Ama Spare Parts for Lawn Tractor SG-200-102H – 13895

Name: Ama Spare Parts for Lawn Tractor SG-200-102H – 13895
Brand: A.M.A. S.p.A.
SKU: Ama SG-200-102H – 13895
Availability: OutOfStock

€0.00

Tax included

Ama Spare Parts for Lawn Tractor SG-200-102H – 13895

For Availability and order management times, call our telephone numbers.

Quantity

Out-of-Stock

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Ama Spare Parts for Lawn Tractor SG-200-102H – 13895

We are AMA Garden original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Lawn Tractor SG-200-102H – 13895-vers.2006.

For Availability and order management times, call our telephone numbers.

In the following table, look for the model of the Lawn Tractor and the respective parts of the code.

LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.1
#	Part Num.	Description
1	000888305	Oil drain valve
2	201958449	Oil drain coupler
4	205577120	Engine, INTEK V-TWIN 20 HP-B&S
5	204958052	Fuel tank cap
6	204958344	Fuel tank
7	204056368	Fuel line 860mm
8	000476300	Fuel tank valve
9	000318164	Fuel line clamp UM 5008
10	200058527	Fuel line 320mm
11	000299530	Hex screw M8x35 DIN 933 8.8
12	000291500	Flat washer 8.4 DIN 125 A
13	000280885	Self locking nut M8 DIN 985 CI.8
14	000201003	Spring washer 8 DIN 127 B
15	000201531	Exhaust screw 5/16-18NC 3/4 LG
18	000244563	Hex screw M8x20 DIN 933 8.8
19	195800062	Muffler heat guard, left
20	505900065	Taptite thread form screw M6x12 DIN 7500 D
21	505900054	Muffler
22	204056367	Seaming profil
23	204056363	Insert
24	820002202	Bushing 18x2
25	203800004	Bushing 16x2 KD 7
26	204958051	Fuel tank holder
27	204958050	Holder
28	195800926	Muffler heat guard, right
30	595900101	Exhaust tube, left - INTEK
31	595900102	Exhaust tube, right - INTEK
32	571001801	Exhaust gasket 18 HP - INTEK
37	000247357	Screw M6x12 DIN 933 8.8
38	000283118	Self locking nut M6 DIN 985 Cl.8
39	200058399	Heat shield
40	000290389	Flat washer 6.4 DIN 125 A
41	000259094	Screw M5x12 Ecofix 4.8
42	000239448	Flat washer 5.3 DIN 9021 B
43	000285912	Self locking nut M5 DIN 985 Cl.8
44	204601206	Screw M6x12 BN 11 252 10.9
45	000245124	Hex screw M8x30 DIN 933 8.8
46	000243441	Hex screw M8x16 DIN 933 8.8
47	205010160	Fuel line clamp 10/16-7.5
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.2
1	221012090	Hex screw M12x90 DIN 931 8.8
2	201221175	Hex screw M10x75 DIN 931 8.8
3	201058447	Spacer
4	000740113	Grease fitting MK 6 DIN 71412
5	000295966	Flat washer 19 DIN 125 A
6	000230230	Spring clip 15 DIN 6799
7	000093852	Front axle
8	000292061	Flat washer 10.5 DIN 125 A
9	000281446	Self locking nut M10 DIN 985 Cl.8
10	505900004	Front axle bushing
11	000282557	Self locking nut M12 DIN 982 Cl.8
12	000069080	Tie rod front axle
13	000207152	Square key 5x7.5 DIN 6888
14	000283118	Self locking nut M6 DIN 985 Cl.8
15	000407121	Hub cap SC 1-1/2
16	000230230	Spring Clip 15 DIN 6799
17	204958041	Washer with tube
18	204959299	Front tyre wheel assy 16x6.5-8 KST
19	205956136	Spindle, left
20	221006045	Hex screw M6x45 DIN 931 8.8
21	200058647	Steering spindle lever for Y2K
22	000273625	Hex nut M10 DIN 934 Cl.8
23	204101006	Self locking nut M10 DIN 980 8/V
26	000235246	Locking stirrups 16 DIN 71805 S
27	200958718	Spindle, right
50	204598001	Tyre 16x6.5-8 KENDA SUPER TURF
