Telwin Spare Parts for Technology Tig 180 AC/DC HF/LIFT 230V

Technology Tig 180 Pag.1
#	Part Num.	Description
1	980468	BOARD KIT H.F.
2	990044	BOARD KIT PRIMARY - DISCONTINUED
3	990048	KIT FORM SECONDARY - DISCONTINUED
5	990077	CONTROL BOARD KIT TIG
6	120043	WIRING CONTROL
7	120050	SECONDARY WIRING
9	122035	SOLENOID
10	322901	KNOB FOR SWITCH
11	121507	SWITCH
12	132158	CABLE ALIM. 3G2.5 2 M
13	152000	FAN
14	990597	TRANSFORMER AUXILIARY
15	990623	TRANSFORMER
16	980153	KIT TRANSFORMER
17	980174	KIT INDUCTOR OUTPUT
18	313813	FRONT PANEL
19	322536	FRAME
20	322538	HANDLE
21	644952	FUND
22	655022	COAT
23	712036	SOCKET DX 50
24	990026	KIT WHEEL
25	112357	PHASE RECTIFIER
26	112048	RESISTANCE
28	112514	CAPACITOR
29	112689	DIODE
30	112690	IGBT
31	112898	RELAY '
32	112391	DIODE
33	122190	FUSE
34	122508	THERMOSTAT
35	152028	SHUNT
36	152232	TRANSFORMER PULSE
37	164932	TRANSFORMER AUXILIARY
38	482690	FRONT
39	482691	RETRO
40	602052	WATER CONNECTION
41	990046	GLAND NUT KIT +
42	990054	KIT DIODES-IGBT-RESISTANCE
43	990120	CONNECTION KIT INLET GAS
TECHNOLOGY TIG 180 AC/DC HF/LIFT - Torch Pag.2
1	722194	Long Ceramic Nozzle Nr.6
1	802244	Kit 10 Ceramic Nozzles Nr.4
1	802245	Kit 10 Ceramic Nozzles Nr.6
1	802246	Kit 10 Ceramic Nozzles Nr.7
2	722248	Insulator
4	802220	Kit 10 Cerium-tungsten Electrodes D.1
4	802222	Kit 10 Cerium-tungsten Electrodes D.1,6
4	802232	Kit 10 Cerium-tungsten Electrodes D.2,4
5	802239	Kit 3 Electrode Holder Clamp D.1
5	802240	Kit 3 Electrode Holder Clamp D.1,6
5	802241	Kit 3 Electrode Holder Clamp D.2,4
6	722192	Short Cap
7	722193	Long Cap
8	722207	Connection 50 Mmq
10	722292	Gas Clutch Connector
12	722999	3P Plug
14	452089	Pushbotton Contact
16	722061	Or Ring
17	742042	Pushbotton
18	722204	Torch Body
19	802249	Kit 3 Electrode Diffusers D.1
19	802250	Kit 3 Electrode Diffusers D.1,6
19	802251	Kit 3 Electrode Diffusers D.2,4
21	990263	Gas Connection Kit
501	742424	Torch
