AR Farmer's Division Parts for Pressure HOT 1408
We have the original AR Farmer's Division Parts for Pressure Washer HOT 1408 - 26412 Parts, the diagram and parts list and tool repair that help you need to get your tools running like new again.
Fix Your Pressure Washer HOT 1408. All Spares are original and can be supplied at Low and discounted prices. Our Parts are Genuine and with a Guarantee.
In the following tables, look for the spare part and its respective code.
| ARSG HOT 1408 230 V - 50 Hz - 26412 - Casing Pag.1 | ||
| # | Part Num. | Description |
| 1 | 3520093 | Casing |
| 2 | 3520520 | Base |
| 3 | 3520260 | Gland |
| 4 | 3520230 | Wheel |
| 5 | 3520240 | Washer |
| 6 | 3520254 | Guard |
| 7 | 3520170 | Tank |
| 8 | 3520180 | Plug |
| 9 | 3520072 | Knob |
| 10 | 3520082 | Casing |
| 11 | 3520060 | Handle |
| 12 | 3520870 | Cable |
| ARSG HOT 1408 230 V - 50 Hz - 26412 - Pump Pag.2 |
||
| 1 | 800220 | Screw |
| 2 | 2900430 | Head |
| 3 | 2849051 | Complete valve |
| 4 | 2200141 | Water seal |
| 5 | 770590 | O-ring |
| 6 | 2840550 | Bushing |
| 7 | 2840540 | Bushing |
| 8 | 1683500 | Oil seal |
| 9 | 480560 | O-ring |
| 10 | 2900500 | Screw |
| 11 | 2900020 | Piston guide |
| 12 | 2901170 | Spring |
| 13 | 2840530 | Piston |
| 14 | 2840050 | Lock |
| 15 | 2840470 | Screw |
| 16 | 2900350 | Plug |
| 17 | 740290 | O-ring |
| 18 | 2840130 | Plug |
| 19 | 2840150 | Seat |
| 20 | 600180 | O-ring |
| 21 | 2900100 | Fitting |
| 22 | 1460430 | O-ring |
| 23 | 2909005 | Spring assembly |
| 24 | 2901070 | Shutter |
| 25 | 2900130 | Fitting |
| 26 | 2022201 | Fork |
| 27 | 2029753 | TSS box assembly |
| 28 | 880581 | Plug |
| 29 | 620301 | Plug |
| 30 | 1080091 | Spring |
| 31 | 800560 | O-ring |
| 32 | 2901060 | Injector |
| 33 | 2909137 | Head assembly |
| A | 2233 | Valve kit |
| B | 2313 | Piston kit |
| C | 42124 | Oil seal kit |
| F | 42438 | Gasket kit |
| ARSG HOT 1408 230 V - 50 Hz - 26412 - Motor Pag.3 |
||
| 1 | 3040270 | O-ring |
| 2 | 2900170 | Bearing |
| 3 | 2900520 | Wobble plate |
| 4 | 1780490 | Bearing |
| 5 | 2320090 | Screw |
| 6 | 2900010 | Pump body |
| 7 | 1462400 | Stud bolt |
| 8 | 1460530 | Oil seal |
| 9 | 1460590 | Bearing |
| 10 | 1460040 | Shield |
| 11 | 1461200 | Oil seal |
| 12 | 394280 | O-ring |
| 13 | 1460370 | Fan |
| 14 | 1460340 | Conveyor |
| 15 | 1680960 | Washer |
| 16 | 1460460 | Screw |
| 17 | 3520050 | Pressure switch |
| 18 | 660170 | O-ring |
| 19 | 2320131 | Box |
| 20 | 1260490 | Washer |
| 21 | 2020570 | Screw |
| 22 | 2320271 | Cover |
| 23 | 1462900 | Gland |
| 24 | 1982590 | Capacitor |
| 25 | 2320640 | O-ring |
| 26 | 44518 | Motor 240V Ass'y |
| 27 | 24230 | Electric pump assembly |
| 28 | 3523500 | Connector |
| 29 | 1262400 | Washer |
| ARSG HOT 1408 230 V - 50 Hz - 26412 - Boiler Pag.4 |
||
| 1 | 3520630 | Pipe coil |
| 2 | 3520620 | Pin |
| 3 | 3520610 | Clamp |
| 4 | 3520600 | Plate |
| 5 | 3520590 | Plate |
| 6 | 3520330 | Cover |
| 7 | 3520790 | Valve |
| 8 | 3520800 | Fan- Substituited by Kit 3520800 |
| 9 | 3520320 | Box- Substituited by Kit 3520800 |
| 10 | 3520810 | Motor- Substituited by Kit 3520800 |
| 11 | 3520310 | Cover |
| 12 | 3521300 | Boiler |
| 13 | 3520860 | Transformer |
| 14 | 3520770 | Cable |
| 15 | 3520650 | Gasket |
| 16 | 3520660 | Element |
| 17 | 3520670 | Support |
| 18 | 3520680 | Nozzle |
| 19 | 3520690 | Flange |
| 20 | 3520710 | Plate |
| 21 | 3520700 | Electrode |
| 22 | 3520820 | Cover |
| ARSG HOT 1408 230 V - 50 Hz - 26412 - Fuel Circuit Pag.5 |
||
| 1 | 3522760 | Pump |
| 2 | 3520730 | Hose tail |
| 3 | 3520740 | Clamp |
| 4 | 3520750 | Pipe |
| 5 | 3520760 | Filter |
| 6 | 3520750 | Pipe |
| ARSG HOT 1408 230 V - 50 Hz - 26412 - Water Circuit Pag.6 |
||
| 1 | 3521470 | Pipe |
| 2 | 3520490 | Fork |
| 3 | 3520420 | Fitting |
| 4 | 3520430 | Piston |
| 5 | 3520440 | Spring |
| 6 | 3520450 | Bushing |
| 7 | 3520460 | O-ring |
| 8 | 3520510 | Fork |
| 9 | 3520480 | Plug |
| 10 | 3520500 | O-ring |
| 11 | 3520540 | Ring |
| 12 | 3520240 | Washer |
| 13 | 3520410 | O-ring |
| 14 | 3520530 | Fitting |
| 15 | 3520370 | Fitting |
| 16 | 3520360 | Fitting |
| 17 | 3520580 | Washer |
| 18 | 3520570 | Screw |
| 19 | 3520930 | Thermostat |
| 20 | 3520470 | O-ring |
| ARSG HOT 1408 230 V - 50 Hz - 26412 - Electric Circuit Pag.7 |
||
| 1 | 3520270 | Knob |
| 2 | 3520280 | Shim |
| 3 | 3520300 | Element |
| 4 | 3520290 | O-ring |
| 5 | 3520340 | O-ring |
| 6 | 3520350 | Fuse holder |
| 7 | 3520850 | Switch |
| 8 | 3520840 | Board |
| ARSG HOT 1408 230 V - 50 Hz - 26412 - Standard Accessories Pag.8 |
||
| 1 | 41047 | Gun |
| 2 | 50690 | Lance |
| 3 | 3729 | Nozzle |
| 4 | 40320 | Tank |
| 5 | 3520550 | High pressure hose |
| 6 | 391000 | O-ring |
| 7 | 2000570 | O-ring |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
