Ama Spare Parts for Push Lawnmower Playcut LS 46
Ama Original spare parts sourced directly from the manufacturer, with after-sales assistance at the best price on the web for to fix Push Lawnmower Playcut LS 46 - 73127.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Ama Spare Parts for Push Lawnmower Playcut LS 46
Ama Original spare parts sourced directly from the manufacturer, with after-sales assistance at the best price on the web for to fix Push Lawnmower Playcut LS 46 - 73127.
In the following table, look for the model of the Lawnmower and the respective parts of the code.
| Push Lawnmower Playcut LS 46 - 73127/Frame Pag.1 | ||
| # | Part Num. | Description |
| 1 | 84948 | Handle Sponge - Out of Stock |
| 2 | 76199 | B Type Stop Lever |
| 3 | 88585 | B Type Upper Handrail |
| 6 | 88568 | Rope Guide |
| 7 | 88565 | A Type Lower Handrail |
| 8 | 88586 | Carriage Bolt |
| 9 | 73196 | Handle Knob |
| 10 | 84822 | Cable Fixing Clamp |
| 11 | 88564 | Cap type NUT |
| 13 | 55824 | T475 Engine |
| 15 | 73801 | Rear Discharge Cover |
| 16 | 73846 | plastic grass bag |
| 17 | 84830 | Engine Brake Cable |
| 18 | 88247 | Fastener |
| 19 | 88589 | Spring Set for Rear Discharge Cover |
| 21 | 76229 | Shaft for Rear Discharge Cover |
| 22 | 88625 | Split Pin |
| 23 | 73845 | Thin Butterfly Knob |
| 27 | 76156 | Mulching Plug |
| 30 | 73201 | Height adjustment handle Ball |
| 31 | 73832 | Board for Height Adjuster |
| 35 | 88626 | Right side board |
| 36 | 88627 | Left side board |
| 37 | 88604 | Left Steel Wire Spring |
| 38 | 88605 | Right Steel Wire Spring |
| 43 | 88630 | Rear Cover Board |
| 44 | 73221 | Pull Spring for Pull Rod |
| 45 | 88596 | Front Bracket Fastener |
| 46 | 84826 | Long Key for Crankshaft |
| 47 | 76227 | Short Washer for Blade Adapter |
| 48 | 84823 | Blade Adapter |
| 49 | 84932 | 460 Blade -- SUBSTITUITED BY 73222 |
| 50 | 73223 | Blade Washer |
| 51 | 84815 | Hex Flange Face Bolt |
| 52 | 73219 | Outside Cover For Wheel Hub |
| 53 | 73217 | Nylon Bush |
| 54 | 73218 | 7" Wheel(wheel hub and tyre) |
| 55 | 73804 | Rear Drive Shaft Assy for Hand push |
| 56 | 73805 | Front Drive Shaft Assy |
| 58 | 88635 | Height Adjustment Pull Rod |
| 59 | 88636 | Rear Baffle |
| 60 | 88606 | Bush for Rear Wheels |
| 62 | 73843 | B Type Flag Grip for Stop Lever |
| Push Lawnmower Playcut LS 46 - 73127/Engine Pag.2 | ||
| 1 | RMGP65070601001 | Engine Cover |
| 2 | RMGP65070100000 | Starter-Rewind |
| 3 | RMGP65070401000 | Cover-Blover Housing |
| 4 | Nut Flywheel | |
| 5 | RMGP65070200000 | Cup-Flywheel |
| 6 | RMGP65070402000 | Fan |
| 7 | RMGP65070301000 | Flywheel |
| 9 | RMGP65070403000 | Bushing Ring |
| 11 | RMGP65070302000 | Coil-Assy-Ignition |
| 12 | RMGP65060300000 | Muffler Cover |
| 13 | RMGP65060000000 | Muffler |
