Skil original spare parts for replacing engine parts or parts of the frame or repairing damaged and worn components of Belt Sander 1220/F 015 122 011.
In the following table, look for the model of the Belt Sander the respective parts of the code.
| Belt Sander 1220/F 015 122 011 | ||
| # | Part Num. | Description |
| 2 | 2610398706 | Field230V |
| 3 | 2610398707 | Armature230V |
| 4 | 2610398709 | On-Off Switch |
| 5 | 1607000386 | Power supply cordEU 230V 4,15m 2 x 1,0mm H05 RN-F |
| 2604460222 | Power supply cordGB 230V 4,15m 2 x 1,0mm H05 RN-F | |
| 1604460403 | Power supply cordCH 230V 4,15m 2 x 1,0mm H05 RN-F | |
| 6 | 2610397124 | Grommet |
| 7 | 2610393890 | Cable Clip |
| 12 | 2610398717 | Suppression Capacitor |
| 16 | 2610398705 | Carbon-Brush Set |
| 20 | 2610Z03240 | Belt Cover |
| 21 | 2610398698 | Toothed Belt |
| 22 | 2610398699 | Fork |
| 23 | 2610398700 | Fork Lever |
| 24 | 2610398701 | Base Plate |
| 25 | 2610398702 | Cover |
| 26 | 2610398703 | Control Lever |
| 27 | 2610398704 | Drive disk |
| 28 | 2610398708 | Toothed Pulley |
| 29 | 2610398710 | Bearing Housing |
| 30 | 2610398711 | Housing |
| 31 | 2610398712 | Housing Cover |
| 32 | 2610398713 | Button Set |
| 33 | 2610398714 | Induction Coil |
| 34 | 2610398715 | Mounting Plate |
| 35 | 2610398716 | Drive Shaft |
| 650 | 2610Z02870 | Dust Bag |
| 651 | 2610398155 | Adapter |
