Alpina Spare Parts for Brushcutter ABR 52 D
STIGA-ALPINA-CASTOR-CASTELGARDEN-Mountfield authorized repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance for Brushcutter ALPINA ALPINA ABR 52 D (2020) 287421004/A20.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter ABR 52 D
STIGA-ALPINA-CASTOR-CASTELGARDEN-Mountfield authorized repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter ALPINA ALPINA ABR 52 D (2020) 287421004/A20.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA ABR 52 D (2020) 287421004/A20 | ||
| Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118804038/0 | Screw |
| 2 | 118804045/0 | Washer |
| 3 | 118804000/0 | Clutch Assy |
| 4 | 112789008/0 | Screw |
| 5 | 118804033/0 | Flywheel cover |
| 6 | 118804046/0 | Washer |
| 7 | 112293200/0 | Nut |
| 8 | 112369500/0 | Elastic Disc |
| 9 | 112521350/0 | Washer |
| 10 | 118804013/0 | Flywheel Magnet |
| 11 | 2135130 | Screw |
| 12 | 118804025/0 | Engine Crankcase, Clutch Side |
| 13 | 118803990/0 | Motor shaft |
| 14 | 118804079/0 | Engine Crankcase Gasket |
| 15 | 118804027/0 | Engine Crankcase, Starter Side |
| 16 | 118804019/0 | Roller Cage |
| 17 | 118804036/0 | Piston 51.7CC |
| 18 | 118804040/0 | Piston Pin |
| 19 | 118804049/0 | Circlip |
| 20 | 118804023/0 | Piston Ring |
| 21 | 118804080/0 | Cylinder Gasket |
| 22 | 118804035/0 | Cylinder 51.7CC |
| 23 | 118804085/0 | Muffler Gasket |
| 24 | 118803992/0 | Muffler |
| 25 | 118804048/0 | Silencer Guard |
| 26 | 2135180 | Screw |
| 27 | 112521330/0 | Washer |
| 28 | 112582100/0 | Grower |
| 29 | 118801180/0 | Screw |
| 30 | 118804081/0 | Gasket |
| 31 | 118804064/0 | Intake Manifold |
| 32 | 6981102 | Supplied with screws |
| 33 | 118804083/0 | Carburettor gasket |
| 34 | 118804009/0 | Carburettor |
| 35 | 118804063/0 | Air Cleaner Base |
| 36 | 112521320/0 | Washer |
| 37 | 112581500/0 | Grower |
| 38 | 2135250 | Screw |
| 39 | 118804074/0 | Air Filter Sponge Element |
| 39 | 118804547/0 | Air Filter B |
| 40 | 118805295/0 | Black filter cover |
| 41 | 118803174/0 | Knob, Grey |
| 42 | 118803996/0 | Starter cup |
| 43 | 118804051/0 | Gasket |
| 44 | 118803994/0 | Starter assembly |
| 45 | 112727356/0 | Screw |
| 46 | 3210024 | Candle |
| 47 | 118805296/0 | Black cylinder cover |
| 48 | 112727796/0 | Screw |
| 50 | 118801188/0 | Oil Seal |
| 51 | 3112040 | Ball bearing |
| 52 | 118804020/0 | Oil Seal |
| 53 | 123072002/0 | Flywheel tab |
| 54 | 118804864/0 | Electronic Coil Assembly |
| 56 | 2135110 | Screw |
| 57 | 118804055/0 | Cable hook |
| 58 | 112760475/0 | Screw |
| 59 | 118804004/0 | Fuel Tank Assy |
| 60 | 118803962/0 | Support |
| 61 | 118804087/0 | Air Conveyor |
| 62 | 112727815/0 | Screw |
| 63 | 112727790/0 | Screw |
| 64 | 112523020/0 | Washer |
| 65 | 118803975/0 | Starter cam |
| 66 | 118804061/0 | Starter spring |
| 67 | 118803976/0 | Starter pulley |
| 68 | 118804060/0 | Starter Spring |
| 69 | 118804069/0 | Starter Plate Yellow |
| 70 | 118803984/0 | Starter handle |
| 71 | 118804068/0 | Cable guide |
| 72 | 118803163/0 | Spark Plug Cap |
| 73 | 322735152/0 | Tank cap |
| 74 | 118804005/0 | Fuel Hose |
| 75 | 118803181/0 | Starter rope |
| 76 | 118805308/0 | Thermal insulating label |
| ALPINA ABR 52 D (2020) 287421004/A20 | ||
| Transmission Pag.2 | ||
| 1 | 118804002/0 | Support Transmission Assy |
| 2 | 118803958/0 | Transmission Pipe |
| 3 | 6981145 | Screw |
| 4 | 112727799/0 | Screw |
| 5 | 112727801/0 | Screw |
| 7 | 112760475/0 | Screw |
| 8 | 112291000/0 | Nut |
| 9 | 118803987/0 | Handle support |
| 10 | 112727801/0 | Screw |
| 11 | 118803210/0 | Left handle |
| 13 | 2135120 | Screw |
| 14 | 112154330/0 | Nut |
| 15 | 118804042/0 | Drive shaft |
| 16 | 118803999/0 | Gear Case Assy |
| 17 | 118804052/0 | plate |
| 18 | 118804054/1 | Plastic Protection Guard Plate |
| 19 | 2132180 | Screw |
| 20 | 118801125/0 | 3 Teeth Disc |
| 22 | 1911-9227-01 | Nylon Head Bump-N-Work Ø 109mm 1911-9226-01 (was 118810717/0) |
| 23 | 118804015/1 | Harness |
| 24 | 118804066/0 | Cable hook |
| 25 | 118804037/0 | Clutch Drum |
| 26 | 118804065/0 | Harness support |
| 27 | 118804062/0 | Knob |
| 28 | 118804072/0 | Upper Handgrip Support |
| 29 | 118804075/0 | Lower Handgrip Support |
| 30 | 118803971/0 | Left Handle Yellow |
| 31 | 118803965/0 | Right Handle Yellow |
| 32 | 118803221/0 | Throttle Lever |
| 33 | 118803219/0 | Safety Lever |
| 34 | 118803213/0 | Switch |
| 35 | 118803220/0 | Spring |
| 36 | 112727810/0 | Screw |
| 37 | 118803986/0 | Throttle Cable |
| 38 | 118803217/0 | Stop Wire |
| 39 | 2452090 | Nut |
| 40 | 118804050/0 | Case Dust Cover |
| 41 | 118804043/0 | Upper Ring Nut |
| 42 | 118804044/0 | Lower Ring |
| 44 | 118804058/0 | Protection |
| 45 | 112727815/0 | Screw |
| 46 | 118803202/0 | Support |
| 47 | 118804056/0 | Wire cutter plate |
| 48 | 6981149 | Screw |
| 49 | 112728531/0 | Screw |
| 50 | 118804890/0 | line retainer |
| 51 | 118804889/0 | Spring |
| 52 | 118804888/0 | Lid + Knob |
| 55 | 118805298/0 | Handle Assy, Grey |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Alpina ABR52D 287421004/A20
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