51	000415426	Tube 16x6.5-8
52	204598024	Rim complete 16x6.5-8
55	195800901	Ball angle joint 16
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.3
22	000273625	Hex nut M10 DIN 934 Cl.8
23	204101006	Self locking nut M10 DIN 980 8/V
26	000235246	Locking stirrups 16 DIN 71805 S
55	195800901	Ball angle joint 16
70	000243441	Hex screw M8x16 DIN 933 8.8
71	000280885	Self-locking nut M8 DIN 985 Cl.8
72	000291500	Flat washer 8.4 DIN 125 A
73	000244563	Hex screw M8x20 DIN 933 8.8
74	000230230	Spring clip C15 DIN 6799
75	105800970	Spacer, upper
76	505900002	Spherical bearing FJB 12
77	105800969	Spacer, lower
78	195800920	Steering shaft pinioin gear
79	000282557	Self-locking nut M12 DIN 985 Cl.8
80	505900043	Eccentric bolt washer 12.4x50x5
81	000281446	Self-locking nut M10 DIN 985 Cl.8
82	201058244	Bushing
83	201058248	Steering plate
84	000040667	Sector gear
85	201058246	Shoulder bolt
86	201058247	Steering pin
87	220012045	Hex screw M12x45 DIN 933 8.8
88	000050413	Drag link
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.4
1	505900074	Idler pulley V3000-3316-steel
2	000280885	Self locking nut M8 DIN 985 CI.8
3	000291500	Flat washer 8.4 DIN 125 A
4	201852564	Hex screw M10x50 DIN 931 8.8
5	201058144	Retainer
6	201852454	Flat washer 10.5 DIN 7349
11	200492077	Traction v-belt La 103
12	000358698	Tuff Torq transmission K46
13	000407121	Hub cap SC 1-1/2 - black
14	000230230	Spring clip 15 DIN 6799
15	204958041	Washer with tube
16	000299299	Square key 3/16x3/16x2.5
17	203959262	Rear tyre wheel assy 20x10.00-8 KST
18	200058432	Spacer, axle
19	201221875	Hex screw M8x75 DIN 931 8.8
22	000238414	Hex screw M10x40 DIN 931 8.8
23	000292061	Flat washer 10.5 DIN 125 A
24	000091993	Idler bushing
25	000281446	Self locking nut M10 DIN 985 CI.8
28	200058260	Spring
31	000244563	Hex screw M8x20 DIN 933 8.8
33	000924605	Retainer
35	000273955	Square key 1/4x1/4x1-1/4
36	000294833	Clutch bolt 7/16-20x2-1/2 LG
37	000276012	Spring washer 7/16
38	000892595	El. magnet clutch Warner MSS-80C 5217-9
39	200959137	Engine pulley
42	000298760	Flat washer 8.4 DIN 9021 B
43	200958721	Idler arm
44	000786445	Idler pulley F 3000-0750
60	204598004	Tyre 20x10.00-8 KENDA SUPER TURF
61	000496826	Tube 20x10.00-8
62	204598018	Rim complete 20x10.00-8
66	200958444	Stabilizer
67	000221845	Screw M8x45 DIN 931 10.9
68	000246235	Screw M8x25 DIN 933 8.8
72	201058448	Support plate
73	000740113	Grease fitting MK 6 DIN 71412
74	203958746	Bracket, left
75	203958007	Bracket, right
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.5
1	000784256	Handle grip - black
2	000015994	Ratchet pivot plate
3	000403535	Plunger button - black
4	000045639	Connection rod
5	000280885	Self-locking nut M8 DIN 985 Cl.8
7	000244563	Hex screw M8x20 DIN 933 8.8
8	201058107	Gear segment
9	000001485	Spring
10	105800953	Arm lever pin
11	000926222	Height adjustment arm lever
12	275200006	Clip for pin 6 DIN 6799
13	000324467	Spring pin 5x30 DIN 1481
14	201958365	Height adjuster shaft
17	000291500	Flat washer 8.4 DIN 125 A
21	000281446	Self-locking nut M10 DIN 985 Cl.8
22	000292061	Flat washer 10.5 DIN 125 A
23	000910283	Eye bolt M10x50x14 - Zc
24	000080608	Lift spring
25	000957110	Pivot arm assy
27	000072985	Lifting pin
29	000235323	Cotter pin 5x50 DIN 94
30	202958277	Bent pin
