Telwin Parts for Welding Machine Inverpulse 420 MIG-TIG-MMA
€18.95
Tax included
Telwin Parts for Welding Machine Inverpulse 420 MIG-TIG-MMA
We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Telwin Welding Machine Inverpulse 420 MIG-TIG-MMA.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Parts for Welding Machine Inverpulse 420 MIG-TIG-MMA
We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Telwin Welding Machine Inverpulse 420 MIG-TIG-MMA.In the following table, look for the model of the drill and the respective parts of the code.
| Inverpulse 420 MIG-TIG-MMA Pag.1 | ||
| # | Part Num. | Description |
| 1 | 116422 | Capacitor |
| 3 | 113281 | Relais |
| 4 | 113603 | Igbt |
| 5 | 113334 | Resistor |
| 6 | 114779 | Filter Card |
| 7 | 980633 | Interface Card Kit |
| 8 | 722798 | Mig Torch 3 M 500 A |
| 9 | 116265 | Sensor Hall |
| 10 | 116297 | Sensor Hall |
| 11 | 120700 | Control Cable |
| 12 | 120701 | Wire Feeder Cable |
| 13 | 120702 | G.r.a.cable |
| 14 | 120710 | Torch Button Cable |
| 15 | 121029 | Electrovalve |
| 16 | 122017 | Switch |
| 17 | 122437 | Fuse |
| 18 | 122571 | Thermal Switch |
| 19 | 132338 | Mains Cable H05vv-f 4G04.00 L=02.50 |
| 20 | 152000 | Fan |
| 21 | 152232 | Pulse Transformer |
| 22 | 169346 | Secondary Inductance |
| 23 | 990987 | Auxiliary Transformer |
| 24 | 990986 | Auxiliary Transformer |
| 25 | 313874 | Panel |
| 26 | 322536 | Frame |
| 27 | 322538 | Handle |
| 28 | 322901 | Switch Knob |
| 29 | 645046 | Bottom |
| 30 | 655304 | Cover |
| 31 | 712034 | Work Clamp 600A |
| 32 | 712037 | Socket RIGHT 70/95 |
| 33 | 712088 | Plug RIGHT 95 |
| 34 | 723114 | Cable 95Mmq 3M-work Clamp-dx 95 |
| 35 | 990026 | Knob Kit |
| 36 | 990120 | Gas Pipe Connector Kit |
| 37 | 990167 | Knob Kit |
| 38 | 990439 | Cable Bushing Kit |
| 39 | 990852 | Front Panel + Module Set GÉnÉrateur |
| 40 | 990853 | Secundary Pcb Kit |
| 41 | 990854 | Primary Kit |
| 42 | 990855 | Kit Transformer + Reactance |
| 43 | 990856 | Diodes Kit |
| 44 | 122159 | Fuse Holder |
| 45 | 122410 | Fuse |
| Torch Spare Parts List Pag.2 | ||
| 1 | 722007 | Ring Nut |
| 2 | 722013 | Liner Nut |
| 3 | 722597 | Wire Guide Hose D. 1,6-2 Mm |
| 3 | 722689 | Liner D. 1-1,2 Mm 3 M |
| 3 | 722795 | Liner D. 1,2-1,6 Mm |
| 3 | 722814 | Wire Guide Hose D.1,6-2mm 3M |
| 3 | 742164 | Wire Guide Hose D. 1-1.2 Mm |
| 4 | 722581 | Contact Tip D.0,8 |
| 4 | 722582 | Contact Tip D.1,0 |
| 4 | 722583 | Contact Tip D.1,2 |
| 4 | 722586 | Contact Tip D.2,0 |
| 4 | 722587 | Contact Tip D.1,6 . |
| 4 | 722769 | Flux Contact Tip D.1 Mm |
| 4 | 722770 | Contact Tip Flux D.1,2 Mm |
| 4 | 722771 | Contact Tip Flux D.1.6 Mm |
| 4 | 722772 | Contact Tip Al/flux D.2 Mm |
| 4 | 742159 | Contact Tip Al D.1 Mm |
| 4 | 742160 | Contact Tip Al D.1.2 Mm |
| 4 | 742161 | Contact Tip Al D.1.6 Mm |
| 5 | 722598 | Wire Guide Locking Nipples |
| 5 | 722599 | Wire Guide Locking Nipples |
| 6 | 722600 | Wire Guide Locking Tube |
| 7 | 722601 | Or Ring |
| 7 | 722606 | Or Ring |
| 8 | 722677 | Pushbutton |
| 9 | 722801 | Swan Neck |
| 10 | 722802 | Gas Diffuser |
| 12 | 722621 | Complete Adaptor Cover |
| 14 | 722807 | Contact Tip Holder |
| 15 | 722808 | Conical Nozzle |
| 15 | 722809 | Cylindrical Nozzle |
| - | 722798 | Torch 3m |
| - | 722800 | Torch 5m |
