Annovi & Reverberi Parts for Pressure Washer AR840
€30.47
Tax included
Annovi & Reverberi Parts for Pressure Washer AR840
We are Annovi & Reverberi original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer Blue Clean Blue Clean AR840.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi & Reverberi Parts for Pressure Washer AR840
We are Annovi & Reverberi original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer Blue Clean Blue Clean AR840.
In the following tables, look for the spare part and its respective code.
| Pressure Washer AR 840 Casing | ||
| # | Part Num. | Description |
| 1 | 2281640 | Handle |
| 2 | 2281630 | Frame |
| 3 | 2281700 | Knob |
| 4 | 2281690 | Antivibration |
| 5 | 380561 | Wheel |
| 6 | 50016 | Stopper |
| 7 | 320620 | Washer |
| 8 | 200230 | Screw |
| 9 | 2240110 | Nut |
| 10 | 4554 | Engine |
| 11 | 1262790 | Pipe Cleaner |
| 12 | 1341030 | Filter |
| 13 | 1269115 | Pre-Assembly Tube |
| 14 | 2180150 | Pipe Cleaner |
| 15 | 961900 | Screw |
| Pump 840 | ||
| 1 | 960160 | O-Ring |
| 2 | 960850 | Stopper |
| 3 | 889052 | Complete Valve |
| 4 | 1382740 | Tenuta Water |
| 5 | 880581 | Stopper |
| 6 | 820510 | O-Ring |
| 11 | 960110 | Ring |
| 12 | 1382740 | Tenuta Water |
| 13 | 1380090 | Piston Guide |
| 14 | 961240 | O-Ring |
| 15 | 880330 | Tenuta Water |
| 16 | 1383130 | Ring |
| 17 | 850370 | Screw |
| 18 | 1380050 | Support |
| 19 | 640030 | O-Ring |
| 20 | 2280340 | Bearing |
| 21 | 1382770 | Pump Housing |
| 22 | 880130 | Stopper |
| 23 | 962010 | Nut |
| 24 | 962000 | Washer |
| 25 | 1380940 | Piston |
| 26 | 1380950 | Disk |
| 27 | 600180 | O-Ring |
| 28 | 1380920 | Piston |
| 29 | 1380060 | Plug |
| 30 | 1383020 | Piston Rod |
| 31 | 1080401 | Ring |
| 32 | 1381850 | Washer |
| 34 | 1780510 | O-Ring |
| 35 | 1789010 | Cover |
| 36 | 1343510 | Screw |
| 37 | 2280130 | Tree |
| 38 | 820440 | Screw |
| 39 | 621170 | Ring |
| 40 | 1380120 | Thickness 0.10 Mm |
| 40 | 1380130 | Thickness 0.20 Mm |
| 40 | 1380530 | Thickness 0.25 Mm |
| 40 | 1382810 | Thickness 0.05 Mm |
| 41 | 2281510 | Flange |
| 42 | 740290 | O-Ring |
| 43 | 1980740 | Stopper |
| 46 | 1980740 | Stopper |
| 47 | 180101 | O-Ring |
| 49 | 2281590 | Head |
| 50 | 820150 | Screw |
| 71 | 180030 | Screw |
| 77 | 1383150 | Bearing |
| 78 | 2289235 | Pre-Assembly Head |
| 86 | 1260250 | Level Indicator |
| 87 | 1260430 | Ring |
| 88 | 1780690 | Disk |
| 89 | 1140450 | O-Ring |
| 91 | 1381580 | Manometer |
| 92 | 1380220 | O-Ring |
| 94 | 50129 | Valve |
| 95 | 20699 | Pre-Assembly Pump |
| A | 1828 | Kit Valves |
| B | 2757 | Piston Kit |
| C | 1856 | Kit Oil Seals |
| E | 1857 | Water Seals Kit |
| G | 1829 | Kit Support Rings |
| Valve 840 | ||
| 1 | 1560580 | Stopper |
| 2 | 540290 | Screw |
| 3 | 1660210 | Nut |
| 4 | 1560400 | Knob |
| 5 | 1080070 | Plug |
| 6 | 1560420 | Screw |
| 7 | 1560410 | Driving |
| 8 | 1560440 | Disk |
| 9 | 1560350 | Spring |
| 10 | 1080610 | Disk |
| 11 | 1080660 | Plug |
| 12 | 1080540 | Piston |
| 13 | 391000 | O-Ring |
| 14 | 1080640 | Ring |
| 15 | 1560150 | O-Ring |
| 16 | 1560100 | Shutter |
| 17 | 1560140 | Spring |
| 18 | 180101 | O-Ring |
| 19 | 1540272 | Screw |
| 21 | 1560010 | Valve Body |
| 22 | 1080550 | Ring |
| 23 | 480480 | O-Ring |
| Accessories 840 | ||
| 1 | 3082 | Nozzle |
| 2 | 40541 | Lancia + Head Without Nozzle |
| 3 | 40650 | Lancia + Head |
| 4 | 41322 | Gun |
| 5 | 1540110 | Washer |
| 6 | 3119 | High Pressure Tube |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