31	000033242	Hair pin 2.5-63
32	203958340	Front suspension mower deck
35	204150124	Ring 12x25x2,5
36	000293172	Flat washer 13 DIN 125 A
37	203058106	Pin
38	000075812	Hair pin clip 3.15-49
41	200958670	Height adjustment rod
42	000282218	Cotter pin 2x18 DIN 94
43	202056038	Rubber washer
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.6
103	105800975	Spring lever
104	000200090	Flat washer 4.3 DIN 125 A
105	000284240	Self locking nut M4 DIN 985 CI.8
107	200958754	Bracket, brake rod
112	000406560	Caps A281/B1 1/2
113	200058634	Lever bypass
114	204056342	Plastic cap
116	201958399	Arm, by-pass lever
118	000290389	Flat washer 6.4 DIN 125 A
119	200258742	Cotter pin 1.6x12 DIN 94
120	000411312	Pedal pad - black
121	195800998	Pedal
123	000280885	Self locking nut M8 DIN 985 CI.8
124	000291500	Flat washer 8.4 DIN 125 A
125	000054340	Brake spring
126	200958651	Brake connecting rod
128	200958707	Brake - shaft
129	000060280	Hand brake spring
130	195800964	Hand brake lever
131	000244563	Hex screw M8x20 DIN 933 8.8
132	000048400	Parking brake lever clamp
135	000291610	Spring pin 5x22 DIN 1481
136	220004025	Hex screw M4x25 DIN 933 8.8
137	200059136	Hair pin 1.8-36
138	200958761	Bracket, brake rod
139	200058690	Spring
140	201058193	Plate by-pass
141	200208243	Stirrup 4 DIN 6799
142	000208263	Stirrup 7 DIN 6799
144	000292061	Washer 10.5 DIN 125 A
145	201878008	Flat washer 10.5 BN 735
146	201852111	Spring washer 10.5 DIN 137 A
147	201852112	Spring washer 6.4 DIN 137 A
148	201878006	Flat washer 6.4 BN 735
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.7
150	200958756	Travel pedal, rear
151	000406901	Pedal pad - Skoda
152	203958202	Travel pedal, front
153	202056153	Pedal pad, front
154	200958752	Travel pad weldment
155	200958755	Tie rod
156	200958760	Diagonal shaft
157	203958216	Formed link
158	200958758	Diagonal shaft
159	200058594	Pin
160	000292061	Washer 10.5 DIN 125 A
161	000282218	Cotter pin 2x18 DIN 94
162	000255530	Cotter pin 2.5x18 DIN 94
163	200058606	Spacer
164	200058618	Pin
165	000272503	Nut M8 DIN 934 Cl.8
166	204208605	Screw M8x60 DIN 933 8.8
167	000291610	Spring pin 5x22 DIN 1481
168	203126311	Spring pin 5x26 ISO 8748
169	200296000	Washer 9 DIN 126
170	000246235	Screw M8x25 DIN 933 8.8
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.8
1	200119023	Cutting system, complete
2	221010090	Hex screw M10x90 DIN 931 8.8
3	105700018	Gauge wheel
4	000281446	Self locking nut M10 DIN 985 Cl.8
5	200003081	Mower housing, complete
6	232108008	Self locking flange nut M8 DIN 6926 CI.8
7	203056136	Quill housing
9	201852083	Hex flange bolt M8x30 DIN 6921 8.8
10	505900059	Ring support
11	222008035	Hex flange bolt M8x35 DIN 6921 8.8
12	000106590	Key 6h9x6x63 DIN 6885 A
13	105800988	Blade shaft, left
14	000233453	Hex screw M10x1x35
15	204056397	Blade, left
16	204056396	Blade, right
17	000245025	Hex screw M10x1x35, left
18	505900073	Belleville washer 40x10.2x2x3.1
19	000281490	Grooved shear pin
20	202058022	Blade adaptor
21	000296076	Locking ring 25 DIN 471
22	14891	Bearing 6205 2RS P6
23	000206030	Square key 6h9x6x25 DIN 6885 A
24	105800987	Blade shaft, right
28	201852163	Washer 10.5 DIN 93
28A	215956982	SET 2 BLADE
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.9
40	000013783	Engagement lever
