Alpina Spare Parts for Chain Saw AC 52 240521800/A17 - 2017
€1.53
Tax included
Alpina Spare Parts for Chain Saw AC 52 240521800/A17 - 2017
STIGA-ALPINA-CASTOR-CASTELGARDEN authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Chain Saw AC 52 240521800/A17 - Season 2017.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Chain Saw AC 52 240521800/A17 - 2017
STIGA-ALPINA-CASTOR-CASTELGARDEN authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Chain Saw AC 52 240521800/A17 - Season 2017.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| ALPINA AC 52 240521800/A17 - Season 2017 pag.1 | ||
| # | Part Num. | Description |
| 3 | 118804618/0 | Heat Insulator Gasket |
| 4 | 118804320/0 | Muffler To 31-august-2017 |
| 4 | 118804919/0 | Muffler From 01-september-2017 |
| 5 | 2132550 | Screw |
| 6 | 2135040 | Screw |
| 7 | 118804294/0 | Muffler Cover To 31-august-2017 |
| 7 | 118804920/0 | Muffler Cover From 01-september-2017 |
| 8 | 2135040 | Screw |
| 9 | 2132550 | Screw |
| 10 | 3210024 | Spark Plug |
| 11 | 118804283/0 | Nozzle |
| 12 | 118804249/0 | Piston Ring |
| 14 | 118804255/0 | Circlip |
| 15 | 118804244/0 | Needle Bearing Gasket |
| 16 | 118804412/0 | Needle bearing |
| 17 | 118804223/0 | Piston Pin |
| 18 | 118804619/0 | Cylinder Gasket |
| 19 | 118800959/0 | Key |
| 20 | 118804393/0 | Crankshaft |
| 34 | 118804620/0 | Crankcase Gasket |
| 99 | 118804531/0 | Decompression Valve |
| 100 | 118804248/0 | Cylinder - Piston Assy |
| 101 | 118804247/0 | Piston Assy |
| 102 | 118804253/0 | Gaskets Assy |
| ALPINA AC 52 240521800/A17 - Season 2017 pag.2 | ||
| 5 | 2132550 | Screw |
| 6 | 2135040 | Screw |
| 9 | 2132550 | Screw |
| 21 | 118804388/0 | Ignition Assy |
| 22 | 118804369/0 | Washer |
| 23 | 118804368/0 | Switch |
| 24 | 118804360/0 | Ground Cable |
| 25 | 123120004/0 | Nut |
| 26 | 118804356/0 | Flywheel |
| 27 | 118804350/0 | Oil Seal |
| 31 | 118804341/0 | Heat Insulator Gasket |
| 32 | 118804334/0 | Left Crankcase |
| 33 | 118801158/0 | Pin |
| 35 | 118800059/0 | Bearing |
| 36 | 118804324/0 | Bearing |
| 37 | 118804319/0 | Oil Seal |
| 38 | 118804309/0 | Shock Absorber |
| 40 | 118804587/0 | Nozzle |
| 44 | 118804302/0 | Chain Guard |
| 45 | 2132180 | Screw |
| 46 | 118801158/0 | Pin |
| 47 | 118804301/0 | Oil Pump Cover |
| 48 | 2135020 | Screw |
| 52 | 118804300/0 | Oil Pump |
| 53 | 118804299/0 | Oil Spray Nozzle |
| 54 | 2135180 | Screw |
| 55 | 118804298/0 | Spike |
| 56 | 118804297/0 | Worm |
| 57 | 118804296/0 | Washer |
| 58 | 118804295/0 | Clutch Assy |
| 59 | 118804293/0 | Washer |
| 60 | 118804292/0 | Clutch Drum |
| 61 | 118804291/0 | Sprocket |
| 62 | 118550591/0 | Needle Bearing |
| 63 | 118804290/0 | Anti-Friction Washer |
| 64 | 112000955/0 | Benzing Ring |
| 65 | 118804410/0 | O-Ring |
| 66 | 118804289/0 | Tensioner Screw |
| 67 | 118804288/0 | Chain Tensioner |
| 68 | 118804287/0 | Gear Cover |
| 69 | 118804286/0 | Chain Tightener Block |
| 70 | 118804285/0 | Plate |
| 71 | 118804284/0 | Bolt To 31-august-2017 |
| 71 | 118804284/1 | Bolt From 01-septembger-2017 |
| 95 | 118804522/0 | Spark Plug Cover Assy |
| 96 | 118804523/0 | Starter Pawl Assy new code 118804356/0 |
| 103 | 118804252/0 | Oil Tank Cap Assy |
| 104 | 118804251/0 | Right Crankcase Assy |
| 105 | 118804250/0 | Pickup Oil Assy |
| ALPINA AC 52 240521800/A17 - Season 2017 pag.3 | ||
| 6 | 2135040 | Screw |
| 46 | 118804926/0 | Air Filter Assy |
| 72 | 118804282/0 | Knob |
| 73 | 118804281/0 | Air Filter Lock |
| 74 | 118804280/0 | Air Filter |
| 75 | 118804279/0 | Shock Absorber |
| 76 | 323315115/0 | Choke Knob |
| 77 | 118804278/0 | Choke Bushing |
| 78 | 118804277/0 | Carburetor To 31-august-2017 |
| 78 | 118804927/0 | Carburatore From 01-september-2017 |
