 | 620301 | Plug |
| 15 | 1460430 | O-ring |
| 16 | 1460260 | Piston |
| 17 | 1540140 | Spring |
| 18 | 2021540 | Injector |
| 19 | 820510 | O-ring |
| 20 | 1465720 | O-ring |
| 21 | 1250270 | Spring |
| 22 | 1250280 | Ball |
| 23 | 480480 | O-ring |
| 24 | 2320210 | Fitting |
| 25 | 480560 | O-ring |
| 26 | 2320180 | Hose tail |
| 27 | 1460150 | Piston |
| 28 | 2240 | Fitting assembly - DISCONTINUED |
| D | 2791 | Seal kit |
| 555 - 12356 - MOTOR Pag.4 |
||
| 1 | 2029738 | TSS box assembly |
| 2 | 2320060 | Wobble plate |
| 3 | 1461430 | Bearing |
| 4 | 1460530 | Oil seal |
| 5 | 2320020 | Pump body |
| 6 | 2320090 | Screw |
| 7 | 1460590 | Bearing |
| 8 | 1460040 | Shield |
| 9 | 1461200 | Oil seal |
| 10 | 394280 | O-ring |
| 11 | 1460370 | Fan |
| 12 | 660170 | O-ring |
| 13 | 2320131 | Box |
| 14 | 1262400 | Washer |
| 15 | 2020570 | Screw |
| 16 | 2320270 | Cover |
| 17 | 2320280 | Switch |
| 18 | 2021480 | Gland |
| 19 | 1760450 | Cable |
| 20 | 2320640 | O-ring |
| 21 | 1982190 | Capacitor |
| 22 | 4609 | Motor |
| 555 - 12356 - STANDARD ACCESSORIES Pag.5 |
||
| 1 | 40167 | Lance+rotopower |
| 2 | 40206 | Lance+lance head |
| 3 | 40925 | Gun |
| 4 | 1460702 | High pressure hose |
| 5 | 2000770 | O-ring |
