Telwin Spare Parts for Welding Technomig 223 Treo Synergic 230V
€2.92
Tax included
Telwin Spare Parts for Welding Technomig 223 Treo Synergic 230V
Telwin Genuine spare parts or replacement parts for to fix Welding Technomig 223 Treo Synergic - 816058.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Spare Parts for Welding Technomig 223 Treo Synergic 230V
Telwin Genuine spare parts or replacement parts for to repair Welding Technomig 223 Treo Synergic - 816058.
Open PDF Diagram, check your spare part number position and then select it in the following table.
| Welding Technomig 223 Treo SYnergic - 816058 Pag.1 | ||
| # | Part Num. | Description |
| 2 | 112048 | RESISTANCE |
| 3 | 112357 | SINGLE-PHASE RECTIFIER |
| 4 | 112694 | CAPACITOR |
| 5 | 116320 | RELAIS |
| 6 | 116839 | DIODE |
| 7 | 121248 | SWITCH |
| 8 | 121315 | ENCODER KNOB D.15 |
| 9 | 121800 | ELECTROVALVE |
| 10 | 123437 | CABLE 16 MMQ 3 M - 25 |
| 11 | 132157 | MAINS CABLE |
| 12 | 152230 | CURRENT TRANSFORMER |
| 13 | 152269 | FAN |
| 14 | 153039 | MOTOREDUCER 24V DC |
| 15 | 164741 | FILTER INDUCTANCE |
| 16 | 169700 | TRANSFORMER X FLYBACK |
| 17 | 169808 | OUTPUT INDUCTANCE |
| 18 | 169822 | POWER TRAFO |
| 19 | 312105 | TORCH CONNECTION PROTECTION |
| 20 | 122353 | SWITCH COVER |
| 21 | 321137 | UPPER FRONT PANEL |
| 22 | 321138 | LOWER FRONT PANEL |
| 23 | 321165 | HANDLE SET |
| 24 | 321194 | SHIELD |
| 25 | 321196 | CARD HOLDER |
| 27 | 321210 | REEL SPACER |
| 28 | 322245 | WHEEL |
| 29 | 322772 | WHEEL |
| 30 | 322814 | COVER |
| 31 | 422940 | WHEELS AXLE |
| 33 | 484688 | SWIVEL SUPPORT + BRAKE |
| 34 | 645623 | DINSE HOLDER |
| 35 | 982077 | INSULATOR KIT |
| 36 | 645667 | DIAPHRAGM |
| 37 | 645668 | LOWER DIAPHRAGM |
| 38 | 645672 | BOTTLE HOLDER |
| 39 | 645674 | SMALL BOTTLE-HOLDER BRACKET |
| 40 | 645677 | LOWER HOLDER |
| 42 | 981740 | COVER KIT |
| 43 | 651212 | LOWER SIDE DOOR |
| 44 | 656165 | SIDE PANEL |
| 45 | 656171 | DOOR |
| 46 | 712030 | TOLEDO 250 WORK CLAMP 250A |
| 47 | 712035 | SOCKET DX 25 |
| 48 | 712039 | PLUG DX 25 |
| 49 | 722112 | FEED ROLL D. 0,6-0,8 MM FE |
| 50 | 742576 | FEED ROLL 4R 0,6FE-0,8FE |
| 51 | 722227 | FEED ROLL D. 0,8-1 MM FE |
| 52 | 722241 | FEED ROLL D. 1,2-1,6 MM FE |
| 53 | 723051 | TORCH CONNECTION |
| 54 | 981928 | 4 ROLL WIREFEEDER |
| 55 | 723229 | TORCH CONNECTION |
| 56 | 742064 | WIRE GUIDE INLET |
| 57 | 742090 | FEED ROLL D. 0,8-1 MM AL |
| 58 | 742096 | ANCHOR FOR PRESSURE ROLLER |
| 59 | 742166 | ADAPTER |
| 60 | 981929 | LEFT ANCHOR FOR PRESSURE ROLLER |
| 61 | 981930 | RIGHT ANCHOR FOR PRESSURE ROLLER |
| 62 | 742348 | MOTOR DRIVE GEAR |
| 63 | 742365 | WIRE CONDUIT Ø 2X5 |
| 64 | 742397 | ROLLERFIXING SCREW |
| 65 | 742590 | GEARS |
| 66 | 742650 | MT15 MIG TORCH 3M |
| 67 | 742660 | MT15 MIG TORCH 3M BLUE |
| 68 | 980990 | IGBT + DIODE KIT |
| 69 | 981494 | COMPLETE PCB KIT |
| 70 | 981496 | KIT 2 ROLLS WIREFEEDER |
| 72 | 981641 | KIT FRONT PANEL CARD |
| 73 | 981642 | BOTTOM KIT |
| 74 | 981643 | BACK PANEL KIT |
| 75 | 981644 | FRONT PANEL KIT |
| 76 | 981645 | AUXILIARY BOARD KIT |
| 77 | 981646 | HOLDING BRACKET KIT |
| 78 | 981647 | UPPER HOLDER KIT |
| 79 | 990046 | KIT CABLE BUSHING + RING NUT |
| 80 | 990097 | GAS HOSE KIT |
| 81 | 981703 | REEL KIT 15KG |
| Torch Parts Pag.2 | ||
| 1 | 722007 | RING NUT |
| 2 | 722013 | LINER NUT |
| 3 | 722305 | SWAN NECK DIFFUSER |
| 5 | 722319 | NOZZLE SPRING |
| 6 | 722326 | DIFFUSER INSULATION |
| 7 | 742172 | TORCH HOLDER |
| 8 | 722415 | CONTACT TIP D. 0,6 MM FE |
| 8 | 722416 | CONTACT TIP D. 0,8 MM FE |
| 10 | 722149 | CYLINDRICAL NOZZLE |
| 10 | 722423 | CONICAL NOZZLE |
| 11 | 722437 | WIRE GUIDE HOSE Ø 0,6-0,8 MM 3 M BLUE |
| 11 | 722689 | WIRE GUIDE HOSE Ø 1,0-1,2 3 M RED |
| 13 | 722441 | TORCH ASSY |
| 14 | 742175 | TORCH CONNECTION |
| 15 | 742171 | TORCH RING NUT |
| 16 | 722325 | TORCH CONNECTION |
| 17 | 722693 | TORCH CONNECTION INSULATION |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Technomig 223 Treo Syn. 816058
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM OR S/N CODE TELWIN:
- TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
