Ama Spare Parts for Lawnmower NRT-52X
€11.90
Tax included
Ama Spare Parts for Lawnmower NRT-52X
Ama original spare parts for to fix of engine or chassis parts or to repair damaged components of Self-Propelled Lawnmower MVG TX (196CC) STAGE V - Cod. 92599 - NRT-52X - 92635.Fix Your Lawnmower NRT-52X. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Ama Spare Parts for Lawnmower NRT-52X
Fix Your Self-Propelled Lawnmower MVG TX (196CC) STAGE V - Cod. 92599 - NRT-52X - 92635. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Engine Lawnmower and the respective parts of the code.
| Self-Propelled Lawnmower NRT-52X - Cod. 92635 | ||
| Handle Pag.1 | ||
| # | Part Num. | Description |
| 1 | 88566 | Foam Rubber Handle Grip |
| 2 | 89398 | Stop lever |
| 3 | 92562 | Self-propelled Lever |
| 4 | 84959 | Upper handrail |
| 5 | 88568 | Rope Guide |
| 6 | 88564 | Cap nut |
| 7 | 84822 | Brake Cable Assy plate |
| 10 | 89399 | Plastic stopper |
| 11 | 84836 | Selfpropelled cable |
| 12 | 84971 | Brake cable |
| 15 | 92504 | Triangle knob |
| 17 | 84973 | Lower handrail |
| 18 | 88247 | Fastener |
| 20 | 88571 | Half round head square neck bolts |
| 22 | 92503 | Triangle knob |
| Deck Pag.2 |
||
| 1 | 92565 | Deck welding assy. |
| 3 | 89447 | Inlet |
| 4 | 90504 | Pipe connector nut |
| 5 | 89515 | Cable stopper |
| 6 | 88360 | Left handle bracket |
| 7 | 88361 | Rigth handle bracket |
| 10 | 88362 | Height adjustment board |
| 11 | 84976 | Rear drive bracket |
| 13 | 73221 | Pull Spring for Pull Rod |
| 14 | 84977 | Height Adjustment Pull Rod |
| 15 | 88625 | R type pin |
| 18 | 88244 | Mulching plug |
| 20 | 92558 | Bracket plate for defelctor |
| 21 | 92540 | Mulching board |
| 22 | 92508 | Side discharge cover |
| 23 | 88418 | Mulch Shaft |
| 24 | 84981 | Mulch board spring |
| 26 | 92544 | Front mask |
| 27 | 90263 | Front mask |
| 38 | 92550 | Fixed block holder |
| 39 | 92555 | Limit block spring |
| 40 | 92547 | The side row overlays |
| 41 | 92554 | The side row covers |
| Traction Pag.3 |
||
| 1 | 84982 | Rear drive assy. |
| 1.1 | 92545 | Height adjustment ball |
| 2 | 92538 | Selfpropelled assy. |
| 3 | 92529 | Bush |
| 4 | 84976 | Displacement pressure plate |
| 5 | 84976 | Displacement pressure plate |
| 6 | 92549 | Inner cover of hub |
| 7 | 79423 | Spring washer |
| 8 | 89889 | Selfpropelled ratchet washer |
| 9 | 89919 | Ratchet Wheel L |
| 10 | 89920 | Ratchet Wheel R |
| 11 | 90304 | Ratchet pin |
| 12 | 89887 | Wheel assy. |
| 15 | 92532 | Outer cover of hub |
| 16 | 84986 | Selfpropelled spring |
| 17 | 88443 | V-belt |
| 18 | 92557 | Brake spring |
| Front Axle Pag.4 |
||
| 1 | 92567 | Front drive assy. |
| 2 | 89885 | Wheel assy |
| 4 | 89450 | Self-locking nut |
| 5 | 92530 | Outer cover of hub |
| 7 | 92552 | Resilient washer |
| Grass Box Pag.5 |
||
| 1 | 92556 | Fabric metal frame |
| 2 | 92507 | Top of grass box |
| 3 | 92551 | Filter net of grass bag |
| 4 | 92527 | Fabric grass bag |
| 5 | 92548 | Rear discharge cover |
| 6 | 88419 | Shaft for rear discharge cover |
| 7 | 84987 | Cover spring |
| 9 | 89883 | Rear disch. cover dust proof board |
| 10 | 88625 | R type pin |
| 11 | 90513 | Blade washer |
| Blade Pag.6 |
||
| 1 | 84844 | Blade Adapter Assy |
| 2 | 84935 | Blade |
| 3 | 73223 | Blade washer |
| 4 | 84815 | Inch hex flange bolts |
| 5 | 88628 | Hexagon head bolts |
| 8 | 84989 | Belt cover |
| 9 | 92599 | Petrol engine |
| Engine MVG TX (196CC) STAGE V - Cod. 92599 Pag.7 |
||
| 1 | RMG25170110000 | Fuel tank cap |
| 2 | RMGP65050106000 | Fuel tank cap sponge |
| 3 | RMGP65050102000 | Fuel Tank Cap seal gasket |
| 4 | 92486 | Connect cable of fuel cap |
| 5 | Standard | Hex flange nuts |
| 6 | RMG60190310000 | The oil tank mount big washer |
| 7 | RMG25310030000 | Tank damping rubber pad |
| 8 | RMG25180230000 | Fuel tank body |
| 9 | RMGP65050500000 | Filtering Net Duct of Fuel |
| 10 | RMG60230020000 | Fuel pipe lock clamp I |
| 11 | RMG25160020000 | Fuel pipe |
| 12 | RMG60230010000 | Fuel pipe lock clamp II |
| 13 | RMG60240250000 | Fuel tank mounting bushing |
| 14 | RMG60140050000 | Hex flange nuts |
| 15 | RMG75210020000 | Starter hub |
