Telwin TELMIG 100 Spare Parts

€0.38
Tax included

Telwin TELMIG 100 Spare Parts

Telwin original spare parts for to replace broken parts for to fix Inverter Welding Telmig 100 - 821050.

Fix Your Inverter Welding Telmig 100 - 821050. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

Telwin Telmig 150/1 Turbo 821052
ITEM CODE: 112125
Quantity
Usually Ships in: 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Telwin TELMIG 100 Spare Parts

Fix Your Inverter Welding Telmig 100 - 821050. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the type of the welding machine and theirs spare parts codes.
Telwin Telmig 100

Telwin Inverter TELMIG 100 - 821050 Spare Parts Pag.1
# Part Num. Description
1 112125 Potentiometer Knob
2 112183 Rectifier Protection
3 113533 Potentiometer
4 114635 Wire Feeder Board
5 120300 Cable 6 Mmq 1,8 M
6 122525 Thermostat
7 122400 Switch
8 122752 Switch
9 132310 Cable 3G1.5 2 M Schuko Plug
11 153900 Wire Feed Motor
12 990811 Transformer Kit
13 169282 Reactance
14 232105 Pressure Roll
16 322126 Roll Support
17 322127 Torch Fixing Casing
18 322128 Pressure Roll Bracket
19 322584 Front Panel Frame
20 322586 Back Panel Frame
21 422257 Wire Feed Handwheel
22 452022 Spring
23 644959 Bottom
24 651015 Door
25 722019 Feed Roll D. 0,6-0,8 Mm
26 742900 Mig Torch 2 M 130 A
29 990097 Gas Hose Kit
30 990251 Gears Kit
31 990288 Reel Kit
32 990746 Rectifier Kit
33 322172 Spindle
34 322173 Reel Ring Nut
35 322174 Reel Handwheel
36 452065 Bobine Reel Spring
37 322585 Fairleader
38 322143 Ring Nut
39 990783 Cover Kit
40 990785 Diaphragm Kit
41 649398 Front Panel
42 644923 Back Panel
43 322587 Handle
44 322590 Handle
45 712001 Work Clamp 150A
46 322112 Cable Bushing
47 322104 Bottle Belt
48 722120 Gas Regulator Throwaway Bottle
Telwin Inverter TELMIG 100 Spare Parts Torch
1 722667 Contact Tip D. 0,8 Mm
2 722054 Cylindrical Nozzle
3 722810 Swan Neck
4 990464 Valve
5 452097 Contact Spring For Mig Torch
6 322295 Pushbutton
7 990600 Kit Cables Set 10Mmq
9 742412 Liner D. 0,6-0,8 Mm
- 742900 Torch
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Telwin TELMIG 100 821050
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM OR S/N CODE TELWIN:
TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