41	000280885	Self locking nut M8 DIN 985 CI.8
42	000320870	Spring
43	000224730	Hex nut M8 DIN 439 B CI.04
44	000201003	Spring washer 8 DIN 127 B
45	000298761	Flat washer 8.4 DIN 7349
46	000785884	Idler pulley W3500 - 3712
47	105800931	Bushing
48	105800943	Belt retainer
49	000282557	Self locking nut M12 DIN 985 CI.8
50	000078573	Flat washer
51	000903606	Drive pulley
52	000246235	Hex screw M8x25 DIN 933 8.8
53	000202114	Spring washer 10 DIN 127 B
54	204056386	Shoulder spacer
55	105800944	Idler arm
56	000221850	Hex screw M8x50 DIN 931 8.8
57	203258354	Hex screw M6x16 DIN 912 8.8
58	271030064	Flat washer 6.4 BN 737
59	105800863	Rubber washer 6.4
60	57950	Cog belt 20DS 8M 1760 Bando
61	195800954	Cog pulley assy
62	105800928	Cog pulley pin
63	000280885	Self locking nut M8 DIN 985 CI.8
64	000291500	Flat washer 8.4 DIN 125 A
65	105800945	Pulley support
66	000993663	Drive cog pulley 28
67	000267476	Hex screw M10x25 DIN 933 8.8
68	240306016	Carriage bolt M6x16 DIN 603 6.8
69	000290389	Flat washer 6.4 DIN 125 A
70	000283118	Self locking nut M6 DIN 985 CI.8
72	105800946	Flat washer
73	204958037	Blade drive plate assy
74	505900043	Cog pulley washer
75	220010045	Hex screw M10x45 DIN 933 8.8
76	105800947	Bracket idler
77	000292061	Flat washer 10.5 DIN 125 A
78	000281446	Self locking nut M10 DIN 985 CI.8
79	195800887	Cog pulley 28
80	201878011	Bearing 6203 2RS P6
81	275100040	Locking ring 40 DIN 472
82	000293172	Flat washer 13 DIN 125 A
83	105700013	Belt cover - black
84	31652	V-Belt 17x1350 B53 - Mitsuboshi
85	203056142	Drive pulley cover - black
86	203056019	Cover holder
87	203125378	Bolt M4x12 4.6 BN 354
89	000254067	Hex screw M5x16 DIN 933 8.8
90	203125377	Flat washer 5x20 BN 732
91	000285912	Self locking nut M5 DIN 985 CI.8
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.10
1	202958270	Tunnel
2	000284240	Self locking nut M4 DIN 985 CI.8
3	000072765	Support plate
4	000071082	Rubber seal
7	202359367	Hex screw M8x12 DIN 933 8.8
8	253504012	Ecofix screw M4x12 BN 4825 H 4.8
9	000262911	Head slotted screw M4x12 DIN 84 A 8.8
10	105800926	Switch cover
11	255108016	Carriage bolt M8x16 BN 11252 10.9
12	000251691	Screw M8x25 Verbus Ripp BN 2797 CI.100
13	200958653	Collector support, right
14	200958652	Collector support, left
15	200058625	Tow hitch
16	222008020	Hex screw M8x20 DIN 6921 8.8
17	200958766	Collector plate assy
18	000291500	Flat washer 8.4 DIN 125 A
19	000280885	Self locking nut M8 DIN 985 CI.8
20	200058623	Tow hitch support
21	000213312	Hex screw M8x25 DIN 6921 8.8
23	202056034	Tunnel support, left
24	202056033	Tunnel support, right
26	200058627	Protective shield bracket
27	201058222	Protective shield
28	201058237	Adjustable shield
29	201058238	Rear plate chute
31	200958656	Overload switch assy, complete
32	201058119	Overload switch actuation lever
33	201058121	Upper housing, over-load switch
34	201058120	Lower housing, over-load switch
35	200059134	Pin, over-load switch
36	240306016	Carriage bolt M6x16 DIN 603 6.8
37	000247357	Hex screw M6x12 DIN 933 8.8
38	000283118	Self locking nut M6 DIN 985 CI.8
39	000846802	Plastic wing nut 1/4-20
40	000290389	Flat washer 6.4 DIN 125 A
41	000207086	Carriage bolt M5x16 DIN 603 6.8
42	000285912	Nut M5 DIN 985 KL8
43	000244563	Hex screw M8x20 DIN 933 8.8
44	000201003	Spring washer 8 DIN 127 B
