Ama Spare Parts for Lawnmower RS421
We have the original AMA Garden Parts, the diagram and parts list and tool repair that help you need to get your tools running like new again.
Fix Your Push-Lawnmower RS421 - 89501. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Electric Lawn Mower and the respective parts of the code.
| AMA Garden Push-Lawnmower RS421 - 89501 | ||
| Handle Pag.1 | ||
| # | Part Num. | Description |
| 1 | 88566 | Foam rubber Handle Grip |
| 2 | 84957 | Stop lever |
| 4 | 89399 | Lever guard |
| 5 | 84822 | Brake Cable Assy plate |
| 7 | 84959 | Upper handrail |
| 8 | 88568 | Rope Guide |
| 9 | 88564 | Cap nut |
| 10 | 84829 | Engine Stop cable |
| 12 | 84972 | Triangle knob |
| 15 | 84974 | Triangle knob |
| 18 | 89476 | Lower handrail |
| 19 | 88247 | Fastener |
| 20 | 73845 | Thin knob |
| 21 | 89867 | Handrail stopper |
| Chassis Pag.2 | ||
| 1 | 55823 | Petrol engine |
| 5 | 89514 | Rear discharge base |
| 6 | 89506 | Rear discharge base |
| 7 | 89507 | Bolt |
| 9 | 89504 | Right bracket |
| 13 | 89503 | Height Adjustment Pull Rod |
| 14 | 88628 | Hexagon head bolts |
| 15 | 89525 | Deck assy. |
| 16 | 89518 | Height adjustment board |
| 17 | 89517 | Right bracket |
| 19 | 89447 | Inlet |
| 20 | 89448 | Pipe connector nut |
| 21 | 89515 | Cable stopper |
| Front Axle Pag.3 | ||
| 1 | 89477 | Outer cover of hub |
| 2 | 89450 | Self-locking nut |
| 3 | 73848 | Wheel punch bearing |
| 4 | 89519 | Wheel assy. |
| 5 | 89521 | Front drive assy. |
| 6 | 88625 | R type pin |
| Back Axle Pag.4 | ||
| 1 | 89477 | Outer cover of hub |
| 2 | 89450 | Self-locking nut |
| 3 | 73848 | Wheel punch bearing |
| 4 | 89478 | Wheel assy. |
| 5 | 73201 | Height adjustment ball |
| 6 | 89479 | Rear drive assy. |
| 7 | 88625 | R type pin |
| Bag Pag.5 | ||
| 2 | 89516 | Back |
| 3 | 84987 | Cover spring |
| 4 | 88116 | Shaft for rear discharge cover |
| 5 | 89499 | Air-out board of fabric grass bag |
| 6 | 89498 | Protection board of grass bag |
| 7 | 89524 | Top of grass box |
| 10 | 89488 | Plastic top frame |
| 11 | 89486 | Fabric grass bag |
| Blade Pag.6 | ||
| 1 | 89522 | Blade Boss |
| 2 | 89523 | Blade |
| 3 | 73223 | Blade washer |
| 4 | 84815 | Inch hex flange bolts |