| 14 | RMGP65060200000 | Gasket |
| 15 | RMGP65051000001 | Primer |
| 16 | RMGP65030200000 | Gasket |
| 17 | RMGP65030400000 | Insulator |
| 18 | RMGP65030300000 | Gasket |
| 19 | RMGP65030100003 | Carburetor Assy |
| 20 | RMGP65030500000 | Gasket |
| 21 | RMGP65040102002 | Case-Air Filter |
| 22 | RMGP65040104000 | Element-Air Filter |
| 23 | RMGP65040106000 | Pre-Filter Element |
| 24 | RMGP65040101000 | Air-Filter Cover |
| 25 | RMGP65040103000 | Exhaust Gas Cover |
| 27 | RMGP65020100000 | Cylinder Head Cover |
| 28 | RMGP65020300000 | Gasket Head Cover |
| 29 | RMGP65080204000 | Combined Nut |
| 30 | RMGP65080203000 | Adjust Nut of Valve |
| 31 | RMGP65080200000 | Rocker of Valve |
| 32 | RMGP65080900000 | Keeper Valve |
| 33 | RMGP65080800000 | Spring-Valve |
| 34 | RMGP65080202000 | Rocker Support |
| 35 | RMGP65080500000 | Guide Board |
| 36 | RMGP65020100000 | Cylinder Head Assy |
| 37 | RMGP65080700000 | Outlet Valve |
| 38 | RMGP65080600000 | Inlet Valve |
| 39 | RMGP65080400000 | Rod Push |
| 40 | RMGP65020600000 | Oil Seal |
| 41 | RMGP65081100000 | Valve Plate |
| 42 | RMGP65081000000 | Keeper Valve |
| 43 | RMGP65010401200 | Piston Ring1 |
| 44 | RMGP65010401300 | Piston Ring2 |
| 45 | RMGP65010401500 | Guide Rail |
| 46 | RMGP65010401400 | Bushing Ring |
| 47 | RMGP65010401600 | Piston-Pin |
| 48 | RMGP65010401700 | Circlip of Piston-Pin |
| 49 | RMGP65010401100 | Piston |
| 50 | RMGP65010402000 | Connecting Road Assy |
| 51 | RMGP65010301000 | Crankshaft Assy |
| 52 | RMGP65010109000 | Gasket |
| 53 | RMGP65010104000 | Valve Elemant |
| 54 | RMGP65010108000 | Filterring Net |
| 55 | RMGP65050600000 | Waste Pipe |
| 56 | RMGP65010301001 | Detent |
| 57 | RMGP65010101000 | Seal Gasket |
| 58 | RMGP65010201000 | Crankcase Cover |
| 59 | RMGP65010210000 | Oil-Seal 25x38x7 |
| 60 | RMGP65010501000 | Lubrificating Gauge |
| 61 | Seal Washer | |
| 62 | O Type Ring | |
| 64 | RMGP65010601000 | Spring Governor Link |
| 65 | RMGP65010603301 | Link-Mechanical Gov |
| 66 | RMGP65010603003 | Lever Governor Control |
| 67 | RMGP65010606004 | Spring-Governor |
| 68 | RMGP65080300000 | Tappet-Valve |
| 69 | Oil-Seal 6x11x4 | |
| 70 | RMGP65080100000 | Camshaft |
| 71 | RMGP65010205000 | Shaft Governor |
| 72 | RMGP65010105000 | Rocker Spindle |
| 73 | RMGP65010206000 | Governor Assy |
| 74 | RMGP65010202000 | Sliding Sleeve |
| 75 | RMGP70B010600000 | Speed Governor |
| 76 | RMGP65050103000 | Fuel Tank |
| 77 | RDY0019 | Fuel Tank Cap - BLACK |
| 78 | RMGP65050106000 | Sponge |
| 79 | RMGP65050102000 | Seal Gasket |
| 80 | RMGP65050500000 | Filtering Net |
| 81 | Line-Fuel | |
| 82 | RMGP65010107000 | Respirator Cover |
| 83 | RMGP65060200000 | Bracket Fuel Tank |
| 84 | RMGP65010103000 | Crankcase Assy |
