Alpina Parts for Lawnmower PRO 50 ASK 2011 - 295506428/PRO
€352.05
Tax included
Alpina Parts for Lawnmower PRO 50 ASK 2011 - 295506428/PRO
Alpina Genuine spare parts or replacement parts for to repair Self-Propelled Petrol Lawnmower PRO 50 ASK (2011) - 295506428/PRO.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Parts for Lawnmower PRO 50 ASK 2011 - 295506428/PRO
Alpina Genuine spare parts or replacement parts for to repair Self-Propelled Petrol Lawnmower PRO 50 ASK (2011) - 295506428/PRO.
In the following table, look for the model of the Lawn Mower and the respective parts of the code.
| Self-Propelled Petrol Lawnmower PRO 50 ASK (2011) - 295506428/PRO pag.1 | ||
| # | Part Num. | Description |
| 1 | 381003500/0 | Deck Red To 31-August-2013 |
| 1 | 381004743/0 | Deck Gray From 01-September-2013 To 31-August-2014 |
| 1 | 381004743/1 | Deck Gray From 01-September-2014 |
| 5 | 112728522/0 | Screw |
| 6 | 322060221/0 | Belt Protection |
| 7 | 112731350/0 | Screw |
| 8 | 112523040/0 | Washer |
| 9 | 122034000/0 | Water washing connection |
| 10 | 119035000/0 | O-Ring |
| 11 | 112728520/0 | Screw |
| 12 | 122060146/0 | Deck, Adjustment |
| 13 | 122546070/0 | plate |
| 14 | 322601003/0 | Protection |
| 15 | 112155000/0 | Nut |
| 17 | 322778397/1 | Left bracket |
| 20 | 322778396/1 | Right bracket |
| 21 | 322601002/1 | Right Protection |
| 22 | 112155000/0 | Nut |
| 23 | 112793301/0 | Screw |
| 24 | 122595352/0 | Inspection Door |
| 25 | 112731350/0 | Screw |
| 26 | 322108205/0 | Conveyor To 31-August-2014 |
| 26 | 322108205/1 | Conveyor From 01-September-2014 |
| 27 | 112789000/0 | Screw |
| 28 | 112523020/0 | Washer |
| 29 | 112154330/0 | Nut |
| 30 | 112731350/0 | Screw |
| 31 | 322545147/0 | plate |
| 33 | 322038407/0 | Brass |
| 34 | 112731350/0 | Screw |
| 35 | 322545156/0 | plate |
| 36 | 122038400/1 | Brass |
| 51 | 381002801/1 | Axle Front Wheel To 31-August-2011 |
| 51 | 381002865/1 | Axle Front WheelFrom 01-September-2011 To 31-August-2012 |
| 51 | 381302865/0 | Axle Front Wheel From 01-September-2013 |
| 58 | 381001137/0 | Rod, Height Adjustment To 31-August-2011 |
| 58 | 381002039/1 | Rod, Height Adjustment From 01-September-2011 |
| 59 | 112000930/0 | Benzing ring |
| 60 | 112000930/0 | Benzing ring |
| 61 | 122446187/0 | Spring |
| 62 | 112436050/1 | Plate To 31-August-2009 |
| 62 | 112436051/0 | Plate From 01-September-2009 |
| 63 | 122446176/0 | Spring To 31-August-2010 |
| 63 | 122446176/1 | Spring From 01-September-2010 |
| 64 | 122517880/1 | Pin |
| 65 | 322672152/0 | Anti-friction washer |
| 66 | 322322829/1 | Lever, Height Adjustment |
| 67 | 122602000/0 | Pushbutton, Lever |
| 68 | 322672151/0 | Anti-friction washer |
| 69 | 322785115/0 | Support, Height |
| 70 | 112155000/0 | Nut |
| 71 | 112729600/0 | Screw |
| 72 | 112793101/0 | Screw To 31-August-2013 |
| 72 | 112793102/0 | Screw From 01-September-2013 |
| 73 | 112293201/0 | Nut |
| 74 | 112154510/0 | Nut |
| 75 | 122519746/0 | Pin |
| 171 | 322140224/0 | Mulching To deflector 31-August-2013 |
| 171 | 322140224/1 | Mulching deflector From 01-September-2013 |
| Self-Propelled Petrol Lawnmower PRO 50 ASK pag.2 | ||
| 1 | 381006861/0 | Handle, Upper Part Black |
| 2 | 112819121/0 | Screw |
| 3 | 122680006/1 | Washer |
| 4 | 122399803/0 | Knob |
| 5 | 112293200/0 | Nut |
| 6 | 122430309/0 | Spring |
| 7 | 112154330/0 | Nut |
| 8 | 181000757/0 | Motor Brake Cable B&S 625/675 Series |
| 9 | 181003291/2 | Motor Brake Lever To 31-August-2006 |
| 9 | 181003291/3 | Motor Brake Lever From 01-September-2006 |
| 10 | 122041966/0 | Bush |
| 13 | 122291050/0 | Handgrip Black |
| 14 | 181003288/1 | Lever, Driving |
| 15 | 122041965/0 | Bush To 31-August-2004 |
| 15 | 322041965/1 | Bush From 01-September-2004 |
| 16 | 381008610/0 | Outfit, Screws To 31-August-2010 |
| 16 | 381008610/1 | Outfit, Screws from 01-September-2010 |
| 21 | 481007160/0 | Cable, Trottle with/ Universal sheath |
