Telwin Spare Parts for Flux Welding Telmig 250/2 Turbo
€2.62
Tax included
Telwin Spare Parts for Flux Welding Telmig 250/2 Turbo
Telwin original spare parts for to replace broken parts for to fix welding machine Flux and Mig-mag Telmig 250/2 Turbo - 821061.Fix Your welding machine. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Spare Parts for Flux Welding Telmig 250/2 Turbo
Telwin original spare parts for to replace broken parts for to fix welding machine Flux and Mig-mag Telmig 250/2 Turbo - 821061.In the following table, look for the model of the welding machine and theirs spare parts codes.
| TELMIG 250/2 TURBO 230-400V cod. 821061 Pag.1 | ||
| # | Description | Part Num. |
| 1 | POTENTIOMETER 10K | 112079 |
| 2 | KNOB | 121424 |
| 3 | CHANGING VOLTAGE CARD | 112165 |
| 4 | RECTIFIER PROTECTION | 112183 |
| 5 | RECTIFIER | 112311 |
| 6 | CONTROL PCB KIT | 980713 |
| 7 | SWITCH | 122052 |
| 8 | SWITCH KNOB SET | 323101 |
| 9 | REACTANCE | 169374 |
| 10 | THERMOSTAT | 122132 |
| 12 | FUSE | 122432 |
| 13 | SWITCH | 121169 |
| 14 | ELECTRO-VALVE | 122682 |
| 15 | CONTACTOR | 122694 |
| 16 | YELLOW PILOT LAMP | 122594 |
| 17 | CABLE 25 MMQ 2 M | 123466 |
| 18 | MAINS CABLE 4G2.5 2 M | 132244 |
| 19 | FAN | 152054 |
| 20 | FAN MOTOR | 152110 |
| 21 | WIRE FEED MOTOR | 153007 |
| 22 | TRANSFORMER | 169753 |
| 23 | AUXILIARY TRANSFORMER | 164270 |
| 25 | PRESSURE ROLL | 232105 |
| 26 | REEL HANDWHEEL | 312137 |
| 27 | REEL | 322081 |
| 28 | CABLE BUSHING KIT | 990439 |
| 29 | ROLL SUPPORT | 322126 |
| 30 | TORCH FIXING CASING | 322127 |
| 31 | PRESSURE ROLL BRACKET | 322128 |
| 32 | SPACER | 322180 |
| 33 | FIXED WHEEL | 322200 |
| 34 | WHEEL | 322246 |
| 35 | FRAME | 322641 |
| 37 | WIRE FEED HANDWHEEL | 422257 |
| 38 | SUPPORT | 422817 |
| 39 | SWIVEL SUPPORT | 422969 |
| 40 | ARGON GAS BOTTLE IT ADAPTOR | 432036 |
| 41 | SPRING | 452022 |
| 42 | REEL SPRING | 452057 |
| 43 | HANDLE | 312328 |
| 44 | BACK PANEL | 644077 |
| 45 | DIAPHRAGM | 644078 |
| 46 | BRACKET FOR BOTTLE | 644606 |
| 47 | FRONT PANEL | 649553 |
| 48 | BOTTOM | 644967 |
| 49 | COVER KIT | 980855 |
| 51 | DOOR KIT | 980899 |
| 52 | WHEELS AXLE | 681092 |
| 53 | TOLEDO 250 WORK CLAMP 250A | 712030 |
| 54 | FEED ROLL D. 0,6-0,8 MM FE | 722019 |
| 55 | GAS REGULATOR REFILLABLE BOTTLE | 722341 |
| 56 | MT15 MIG TORCH 3 M 220 A | 742180 |
| 57 | TORCH CONNECTION | 723051 |
| 60 | GAS HOSE KIT | 990097 |
| 61 | GEARS KIT | 990257 |
| 62 | REEL KIT | 990264 |
| Torch TELMIG 250/2 TURBO 230-400V Pag.2 | ||
| 1 | RING NUT | 722007 |
| 2 | LINER NUT | 722013 |
| 3 | SWAN NECK DIFFUSER | 722305 |
| 5 | NOZZLE SPRING | 722319 |
| 6 | DIFFUSER INSULATION | 722326 |
| 7 | TORCH HOLDER | 742172 |
| 8 | CONTACT TIP D. 0,8 MM FE | 722416 |
| 8 | CONTACT TIP D. 0,6 MM FE | 722415 |
| 10 | CYLINDRICAL NOZZLE | 722149 |
| 10 | CONICAL NOZZLE | 722423 |
| 11 | WIRE GUIDE HOSE D. 1-1,2 MM 3 M | 722689 |
| 11 | WIRE GUIDE HOSE D. 0,6-0,8 MM 3 M | 722437 |
| 13 | TORCH BODY ASSY | 722441 |
| 14 | TORCH CONNECTION | 742175 |
| 15 | TORCH RING NUT | 742171 |
| 16 | TORCH CONNECTION | 722325 |
| 17 | TORCH CONNECTION INSULATION | 722693 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Telwin TELMIG 250/2 TURBO 821061
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM OR S/N CODE TELWIN:
- TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
