Telwin Parts for Inverter SUPERIOR TIG 251 DC-HF/LIFT VRD
€9.20
Tax included
Telwin Parts for Inverter SUPERIOR TIG 251 DC-HF/LIFT VRD
TELWIN Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Inverter Welding SUPERIOR TIG 251 DC-HF/LIFT VRD 816116
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Parts for Inverter SUPERIOR TIG 251 DC-HF/LIFT VRD
TELWIN Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Inverter Welding SUPERIOR TIG 251 DC-HF/LIFT VRD - 816116
In the following table, look for the model of the Welding and the respective parts of the code.
| SUPERIOR TIG 251 DC-HF/LIFT VRD - 816116 Pag.1 | ||
| 1 | 111095 | IGBT |
| 2 | 111194 | DIODE |
| 3 | 113790 | RELAY ' |
| 4 | 111259 | PONTE singl. 12A 1000V |
| 5 | 116752 | RESISTANCE |
| 6 | 116760 | VARISTOR |
| 7 | 116882 | CAPACITOR |
| 8 | 116935 | SUPPRESSOR VOLTAGE |
| 9 | 116962 | RESISTANCE 10R 2W 5% FUSE |
| 10 | 121029 | SOLENOID |
| 11 | 121546 | THERMOSTAT |
| 12 | 121556 | SWITCH |
| 13 | 122159 | FUSE |
| 14 | 122433 | FUSE 1A |
| 15 | 124105 | WIRING CONTROL / C.A.D. |
| 16 | 124657 | WIRING G.R.A. |
| 17 | 124694 | WIRING KEY TORCH |
| 18 | 132237 | CABLE ALIM. 4G1.5 2 M |
| 19 | 152230 | CURRENT TRANSFORMER |
| 20 | 152269 | FAN |
| 21 | 169556 | REACTOR |
| 22 | 169627 | TRANSFORMER |
| 23 | 169746 | REACTOR |
| 24 | 169747 | CHOKE FILTER |
| 25 | 169749 | POWER TRANSFORMER |
| 26 | 321126 | FRONT |
| 27 | 321127 | RETRO |
| 28 | 321128 | HANDLE |
| 29 | 323101 | TOGETHER FOR SWITCH KNOB |
| 30 | 602052 | WATER CONNECTION |
| 31 | 712036 | SOCKET DX 50 |
| 32 | 980021 | BOARD KIT HF |
| 33 | 121547 | KNOB FOR POT |
| 34 | 980548 | CONNECTION KIT INLET GAS |
| 35 | 981183 | KIT IGBT + DIODE |
| 36 | 981278 | KIT AUTOTRASFO |
| 37 | 981372 | KIT TRANSFORMER PULSE |
| 38 | 981399 | BOARD KIT POWER |
| 39 | 981400 | KIT IGBT + DIODE |
| 40 | 981434 | KIT TRANSFORMER |
| 41 | 981435 | KIT CONTROL BOARD |
| 42 | 981436 | BOARD KIT KEYPAD |
| 43 | 981437 | KIT COAT |
| 44 | 981438 | KIT FUND |
| 45 | 981535 | KIT FORM PANEL |
| TORCH FOR SUPERIOR TIG 251 DC-HF/LIFT VRD - 816116 Pag.2 | ||
| 0 | 722559 | TORCH 4 M |
| 1 | 802245 | KIT 10 CERAMIC NOZZLES NR.6 |
| 1 | 802246 | KIT 10 CERAMIC NOZZLES NR.7 |
| 1 | 802244 | KIT 10 CERAMIC NOZZLES NR.4 |
| 1 | 802247 | KIT 10 CERAMIC NOZZLES NR.8 |
| 1 | 802248 | KIT 10 CERAMIC NOZZLES NR.10 |
| 2 | 722248 | INSULATION |
| 4 | 802237 | KIT 10 ELETTR.TUNGSTENO PURE D.3,2 MM |
| 4 | 802235 | KIT 10 ELETTR.TUNGSTENO PURE D.1,6 MM |
| 4 | 802238 | KIT 10 ELETTR.TUNGSTENO PURE D. 4 MM |
| 4 | 802232 | KIT 10 ELETTR.TUNGSTENO CERIUM D.2,4 MM |
| 4 | 802222 | KIT 10 ELETTR.TUNGSTENO CERIUM D.1,6 MM |
| 4 | 802220 | KIT 10 ELETTR.TUNGSTENO CERIUM D.1 MM |
| 4 | 802236 | KIT 10 ELETTR.TUNGSTENO PURE D.2,4 MM |
| 4 | 802233 | KIT 10 ELETTR.TUNGSTENO CERIUM D.3,2 MM |
| 5 | 802242 | KIT 3 CLAMP ELECTRODE D.3,2 MM SERRA |
| 5 | 802240 | KIT 3 CLAMP ELECTRODE D.1,6 MM SERRA |
| 5 | 802239 | KIT 3 CLAMP ELECTRODE D.1,0 MM SERRA |
| 5 | 802241 | KIT 3 CLAMP ELECTRODE D.2,4 MM SERRA |
| 5 | 802243 | KIT 3 CLAMP ELECTRODE D.4 MM SERRA |
| 6 | 722192 | HOOD SHORT |
| 7 | 722193 | HOOD LONG |
| 9 | 981443 | KIT CONNECTION 50 |
| 12 | 742599 | PLUG 5P |
| 14 | 452089 | CONTACT BUTTON |
| 16 | 722061 | RING OR |
| 17 | 742042 | BUTTON |
| 18 | 722944 | BODY TORCH |
| 19 | 802250 | KIT 3 SPEAKER ELECTRODE D.1,6 MM |
| 19 | 802252 | KIT 3 SPEAKER ELECTRODE D.3,2 MM |
| 19 | 802251 | KIT 3 SPEAKER ELECTRODE D.2,4 MM |
| 19 | 802253 | KIT 3 SPEAKER ELECTRODE D.4 MM |
| 19 | 802249 | KIT 3 SPEAKER ELECTRODE D.1 MM |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