| 79 | 118804276/0 | Vacumm Tube |
| 80 | 118804275/0 | Copper Tube |
| 81 | 112728519/0 | Screw To 31-august-2017 |
| 81 | 112731601/0 | Screw From 01-september-2017 |
| 82 | 323784017/0 | Carburettor Support |
| 83 | 118804274/0 | Pressure Tube |
| 84 | 118804273/0 | Gasket |
| 85 | 118804271/0 | Air Intake Manifold |
| 86 | 118804264/0 | Spring Ring |
| 87 | 2135250 | Screw |
| 88 | 118804263/0 | Air Filter Base |
| 89 | 118804262/0 | Throttle Cable |
| 90 | 118804261/0 | Cable Reel |
| 91 | 118804260/0 | Guide |
| 92 | 118804259/0 | Carter |
| 93 | 118804258/0 | Grommet |
| 94 | 118804257/0 | Bushing |
| 97 | 118804526/0 | Carburetor Repair Kit |
| 98 | 118804527/0 | Carburetor Gasket Kit |
| ALPINA AC 52 240521800/A17 - Season 2017 pag.4 | ||
| 1 | 118804563/0 | Starter Assy To S/N 610CD101272 (For SP466) To S/N 610CE101564 (For SP526) |
| 1 | 118804563/1 | Starter Assy From S/N 707CE101985 (For SP526) New for SP466 |
| 2 | 118804559/0 | Starter Handle |
| 3 | 2132550 | Screw |
| 8 | 118804243/0 | Starter Pulley |
| 9 | 112521330/0 | Washer |
| 10 | 112728519/0 | Screw To 31-august-2017 |
| 10 | 112731601/0 | Screw From 01-september-2017 |
| 11 | 118804242/0 | Air Guide |
| 14 | 118804406/0 | Dowel Pin |
| 38 | 112728523/0 | Screw |
| 46 | 118804216/0 | Hook |
| 47 | 118804215/0 | Lever |
| 48 | 118804214/0 | Flange |
| 50 | 323059043/0 | Cylinder Cover |
| 51 | 118804392/0 | Flange |
| 52 | 118804391/0 | Heat shield |
| 53 | 118804390/0 | Air Conveyor |
| 54 | 118804389/0 | Shock Absorber |
| 75 | 118804385/0 | Starter Spring Assy |
| 78 | 118804566/0 | Air Filter Cover Assy |
| ALPINA AC 52 240521800/A17 - Season 2017 pag.5 | ||
| 3 | 2132550 | Screw |
| 10 | 112728519/0 | Screw To 31-august-2017 |
| 10 | 112731601/0 | Screw From 01-september-2017 |
| 12 | 118804565/0 | Handle Cover |
| 13 | 118804240/0 | Safety Lever |
| 14 | 118804406/0 | Dowel Pin |
| 15 | 118804239/0 | Spring |
| 16 | 118804238/0 | Bracket |
| 17 | 118804237/0 | Bracket |
| 18 | 118804236/0 | Spring |
| 19 | 118804235/0 | Fuel Tube Assy |
| 20 | 118804234/0 | Clip |
| 21 | 118804233/0 | Fuel Filter To 31-august-2017 |
| 21 | 118804885/0 | Fuel Filter From 01-september-2017 |
| 22 | 118804232/0 | Pipe |
| 23 | 118804231/0 | Primer |
| 24 | 118804230/0 | Fuel Pipe |
| 25 | 118804229/0 | Grommet |
| 29 | 118804228/0 | Valve Valve cap |
| 30 | 118804227/0 | Vent valve |
| 31 | 2132180 | Screw |
| 32 | 118804226/0 | Shock Absorber |
| 33 | 118804225/0 | Spring |
| 34 | 118804411/0 | Screw To 31-august-2017 |
| 34 | 118804411/1 | Screw From 01-september-2017 |
| 35 | 118804224/0 | Shock Absorber |
| 37 | 323059046/0 | Plate |
| 38 | 112728523/0 | Screw |
| 40 | 118804222/0 | Spring |
| 41 | 118804221/0 | Spark Plug Wrench |
| 42 | 118804220/0 | Throttle Lever |
| 43 | 118804219/0 | Shock Absorber |
| 44 | 118804218/0 | Spring |
| 45 | 118804383/0 | Front Handle |
| 76 | 118804307/0 | Tank Cap Assy |
| 77 | 118804270/0 | Rear Handle Assy |
| 80 | 118804881/0 | Spring |
| ALPINA AC 52 240521800/A17 - Season 2017 pag.6 | ||
| 3 | 2132550 | Screw |
| 55 | 323455014/0 | Hand Guard |
| 56 | 118804318/0 | Bushing |
| 57 | 118804315/0 | Return Spring Fixture |
| 58 | 118804316/0 | Spring |
| 59 | 118804317/0 | Return Spring Guard |
| 60 | 118804313/0 | Chain Brake Lever |
| 61 | 118804407/0 | Retaining Ring |
| 62 | 118804314/0 | Brake Band |
| 63 | 123753000/0 | Needle |
| 64 | 118804312/0 | Spring |
| 65 | 118804387/0 | Gasket |
| 66 | 118804386/0 | Brake Spring Cover |
| 67 | 9860-0520-16 | Screw |
| 69 | 118804303/0 | Screw |
| 70 | 118800130/0 | Guide Bar 18"-.325"-0,058" |
| 71 | 118801748/0 | Chain 18"-.325"-0,058"-72X |
| 79 | 118804567/0 | Clutch Cover Assy |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
