Alpina Spare Parts for Brushcutter BJ 336
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter BJ 336 (2013) 280220000/ALP.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| BJ 336 (2013) 280220000/ALP - Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118801251/0 | Screw |
| 2 | 118801250/0 | Hub |
| 4 | 118801249/0 | Starter Pulley |
| 5 | 118801252/0 | Starter Cord |
| 6 | 118801253/0 | Spring |
| 9 | 118801263/0 | Starter Handle |
| 10 | 118801264/0 | Retainer |
| 11 | 118801262/0 | Starter Ass.Y Black |
| 12 | 2135030 | Screw |
| 13 | 118801254/0 | Starter Cup Ass.Y |
| 17 | 119035159/0 | Seal Ring |
| 18 | 123685026/0 | Crank Case |
| 19 | 123280047/0 | Crankcase Gasket |
| 20 | 119216038/0 | Bearing |
| 21 | 123020025/0 | Crankshaft |
| 22 | 123072002/0 | Woodruff Key |
| 24 | 123685027/0 | Crank Case |
| 25 | 2132140 | Screw |
| 26 | 123880018/0 | Flywheel REPLACED BY 123880009/0 BUY WITH COIL |
| 29 | 112154200/0 | Nut |
| 30 | 123044018/0 | Electronic Coil REPLACED BY 123044011/0 BUY WITH FLYWHEEL |
| 32 | 2135030 | Screw |
| 35 | 123430583/0 | Clutch Unit |
| 37 | 123878058/0 | Screw |
| 53 | 123235007/0 | Ball Bearing |
| 54 | 123202009/0 | Washer, Piston Pin |
| 55 | 123760007/0 | Piston Pin |
| 56 | 123590008/0 | Piston |
| 57 | 123204010/0 | Piston Ring |
| 58 | 123280045/0 | Gasket |
| 59 | 123071024/0 | Cylinder Assy |
| 60 | 2132330 | Screw |
| 61 | 3210024 | Spark Plug |
| 63 | 118801258/0 | Spark Plug Cover |
| 64 | 123275023/0 | Grommet |
| 65 | 118801460/0 | Yellow Cylinder Cover |
| 67 | 118801463/0 | Yellow Cover |
| 68 | 2112140 | Screw |
| 69 | 123280041/0 | Gasket |
| 70 | 123073509/0 | Intake Manifold |
| 71 | 2135030 | Screw |
| 72 | 118801227/0 | Carburetor Gasket |
| 73 | 123054025/0 | Carburettor |
| 74 | 118801229/0 | Lever |
| 75 | 118801228/0 | Air Filter Support |
| 76 | 123190000/0 | Choke Lever |
| 78 | 2132160 | Screw |
| 79 | 123220011/0 | Air Filter |
| 80 | 118801297/0 | Filter Cover Yellow |
| 81 | 118801267/0 | Muffler Gasket |
| 83 | 183740022/0 | Muffler |
| 85 | 118801256/0 | White Cover |
| 88 | 2122210 | Screw |
| 89 | 123280060/0 | Grommet |
| 90 | 2112140 | Screw |
| 91 | 118801265/0 | Tank |
| 92 | 118801266/0 | Lower Guard |
| 93 | 2135030 | Screw |
| 94 | 2135200 | Screw |
| 95 | 118801319/0 | Tube |
| 96 | 118801318/0 | Grommet |
| 97 | 118801313/0 | Fuel Line |
| 98 | 183520005/0 | Intake |
| 99 | 118801243/0 | Fuel Tank-Cap Ass.Y |
| BJ 336 (2013) 280220000/ALP - Handle Drive Shaft Pag.2 | ||
| 1 | 123050012/0 | Drum Ass'Y, Clutch |
| 2 | 2122080 | Screw |
| 3 | 118801261/0 | Guard |
| 4 | 112610800/0 | Seeger |
| 5 | 119216048/0 | Ball Bearing |
| 6 | 112609200/0 | Seeger |
| 7 | 118801259/0 | Clutch Case |
| 8 | 2132330 | Screw |
| 9 | 118801260/0 | Button |
| 10 | 118801316/0 | Reduction |
| 11 | 118801311/0 | Reduction |
| 12 | 118801310/0 | Support |
| 13 | 118801309/0 | Support |
| 14 | 2135020 | Screw |
| 15 | 2135030 | Screw |
| 21 | 183869073/0 | Assy Transm. Tube+Flex |
| 22 | 123020038/0 | Drive Shaft |
| 31 | 118801337/0 | Clamp |
| 32 | 2112030 | Screw |
| 33 | 118801335/0 | Safety Lever ,Red |
| 34 | 118801336/0 | Throttle Lever,Red |
| 35 | 118801334/0 | Spring |
| 36 | 118801372/0 | Right Handgrip,Yellow |
| 37 | 112735105/0 | Screw |
| 38 | 118801354/0 | Wire Ass.Y |
| 40 | 118801333/0 | Spring |
| 41 | 118801329/0 | Stop Knob,Red |
| 43 | 118801330/0 | Stop Plate |
| 44 | 118801338/0 | Spring |
| 45 | 118801328/0 | Stop Wire |
| 46 | 118801374/0 | Left Handgrip,Yellow |
| 50 | 118801322/0 | Earth Cable |
| 51 | 183780002/0 | Harness Support Ass.Y |
| 52 | 123170004/0 | Spacer |
| 55 | 118801381/0 | Front Handle Ass.Y,Yellow |
| 71 | 118801327/0 | Harness |
| BJ 336 (2013) 280220000/ALP - Gears Case Pag.3 | ||
| 1 | 183820507/0 | Gear Case Assy |
| 6 | 112727801/0 | Screw |
| 7 | 2112030 | Screw |
| 8 | 112727794/0 | Screw |
| 10 | 123670002/0 | Guard |
| 15 | 123250002/0 | Upper Ring Nut |
| 16 | 123250003/0 | Lower Ring Nut |
| 18 | 123120015/0 | Nut |
| 21 | 123784012/0 | Support |
| 22 | 2135050 | Screw |
| 23 | 2135180 | Screw |
| 24 | 118801341/0 | Safety Cover, Black |
| 25 | 112735654/0 | Screw |
| 26 | 118801342/0 | Guard, Black |
| 27 | 112728099/1 | Screw |
| 28 | 123311013/0 | Line Cutter |
| 31 | 123155009/0 | 2 Hedges Nylon Head |
| 32 | 123155010/0 | 3 Teeth Disc |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
