Alpina Spare Parts for Brushcutter BJ 346
€0.66
Tax included
Alpina Spare Parts for Brushcutter BJ 346
We have the original Spares for ALPINA for Brushcutter BJ 346 (2013) 280320000/ALP, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Brushcutter BJ 346 (2013) 280320000/ALP. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter BJ 346
Fix Your Brushcutter BJ 346 (2013) 280320000/ALP. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| BJ 346 (2013) 280320000/ALP - Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118801251/0 | Screw |
| 2 | 118801250/0 | Hub |
| 4 | 118801249/0 | Starter Pulley |
| 5 | 118801252/0 | Starter Cord |
| 6 | 118801253/0 | Spring |
| 9 | 118801263/0 | Starter Handle |
| 10 | 118801264/0 | Retainer |
| 11 | 118801262/0 | Starter Ass.Y Black |
| 12 | 2135030 | Screw |
| 13 | 118801254/0 | Starter Cup Ass.Y |
| 17 | 119035159/0 | Seal Ring |
| 18 | 118801281/0 | Crank Case |
| 19 | 123280087/0 | Crankcase Gasket |
| 20 | 119216048/0 | Ball Bearing |
| 21 | 118801278/0 | Crankshaft |
| 22 | 123072002/0 | Woodruff Key |
| 24 | 118801280/0 | Crank Case |
| 25 | 2132140 | Screw |
| 26 | 118801321/0 | Flywheel |
| 29 | 112154200/0 | Nut |
| 30 | 118801276/0 | Electronic Coil |
| 32 | 2135030 | Screw |
| 35 | 123430583/0 | Clutch Unit |
| 37 | 123878058/0 | Screw |
| 53 | 118801284/0 | Ball Bearing |
| 54 | 118801325/0 | Washer, Piston Pin |
| 55 | 123760008/0 | Piston Pin |
| 56 | 118801279/0 | Piston |
| 57 | 123204017/0 | Piston Ring |
| 58 | 118801282/0 | Gasket |
| 59 | 118801270/0 | Cylinder Assy |
| 60 | 2135030 | Screw |
| 61 | 3210024 | Spark Plug |
| 63 | 118801272/0 | Spark Plug Cover |
| 64 | 123275023/0 | Grommet |
| 65 | 118801299/0 | Yellow Cylinder Cover |
| 67 | 118801301/0 | Yellow Cover |
| 68 | 2135030 | Screw |
| 69 | 123280085/0 | Gasket |
| 70 | 118801323/0 | Intake Manifold |
| 72 | 123280086/0 | Carburetor Gasket |
| 73 | 118801268/0 | Carburettor |
| 74 | 118801229/0 | Lever |
| 75 | 118801228/0 | Air Filter Support |
| 76 | 123190000/0 | Choke Lever |
| 78 | 2132160 | Screw |
| 79 | 123220011/0 | Air Filter |
| 80 | 118801303/0 | Filter Cover Yellow |
| 81 | 118801277/0 | Muffler gasket |
| 83 | 118801269/0 | Muffler |
| 84 | 2112030 | Screw |
| 85 | 118801283/0 | White Cover |
| 86 | 2122210 | Screw |
| 87 | 123280060/0 | Grommet |
| 88 | 2112140 | Screw |
| 89 | 118801274/0 | Fuel Tank Assy. ( new 118801274/1 ) |
| 90 | 118801417/0 | Lower Guard |
| 91 | 2135030 | Screw |
| 92 | 2135200 | Screw |
| 93 | 118801319/0 | Tube |
| 94 | 118801318/0 | Grommet |
| 95 | 118801313/0 | Fuel Line |
| 96 | 183520005/0 | Fuel Filter |
| 97 | 118801243/0 | Fuel Tank-Cap Ass.Y |
| BJ 346 (2013) 280320000/ALP - Handle Drive Shaft Pag.2 | ||
| 1 | 123050012/0 | Drum Ass'Y, Clutch |
| 2 | 2122080 | Screw |
| 3 | 118801261/0 | Guard |
| 4 | 112610800/0 | Seeger |
| 5 | 119216048/0 | Ball Bearing |
| 6 | 112609200/0 | Seeger |
| 7 | 118801259/0 | Clutch Case |
| 8 | 2132330 | Screw |
| 9 | 118801260/0 | Button |
| 10 | 118801316/0 | Reduction |
| 11 | 118801311/0 | Reduction |
| 12 | 118801310/0 | Support |
| 13 | 118801309/0 | Support |
| 14 | 2135020 | Screw |
| 15 | 2135030 | Screw |
| 21 | 183869073/0 | Assy Transm. Tube+Flex |
| 22 | 123020038/0 | Drive Shaft |
| 31 | 118801337/0 | Clamp |
| 32 | 2112030 | Screw |
| 33 | 118801335/0 | Safety Lever ,Red |
| 34 | 118801336/0 | Throttle Lever,Red |
| 35 | 118801334/0 | Spring |
| 36 | 118801372/0 | Right Handgrip,Yellow |
| 37 | 112735105/0 | Screw |
| 38 | 118801354/0 | Wire Ass.Y |
| 40 | 118801333/0 | Spring |
| 41 | 118801329/0 | Stop Knob,Red |
| 43 | 118801330/0 | Stop Plate |
| 44 | 118801338/0 | Spring |
| 45 | 118801328/0 | Stop Wire |
| 46 | 118801374/0 | Left Handgrip,Yellow |
| 50 | 118801322/0 | Earth Cable |
| 51 | 183780002/0 | Harness Support Ass.Y |
| 52 | 123170004/0 | Spacer |
| 55 | 118801381/0 | Front Handle Ass.Y,Yellow |
| 71 | 118801327/0 | Harness |
| BJ 346 (2013) 280320000/ALP - Gear Case Pag.3 | ||
| 1 | 183820507/0 | Gear Case Assy |
| 6 | 112727801/0 | Screw |
| 7 | 2112030 | Screw |
| 8 | 112727794/0 | Screw |
| 10 | 123670002/0 | Guard |
| 15 | 123250002/0 | Upper Ring Nut |
| 16 | 123250003/0 | Lower Ring Nut |
| 18 | 123120015/0 | Nut |
| 21 | 123784012/0 | Support |
| 22 | 2135050 | Screw |
| 23 | 2135180 | Screw |
| 24 | 118801341/0 | Safety Cover, Black |
| 25 | 112735654/0 | Screw |
| 26 | 118801342/0 | Guard, Black |
| 27 | 112728099/1 | Screw |
| 28 | 123311013/0 | Line Cutter |
| 31 | 123155009/0 | 2 Hedges Nylon Head |
| 32 | 123155010/0 | 3 Teeth Disc |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
BJ346 (2013) 280320000/ALP
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
