Alpina Spare Parts for Brushcutter B 28 J
€2.19
Tax included
Alpina Spare Parts for Brushcutter B 28 J
We are ALPINA authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter B 28 J/280120100-12-2015.for
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter B 28 J
We are ALPINA authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter B 28 J/280120100-12-2015.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA Brushcutter B 28 J/280120100-12-2015 Pag.1 | ||
| Housing | ||
| # | Part Num. | Description |
| 1 | 112789000/0 | Screw |
| 3 | 118801241/0 | Hub |
| 5 | 118801240/0 | Starter Pulley |
| 6 | 118801225/0 | Starter Cord |
| 7 | 118801242/0 | Spring |
| 10 | 118801238/0 | Starter Handle |
| 11 | 118801239/0 | Retainer |
| 12 | 118801237/0 | Starter Ass.Y Black |
| 13 | 2132450 | Screw |
| 14 | 118801226/0 | Starter Cup Ass.Y |
| 18 | 119035159/0 | Seal Ring |
| 19 | 123685024/0 | Crank Case |
| 20 | 123280046/0 | Crankcase Gasket |
| 21 | 114215218/0 | Ball Bearing |
| 22 | 123020024/0 | Crankshaft |
| 23 | 123072002/0 | Flywheel Key |
| 25 | 123685025/0 | Crank Case |
| 26 | 2135060 | Screw |
| 27 | 123880010/0 | Flywheel Ass.Y |
| 30 | 112154200/0 | Nut |
| 31 | 118801231/0 | Electronic Coil |
| 33 | 2135030 | Screw |
| 35 | 123430582/0 | Spring |
| 36 | 123400002/0 | Clutch Unit |
| 38 | 123878057/0 | Screw |
| 51 | 123235006/0 | Needle Bearing |
| 52 | 123202005/0 | Washer, Piston Pin |
| 53 | 123760005/0 | Piston Pin |
| 54 | 123590007/0 | Piston |
| 55 | 123204009/0 | Piston Ring |
| 56 | 123280044/0 | Cylinder Base Gasket |
| 57 | 123071013/0 | Cylinder Assy |
| 58 | 112760475/0 | Screw |
| 59 | 3210024 | Spark Plug |
| 61 | 118801232/0 | Spark Plug Cover |
| 62 | 123275023/0 | Grommet |
| 63 | 118801233/0 | White Cylinder Cover |
| 64 | 118801245/0 | White Cover |
| 65 | 118801255/0 | Gasket |
| 66 | 112760475/0 | Screw |
| 67 | 123280040/0 | Intake Manifold Gasket |
| 68 | 123073508/0 | Intake Manifold |
| 69 | 2135060 | Screw |
| 70 | 118801227/0 | Carburetor Gasket |
| 71 | 123054025/0 | Carburetor |
| 72 | 118801229/0 | Lever |
| 73 | 118801228/0 | Air Filter Support + Cover |
| 74 | 123190000/0 | Shutter |
| 76 | 2132160 | Screw |
| 77 | 123220011/0 | Air Filter |
| 78 | 118801230/0 | Filter Cover White |
| 79 | 118801320/0 | Gasket |
| 80 | 118801247/0 | Muffler Gasket |
| 82 | 183740021/0 | Muffler |
| 83 | 118801248/0 | Muffler Guard |
| 86 | 6981104 | Outfit, Screws |
| 87 | 123280060/0 | Rubber Gasket |
| 88 | 112788910/0 | Screw |
| 89 | 118801244/0 | Fuel Tank |
| 90 | 118801246/0 | Lower Guard |
| 91 | 2135030 | Screw |
| 92 | 2135200 | Screw |
| 93 | 118801319/0 | Tube |
| 94 | 118801318/0 | Grommet |
| 95 | 118801313/0 | Fuel Line |
| 96 | 183520005/0 | Intake Filter |
| 97 | 118801243/0 | Fuel Tank-Cap Ass.Y |
| Handle - Trasmission Pag.2 | ||
| 1 | 123050011/0 | Clutch Drum Assy |
| 2 | 112727815/0 | Screw |
| 3 | 118801235/0 | Guard |
| 6 | 112609200/0 | Seeger |
| 7 | 118801234/0 | Clutch Case White |
| 8 | 2135131 | Screw |
| 9 | 118801236/0 | Button |
| 10 | 118801308/0 | Rubber Sleeve |
| 12 | 118801307/0 | Bottom Clamp |
| 13 | 118801306/0 | Upper Clamp |
| 14 | 112788910/0 | Screw |
| 15 | 2135060 | Screw |
| 21 | 183869072/0 | Assy Transmission Tube |
| 22 | 118801343/0 | Trasmission Shaft |
| 23 | 118801344/0 | Joint Chair Assy |
| 25 | 183260002/0 | Connecting Head Assy |
| 26 | 123593510/0 | Knob |
| 27 | 183869074/0 | Assy Transmission Tube |
| 28 | 123020035/0 | Trasmission Shaft |
| 31 | 118801337/0 | Clamp |
| 32 | 112789000/0 | Screw |
| 33 | 118801335/0 | Safety Lever, Red |
| 34 | 118801336/0 | Throttle Lever, Red |
| 35 | 118801334/0 | Spring |
| 36 | 118801332/0 | Right Handgrip,White |
| 37 | 112735105/0 | Screw |
| 38 | 118801354/0 | Throttle Cable |
| 40 | 118801333/0 | Spring |
| 41 | 118801329/0 | Stop Knob,Red |
| 43 | 118801330/0 | Stop Plate |
| 44 | 118801338/0 | Spring |
| 45 | 118801328/0 | Stop Wire |
| 46 | 118801331/0 | Left Handgrip,White |
| 50 | 118801322/0 | Earth Cable |
| 51 | 183780002/0 | Harness Support |
| 52 | 123170004/0 | Spacer |
| 55 | 118801339/0 | Front Handle Assy, White |
| 56 | 118801340/0 | Lower Support |
| 57 | 2135040 | Screw |
| 71 | 118801327/0 | Harness |
| Gear Case Assy Pag.3 | ||
| 1 | 183820507/0 | Gear Case Assy |
| 6 | 112727801/0 | Screw |
| 7 | 112789000/0 | Screw |
| 8 | 112727794/0 | Screw |
| 10 | 123670002/0 | Guard |
| 15 | 123250002/0 | Upper Ring Nut |
| 16 | 123250003/0 | Lower Ring Nut |
| 18 | 123120015/0 | Nut |
| 21 | 123784012/0 | Support |
| 22 | 2135050 | Screw |
| 23 | 2135180 | Screw |
| 24 | 118801341/0 | Safety Cover, Black |
| 25 | 112735654/0 | Screw |
| 26 | 118801342/0 | Guard, Black |
| 27 | 112728099/1 | Screw |
| 28 | 123311013/0 | Line Cutter Blade |
| 31 | 123155009/0 | 2 Hedges Nylon Head |
| 32 | 123155010/0 | 3 Teeth Disc |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
