Alpina Spare Parts for Brushcutter B 28
€2.19
Tax included
Alpina Spare Parts for Brushcutter B 28
Alpina original replacement parts for to replace broken parts for to fix Brushcutter B 28/280120000/12-2015.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter B 28
Alpina original replacement parts for to replace broken parts for to fix Brushcutter B 28/280120000/12-2015.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA Brushcutter B 28/280120000/12-2015 Pag.1 | ||
|
Casing
|
||
|
#
|
Part Num.
|
Description
|
|
1
|
112789000/0
|
Screw
|
|
3
|
118801241/0
|
Hub
|
|
5
|
118801240/0
|
Starter Pulley
|
|
6
|
118801225/0 | Starting rope |
|
7
|
118801242/0
|
Spring
|
|
10
|
118801238/0
|
Starting handle
|
|
11
|
118801239/0
|
Fermo
|
|
12
|
118801237/0 | Black Starter Cpl |
|
13
|
2132450
|
Screw
|
|
14
|
118801226/0 | Starter Cup Assy |
|
18
|
||
|
19
|
123685024/0
|
Engine Cover, Starter Side
|
|
20
|
123280046/0
|
Crankcase Gasket
|
|
21
|
114215218/0
|
Ball bearing
|
|
22
|
123020024/0 | Crankshaft |
|
23
|
123072002/0 | Woodruff |
|
25
|
123685025/0
|
Engine Cover, Clutch Side
|
|
26
|
2135060
|
Screw
|
|
27
|
123880010/0
|
Flywheel
|
|
30
|
112154200/0
|
Nut
|
|
31
|
118801231/0 | Electronic Ignition Coil |
|
33
|
2135030 | Screw |
|
35
|
123430582/0 | Spring |
|
36
|
123400002/0 | Clutch unit |
|
38
|
123878057/0
|
Screw
|
|
51
|
123235006/0
|
Needle Bearing
|
|
52
|
123202005/0
|
Circlip
|
|
53
|
123760005/0
|
Piston pin
|
|
54
|
123590007/0 | Piston |
|
55
|
123204009/0 | Piston Ring |
|
56
|
123280044/0
|
Cylinder Gasket
|
|
57
|
123071013/0
|
Ass. Cylinder
|
|
58
|
112760475/0
|
Screw
|
|
59
|
3210024
|
Spark Plug
|
|
61
|
118801232/0
|
Spark Plug Cap
|
|
62
|
123275023/0
|
Grommet
|
|
63
|
118801233/0
|
White Cylinder Cap
|
|
64
|
118801245/0
|
White Cover
|
|
65
|
118801255/0
|
Gasket
|
|
66
|
112760475/0
|
Screw
|
|
67
|
123280040/0
|
Cylinder Manifold Gasket
|
|
68
|
123073508/0
|
Intake manifold
|
|
69
|
2135060
|
Screw
|
|
70
|
118801227/0 | Carburetor-Manifold Gasket |
|
71
|
123054025/0
|
Carburetor
|
|
72
|
118801229/0
|
Lever
|
|
73
|
118801228/0 | Cleaner Inside Cover |
|
74
|
123190000/0
|
Air Lever
|
|
76
|
2132160
|
Screw
|
|
77
|
||
|
78
|
118801230/0
|
White filter cover
|
|
79
|
118801320/0
|
Gasket
|
|
80
|
118801247/0
|
Muffler gasket
|
|
82
|
183740021/0
|
Muffler
|
|
83
|
118801248/0
|
Muffler protection
|
|
86
|
6981104
|
Screw
|
|
87
|
123280060/0 | Gasket |
|
88
|
112788910/0
|
Screw
|
|
89
|
118801244/0
|
Fuel Tank
|
|
90
|
118801246/0
|
Lower Protection
|
|
91
|
2135030 | Screw |
|
92
|
2135200
|
Screw
|
|
93
|
118801319/0 | Pipe |
|
94
|
118801318/0 | Rubber grommets |
|
95
|
118801313/0 | Fuel Tube |
|
96
|
183520005/0 | Fuel Filter |
|
97
|
118801243/0 | Cap |
|
Handle-Trasmission Pag.2
|
||
|
1
|
123050011/0 | Clutch Drum |
|
2
|
112727815/0
|
Screw
|
|
3
|
118801235/0
|
Protection
|
|
6
|
112609200/0
|
Seeger
|
|
7
|
118801234/0 | White Clutch Cover |
|
8
|
2135131
|
Screw
|
|
9
|
118801236/0
|
Button
|
|
10
|
||
|
12
|
||
|
13
|
||
|
14
|
112788910/0
|
Screw
|
|
15
|
2135060
|
Screw
|
|
21
|
183869073/0 | Transmission Tube And Flex Shaft Assy |
|
22
|
123020038/0 | Drive Shaft |
|
31
|
118801337/0
|
Bracket
|
|
32
|
112789000/0
|
Screw
|
|
33
|
118801335/0
|
Safety Lever, Red
|
|
34
|
118801336/0
|
Throttle Lever, Red
|
|
35
|
118801334/0
|
Spring
|
|
36
|
118801332/0
|
Right Handle, White
|
|
37
|
112735105/0
|
Screw
|
|
38
|
118801354/0
|
Throttle Cable
|
|
40
|
118801333/0
|
Spring
|
|
41
|
118801329/0
|
Red knob
|
|
43
|
118801330/0
|
Stop Plate
|
|
44
|
118801338/0
|
Spring
|
|
45
|
118801328/0
|
Stop Cable
|
|
46
|
118801331/0
|
Left Handle, White
|
|
50
|
118801322/0
|
Stop Cable Adapter
|
|
51
|
183780002/0
|
Harness support
|
|
52
|
123170004/0
|
Spacer
|
|
55
|
118801339/0
|
Front Handgrip White
|
|
56
|
118801340/0
|
Lower Support
|
|
57
|
2135040 | Screw |
|
71
|
118801327/0
|
Harness
|
|
Gear Case Pag.3
|
||
|
1
|
183820507/0
|
Gear Case
|
|
6
|
112727801/0 | Screw |
|
7
|
112789000/0
|
Screw
|
|
8
|
112727794/0
|
Screw
|
|
10
|
123670002/0
|
Protection
|
|
15
|
123250002/0 | Upper ring |
|
16
|
123250003/0 | Lower ring |
|
18
|
123120015/0
|
Nut
|
|
21
|
123784012/0 | Support |
|
22
|
2135050 | Screw |
|
23
|
2135180
|
Screw
|
|
24
|
118801341/0 | Stone Guard Black |
|
25
|
112735654/0
|
Screw
|
|
26
|
||
|
27
|
112728099/1
|
Screw
|
|
28
|
123311013/0 | Blade |
|
31
|
123155009/0 | 2 Hedges Nylon Head |
|
32
|
123155010/0
|
Disc 3 Tips
|
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Alpina B28 280120000/12-2015
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
