Ama Spare Parts for Brushcutter AG3 530U
€5.90
Tax included
Ama Spare Parts for Brushcutter AG3 530U
We are AMA GARDEN original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Brushcutter AG3 530U–84901.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Ama Spare Parts for Brushcutter AG3 530U
We are AMA GARDEN original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Brushcutter AG3 530U–84901.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| Brushcutter AG3 530U–84901 | ||
| Transmission Pag.1 | ||
| # | Part Num. | Description |
| 1 | 88269 | Gear Care Ass'y |
| 5 | 88289 | Pinion |
| 13 | 88288 | Safety Guard |
| 15 | 88287 | Gear Care Ass'y |
| 16 | 88286 | Gear Shaft |
| 19 | 88270 | Holder A |
| 20 | 88271 | Holder B |
| 25 | 88313 | Pipe Comb |
| 28 | 88275 | Drive Shaft |
| 30 | 88282 | Holder Ass'y |
| 35 | 88272 | Clutch Comb |
| 36 | 88273 | Clutch Drum Comb |
| 40 | 88290 | Linker |
| 41 | 38514 | Rubber Cover |
| 45 | 88284 | Clamp B |
| 46 | 88283 | Clamp A |
| 50 | 88314 | Cap lower |
| 51 | 883153 | Rubber Washer |
| 52 | 88316 | Bracket |
| 53 | 88317 | Handle |
| 55 | 88319 | Upper Bracket |
| 57 | 88318 | Handle |
| 58 | 88320 | Throttle Lever Ass'y |
| 63 | 88321 | Handgrip |
| 64 | 88322 | Spring |
| 65 | 88323 | Box,Right |
| 68 | 88325 | Cable Comp |
| 70 | 88326 | Stop Button Comp |
| 71 | 88327 | Handgrip |
| 72 | 88328 | Spring |
| 73 | 88324 | Box,Left |
| 81 | 88276 | Bracket |
| 83 | 88277 | Safety Guard |
| 88 | 88278 | Guard Ass'y |
| Starter Pag.5 | ||
| 2 | 88309 | Ratchet |
| 3 | 58919 | Starter Rope Reel |
| 5 | 64081 | Recoil Spring |
| 10 | 88310 | Spring |
| 11 | 58915 | Start Pole |
| 12 | 55039 | Starter |
| 13 | 88299 | Gasket |
| 14 | 58916 | Start Reel |
| 76 | 88297 | Stand |
| 77 | 88298 | Rubber Cover |
| Carburetor Tank Pag.4 | ||
| 78 | 58933 | Cleaner Cover |
| 79 | Fuel Pipe 3x1,5x145 | |
| 80 | Plug | |
| 81 | Fuel Pipe 2,5x1,25x80 | |
| 83 | 79361 | Fuel Tank |
| 90 | 13758 | Lid Ass'y |
| 91 | 88301 | Tank Damper |
| Carburetor Tank Pag.4 | ||
| 62 | 79356 | Gasket |
| 63 | 79357 | Admitting Pipe |
| 64 | 79358 | Carburator Gasket |
| 65 | 79359 | Carburetor |
| 66 | 13754 | Choker Handle |
| 69 | 79360 | Cleaner Inside Cover |
| 71 | 88311 | Choke Lever |
| 73 | 55670 | Air Filter Set cpl. |
| 74 | 79339 | Cleaner Outside Cover |
| 75 | 55134 | Screw |
| Flywheel Muffler Pag.3 | ||
| 26 | 79343 | Magneto Rotor Comp |
| 29 | Nut M8x1 | |
| 30 | 79344 | Ignition Coil Comp |
| 33 | 76284 | WasherB |
| 34 | 79345 | Spring |
| 35 | 79346 | Expander |
| 37 | 13733 | Screw Pin |
| 38 | 88312 | Fan Cover |
| 56 | 79354 | Gasket |
| 57 | 79355 | Muffler |
| 94 | 79362 | Cover |
| Engine Pag.2 | ||
| 16 | 88422 | Crank Case |
| 17 | 88423 | Gasket |
| 18 | Bearing 6202/P6 | |
| 19 | 88424 | Crank Shaft |
| 20 | 88264 | Key 3x5x13 |
| 22 | 88425 | Crank Case |
| 41 | 79347 | Bearing |
| 42 | 79348 | Ring |
| 43 | 88432 | Piston |
| 44 | 88426 | Piston Pin |
| 45 | 88431 | Piston Ring |
| 46 | 88430 | Gasket |
| 47 | 88429 | Cylinder |
| 49 | 79352 | Guide Cover Ass'y |
| 50 | 10660 | Spark Plug |
| 53 | 38421 | Plug Cap |
| 54 | 88427 | Sleeve |
| 55 | 79353 | Spark Plug Cap |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