| 16 | RMGP70B07040000 | Fan |
| 17 | 92467 | Flywheel assy |
| 18 | 88621 | Bolt |
| 19 | RMGV510000000 | Respirator Cover Plate |
| 20 | RMGV510020000 | Respirator head gasket |
| 21 | RMGV510010000 | Respirator valve plate |
| 22 | RMG75150010000 | Oil filter |
| 23 | Standard | Bolt |
| 24 | RMG75330060000 | Main bracket of fuel tank |
| 25 | 92475 | Detent assy. |
| 26 | RMG75030070000 | wind shield |
| 27 | 92492 | Waste pipe |
| 28 | RMGP65010105000 | Rate-limiting rocker arm shaft |
| 29 | RMG60200490000 | Gasket |
| 30 | RMGP65010112000 | Oil seal |
| 31 | Standard | R type pin |
| 32 | RMGV510103000 | Handspike of Valve |
| 33 | RMGP65010601000 | Valve spring |
| 34 | RMGV510004000 | Throttle rocker arm |
| 35 | 92496 | Bolt |
| 36 | Standard | Clip |
| 37 | RMGP70B01060000 | Single phrase throttle assy. |
| 38 | RMG60410640000 | Throttle control spring |
| 39 | 92476 | Connecting rod assy. |
| 40 | 92495 | Crankshaft assy. |
| 41 | 92477 | Camshaft assy. |
| 42 | RMGP65080300000 | Pin |
| 43 | RMGV510009000 | Clockwise gear gasket |
| 44 | RMGV510007000 | Respirator head gasket |
| 45 | RMGP65010206000 | Rate-limiting gear shaft |
| 46 | RMGP65010202000 | Sliding Sleeve |
| 47 | 92478 | Rate-limiting gear assy. |
| 48 | RMGV410001000 | Rate-limiting gear shaft |
| 49 | RMG60200060000 | Gasket |
| 50 | RMG60280030000 | Spacing pin |
| 51 | RMGV510008000 | Crank box cover |
| 52 | RMG60280050000 | Spacing pin |
| 53 | Standard | Locking bolt |
| 54 | RMGP65010210000 | Oil seal |
| 55 | 92498 | Oil drain bolt gasket |
| 56 | 92497 | Oil drain bolt |
| 57 | 92511 | Lubricating Gauge Assy |
| 58 | 92499 | Distance Sleeve of Lub. Setting |
| 59 | Standard | Bolt |
| 60 | RMGP65040101000 | Air Filter Upper Cover |
| 61 | RMGP65040104000 | Paper filter |
| 62 | RMGP65040106000 | Coarse sponge filter |
| 63 | RMGP65040103000 | Exhaust Gas Cover Board |
| 64 | RMGP65040102002 | Air filter base assy.(II) |
| 65 | RMG75130110000 | Piston Ring II |
| 66 | RMG75130120000 | Piston Ring II |
| 67 | RMG75090050000 | Guide Rail |
| 68 | RMG75000060000 | Bushing Ring |
| 69 | RMGH140002000 | Piston pin |
| 70 | RMG75120070000 | Piston |
| 71 | RMGH140003000 | Washer |
| 72 | RMG60010140000 | Rolling bearing |
| 73 | 92494 | Oil seal |
| 74 | RMG75500140000 | Crankshaft box assy. |
| 75 | RMGP65030500000 | Empty filter paper pad |
| 76 | RMG75410610000 | Carburetor |
| 77 | 92482 | Intake pipe paper pad II |
| 78 | RMGP70B03040000 | Air Inlet Pipe |
| 79 | RMGP70B03020000 | Intake pipe paper pad I |
| 80 | 60080030000 | Dual-head bolts |
| 81 | RMGP65051000001 | Prime button II |
| 82 | RMGP70B08020000 | Push rod |
| 83 | RMGP70B08030000 | Push rod director plate |
| 84 | 92512 | Valve rocker arm support bolts |
| 85 | RMGP65080200000 | Rocker of Valve |
| 86 | 92513 | Valve adjustment nut |
| 87 | 92514 | And nuts |
| 88 | 92515 | Cylinder head cover II |
| 89 | 92483 | Respirator head gasket |
| 90 | 92516 | Cylinder head cover I |
| 91 | RMGP65081100000 | Top Cover of Exhaust Valve |
| 92 | 92517 | Spring Coil of Exhaust Valve |
| 93 | RMGP70B08080000 | valve spring |
| 94 | 92518 | Oil seal assy |
| 95 | 79567 | Spark plug |
| 96 | RMGP70B02010000 | Cylinder head assy. |
| 97 | RMGP70B08070000 | Exhaust Valve |
| 98 | RMGP70B08060000 | Intake Valve |
| 99 | RMG60280020000 | Spacing pin |
| 100 | RMGP70B02040000 | Cylinder head gasket |
| 101 | RMGP65060200000 | Muffler insulating pad |
| 102 | 92485 | Muffler assy. |
| 103 | 92523 | Muffler cover assy. |
| 104 | Standard | Self-locking nut |
| 105 | 92519 | wind shield |
| 106 | Standard | Bolt |
| 107 | RMG60080290000 | Double-head bolts I |
| 108 | RMG75370032000 | Ignition assy. |
| 109 | RMG60080210000 | Double-head bolts II |
| 110 | Standard | Bolt |
| 111 | RMG60080300000 | Double-head bolts III |
| 112 | RMG25190250000 | The transparent cover |
| 113 | RMG65070100000 | Pull starter assy. |
| 114 | 88564 | Cap nut |
| 115 | RMG25190210086 | The transparent cover |
| 116 | Standard | Bolt |
| 117 | 92524 | Single speed control panel |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