| 22 | 381007280/2 | Lever, Throttle Honda Engine / B&S 625-675-700 Series / GGP 140-160-196cc dashboard |
| 23 | 112735105/0 | Screw |
| 24 | 322981467/0 | plate |
| 25 | 112791500/0 | Screw |
| 26 | 112530060/0 | Elastic Washer |
| 27 | 112523040/0 | Washer |
| 28 | 112523040/0 | Washer |
| 29 | 112154510/0 | Nut |
| 30 | 422120158/0 | Dash Board Black |
| 31 | 114356744/0 | Throttle label B&S 675 Series To 31-August-2007 |
| 31 | 114356744/1 | Throttle label B&S 675 Series From 01-September-2007 |
| 32 | 122943006/0 | Screw |
| 33 | 112728460/0 | Screw |
| 35 | 381008609/0 | Outfit, Dash-Board Screws |
| 36 | 381000669/0 | Cable, Rear Drive (General Transmission) |
| 36 | 381000673/0 | Cable, Rear Drive (Bi. Ci. Di.) |
| Self-Propelled Petrol Lawnmower PRO 50 ASK pag.3 | ||
| 1 | 112608600/0 | Snap Ring |
| 2 | 122570120/1 | Pinion Left |
| 3 | 122120105/1 | Corona To 31-August-2016 |
| 3 | 122120105/2 | Ring Gear From 01-September-2016 |
| 4 | 322600091/1 | Protection Wheel To 31-August-2012 |
| 4 | 322600268/0 | Protection Wheel From 01-September-2012 |
| 5 | 122570110/1 | Pinion Right |
| 6 | 112608600/0 | Snap Ring |
| 7 | 119216035/0 | Bearing |
| 8 | 381002811/0 | Axle Rear Wheel To 31-August-2012 |
| 8 | 381302867/0 | Axle Rear Wheel From 01-September-2012 |
| 9 | 122753000/0 | Plug |
| 10 | 181003070/0 | Gear Box General Transmission Group To 31-August-2001 |
| 10 | 181003074/1 | Gear Box (Bi. Ci. Di.) From 01-September-2002 To 31-August-2003 |
| 10 | 181003074/2 | Gear Box Bi.Ci.Di (Bi. Ci. Di.) From 01-September-2003 To 31-August-2004 |
| 10 | 181003079/0 | Gear Box (Black) (General Transmission) To 31-August-2011 |
| 10 | 181003079/1 | Gear Box (Black) (General Transmission) From 01-September-2011 |
| 10 | 181003082/0 | Gear Box Bi.Ci.Di (Gray) (Bi. Ci. Di.) From 01-September-2004 To 31-August-2005 |
| 10 | 181003082/1 | Gear Box Bi.Ci.Di (Gray) (Bi. Ci. Di.) From 01-September-2005 |
| 11 | 122601904/0 | Pulley To 31-August-2005 |
| 11 | 122601909/0 | Pulley From 01-September-2005 |
| 12 | 112645705/0 | Pin ø5X32 |
| 13 | 122033281/0 | Adjustment Rod From 01-September-2004 |
| 13 | 122033284/0 | Adjustment Rod To 31-August-2004 |
| 14 | 122041957/0 | Bush To 31-August-2001 |
| 14 | 122041957/1 | Bush From 01-September-2001 |
| 15 | 122450063/0 | Spring |
| 16 | 322680009/0 | Washer |
| 17 | 112154510/0 | Nut |
| 18 | 122110230/0 | Hubcap |
| 19 | 135064150/0 | Belt |
| Self-Propelled Petrol Lawnmower PRO 50 ASK pag.4 | ||
| 1 | 481007317/0 | Wheel |
| 2 | 322110416/0 | Hubcap Gray |
| 3 | 122122200/0 | Bearing |
| 4 | 481007318/1 | Wheel |
| 5 | 322110417/0 | Hubcap Gray |
| 6 | 112521350/0 | Washer |
| 7 | 112155000/0 | Nut |
| 8 | 112530150/0 | Spring washer 31-August-2011 |
| 8 | 122675100/0 | Washer From 01-September-2011 |
| Self-Propelled Petrol Lawnmower PRO 50 ASK pag.5 | ||
| 1 | 122465607/1 | Hub With Pulley, Crankshaft Ø 22.2To 31-August-2007 |
| 1 | 122465607/2 | Hub With Pulley, Crankshaft Ø 22.2 From 01-September-2007 To 31-August-2010 |
| 1 | 122465607/3 | Hub With Pulley, Crankshaft Ø 22.2 From 01-September-2010 To 31-December-2018 |
| 1 | 122465607/4 | Hub With Pulley, Crankshaft Ø 22.2 From 01-January-2019 |
| 2 | 181004366/2 | Blade |
| 3 | 122160400/0 | Elastic Washer |
| 4 | 112523080/0 | Washer |
| 5 | 112735698/0 | Screw |
| 6 | 112139100/0 | Key |
| 7 | 112691900/0 | Screw |
| 8 | 112155000/0 | Nut |
| 9 | 112521350/0 | Washer |
| Self-Propelled Petrol Lawnmower PRO 50 ASK pag.6 | ||
| 1 | 381008050/0 | Stone Guard Black 26-January-2020 |
| 1 | 381008050/1 | Stone Guard Black From 27-Januray-2020 |
| 2 | 122451000/0 | Spring |
| 3 | 122517856/1 | Deflector Rod |
| 6 | 322486102/0 | Grass-Box, Upper Part |
| 7 | 122608526/0 | Grass-Box, Lower Stiffening ATo 26-January-2020 |
| 7 | 122608526/1 | Stiffening Lower From 27-Januray-2020 |
| 8 | 181002212/0 | Grass-Bag Canvas Black without Logo |
| 9 | 112728680/0 | Screw |
| 10 | 112523050/0 | Washer |