45	201115853	Reinforcing
46	203125379	Bushing KD 716
48	000284449	Hex screw M6x16 DIN 933 8.8
49	000289828	Flat washer 5.3 DIN 125 A
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.11
1	204956008	Grass collector assy
2	000254067	Hex screw M5x16 DIN 933 8.8
3	000285912	Self locking nut M5 DIN 985 Cl.8
4	105800918	Collector spring, interlock
5	201958329	Spring bracket
6	000489951	Handle grip, dump lever
7	105800952	Dumping lever
8	000975249	Front frame assy
9	200058278	Grass collector bag CZ
10	000019063	Corner support - right
11	000239448	Flat washer 5.3 DIN 9021 B
12	000272635	Hex screw M5x30 DIN 933 8.8
13	000289828	Flat washer 5.3 DIN 125 A
14	000286605	Hex screw M5x25 DIN 933 8.8
15	000060269	Corner support- left
16	000024937	Connecting brace
17	000283250	Hex screw M5x35 DIN 933 8.8
18	200958657	Bottom frame assy
19	000280885	Self locking nut M8 DIN 985 Cl.8
20	000026048	Brace
21	000246235	Hex screw M8x25 DIN 933 8.8
22	000207086	Carriage bolt M5x16 DIN 603 6.8
23	000244563	Hex screw M8x20 DIN 933 8.8
24	000201003	Spring washer 8 DIN 127 B
25	000298760	Flat washer 8.4 DIN 9021 B
26	201958328	Top frame assy
27	000978604	Lift handle
28	204056413	Collector cover RAL 2004
29	505900065	Taptite thread form screw M6x12 DIN 7500 D
30	105800862	Rubber washer 5
31	000639144	Decal arrow
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.12
1	105800940	Seat support bracket
2	000201003	Spring washer 8 DIN 127 B
3	000244563	Hex screw M8x20 DIN 933 8.8
4	222008020	Hex flange bolt M8x20 DIN 6921 8.8
5	201058223	Spacer
7	105800939	Seat support
8	240306030	Carriage bolt M6x30 DIN 603 6.8
9	000298210	Flat washer 6.4 DIN 9021 B
10	000331386	Seat spring
11	105800935	Spacer split
12	505900119	Seat quatro 400 071
13	105800938	Bracket
14	000002156	Bushing
15	000283118	Self locking nut M6 DIN 985 Cl.8
16	000290642	Spring washer 8 DIN 137 A
17	203150000	Adj. knob KRG 1A 40 M8x15
18	200958705	Chasis frame
19	000246235	Hex screw M8x25 DIN 933 8.8
20	000074690	Seat support screw
21	000291500	Flat washer 8.4 DIN 125 A
22	000280885	Self locking nut M8 DIN 985 Cl.8
23	204200001	Flat head socket screw M5x16 DIN 7991 10.9
24	000268774	Finishing washer 5.3 SN 213912
25	204056415	Fender RAL 2004
26	000292061	Flat washer 10.5 DIN 125 A
27	000281446	Self locking nut M10 DIN 985 Cl.8
28	000285912	Self locking nut M5 DIN 985 Cl.8
29	000239448	Flat washer 5.3 DIN 9021 B
30	200057102	Footrest assy - black
31	000098692	Seat spring
32	201058111	Storage box
33	000298760	Flat washer 8.4 DIN 9021 B
37	000207086	Carriage bolt M5x16 DIN 603 6.8
38	000407121	Hub cap SC 1-1/2 - black
39	105800864	Rubber washer 10.5
40	105800862	Rubber washer 5.3
41	105800870	Rubber washer 11.5
42	000289828	Flat washer 5.3 DIN 125 A
43	254505016	Flat head screw M5x16 DIN 965 A 4.8
46	205956135	Storage box door
48	204958059	Latch
49	204958060	Door bracket
50	204056349	Pin
51	204056354	Spring
52	204056353	Support plate
53	204206201	Hex screw M6x20 DIN 933 8.8
55	204041206	Screw M4x12 DIN 965 A 4.8
56	200258742	Cotter pin 1.6x12 DIN 94
57	000200090	Flat washer 4.3 DIN 125 A
58	000290389	Flat washer 6.4 DIN 125 A
59	000284240	Self locking nut M4 DIN 985 Cl.8
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.13
61	204956018	Bumper
62	204956011	Hood
68	204160001	Spring pin 6x45 ISO 8750
69	204958063	Steering wheel
70	254505016	Flat head screw M5x16 DIN 965 A 4.8
71	250004014	Head-slotted screw M4x14 DIN 84 A 4.8
72	000084414	Throttle knob - black
73	000284240	Self locking nut M4 DIN 985 Cl.8
74	000285912	Self locking nut M5 DIN 985 Cl.8
75	000770880	Throttle lever assy
76	105800812	Brace
77	203056091	Dash panel - black
81	220005020	Hex screw M5x20 DIN 933 8.8
82	000239448	Flat washer 5.3 DIN 9021 B
83	000244563	Hex screw M8x20 DIN 933 8.8
84	000298760	Flat washer 8.4 DIN 9021 B
86	105800818	Safety bar
87	105800801	Hood spring
89	195800866	Heat shield
90	000259314	Self drilling screw 4.2x13 DIN 7504 K
91	000978450	Choke - Capro
92	505900084	Hex nut 3/8 - 24
93	203300113	Hub cap GL 25x3-3.5 - black
94	201852111	Spring washer 10 DIN 137 A
95	000201003	Spring washer 8 DIN 127 B
96	205056621	Rubber purl 8 / 2
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.14
1	000820556	Battery 12V-22Ah
2	000271942	Hex nut M6 DIN 934 Cl.8
3	000284449	Hex screw M6x16 DIN 933 8.8
4	205056500	Battery clamp
5	000652388	Rubber boot
6	204958054	Battery cable (-)
8	000290389	Flat washer 6.4 DIN 125 A
9	204958056	Battery support
10	000243441	Hex screw M8x16 DIN 933 8.8
12	000323356	Cable ties RT 360
14	000059004	Wiring harness holder
15	000829191	Clip - snap in 1903-00 F/A
16	201958368	Light wiring harness CZ
18	000818323	Light bulb R 10W 12V BA15s
20	195800914	Clutch harness with diode
21	205956142	Main wiring harness HYDRO-06
22	000890670	Cap - 15455 - 4539
23	000430595	Bushing 9x1.5 KD 712
24	820002202	Bushing 18x2
25	204958053	Battery cable (+)
26	000692054	Nylon clips - adhesive 1/4 PCNY 250-9
27	000820699	Bushing 23x2 KD 5
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.15
35	505900049	Protective cover 9910
36	000877943	Switch DELTA 6440-04
38	201852333	Screw 2.9x13 DIN 7981 Z
39	204958025	Control modulus HYDRO-05
40	200058252	Holder modulus
41	201852334	Flat washer 3 DIN 125 A
47	000247357	Hex screw M6x12 DIN 933 8.8
48	000200442	Spring washer 6 DIN 127 B
49	000290389	Flat washer 6.4 DIN 125 A
50	000277816	Nut W 1/4" - 20
51	000453332	Rubber boot 16x11
52	195800916	El. starter lead (10)
53	000821117	Solenoid 94255/12V - 150A
54	203356752	Screw 4.2x13 DIN 7981 F
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.16
56	195800895	Connect cable
57	505900052	Locking rocker switch
58	200830600	Ignition switch DELTA integral with key
59	200800001	Key with moulded cover for integral switch
60	000304909	Ring 406 15/40
65	201852002	Buzzer
67	201958410	Buzzer compl.
68	205059317	Hourmeter DELTA 2014-101
LAWN TRACTOR SG-200-102H-TRACTOR-SG-200-102H-code-13895 pag.17
1	000639144	Decal arrow
3	000604945	Battery label
4	201059075	Decal B&S
5	203056086	Decal, dash panel, right
6	201058188	Decal, dash panel, left
7	204056450	Hood decal, side
8	204056451	Hood decal, front
9	000689315	Brake locking
10	000686620	Users information
11	000668041	Safety label
12	000601920	Safety label - cutting
13	000697521	Label of lifting, left
14	105800819	Label of lifting, right
15	000641179	Travel direction decal
16	200058280	By-pass decal
17	201058186	Safety decal
19	205056631	Decal, SG 200-102
23	201058253	Rear plate chute decal

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
