Telwin Parts for Inverter INVERPULSE 625 MIG/TIG/MMA 400V
€2.89
Tax included
Telwin Parts for Inverter INVERPULSE 625 MIG/TIG/MMA 400V
Original spare parts and replacement parts for Telwin MIG-MAG-FLUX Welding Machine INVERPULSE 625 MIG/TIG/MMA 400V + ACCESSORIES - 815490.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Parts for Inverter INVERPULSE 625 MIG/TIG/MMA 400V
Original spare parts and replacement parts for Telwin MIG-MAG-FLUX Welding Machine INVERPULSE 625 MIG/TIG/MMA 400V + ACCESSORIES - 815490In the following table, look for the model of the drill and the respective parts of the code.
| INVERPULSE 625 MIG/TIG/MMA 400V+ACC. 815490 Pag.1 | ||
| 1 | RELAIS | 113281 |
| 2 | RESISTOR | 113334 |
| 3 | IGBT | 113603 |
| 4 | RECTIFIER | 116066 |
| 5 | CAPACITOR | 116422 |
| 6 | SENSOR HALL | 116837 |
| 7 | IGBT | 116789 |
| 8 | SENSOR HALL | 116836 |
| 9 | ELECTROVALVE | 121029 |
| 10 | SWITCH | 121505 |
| 11 | FUSE HOLDER | 122159 |
| 12 | FUSE | 122437 |
| 13 | THERMAL SWITCH | 122571 |
| 14 | ELECTRO-VALVE | 122682 |
| 15 | FUSE | 121445 |
| 16 | TORCH BUTTON CABLE | 124218 |
| 17 | CONNECTOR CABLE | 124219 |
| 18 | WIRE FEEDER CONNECTOR CABLE | 124220 |
| 19 | G.R.A./ELECTROVALVE CABLE | 124222 |
| 20 | CONNECTOR CABLE | 124226 |
| 21 | WIRE FEEDER CONNECTOR CABLE | 124362 |
| 22 | MAINS CABLE 4G06.00 L=03.00 | 132361 |
| 23 | FAN | 152000 |
| 24 | MOTOREDUCER 42VDC + HALL SONDE | 153036 |
| 25 | AUXILIARY TRANSFORMER KIT | 980958 |
| 26 | PRIMARY INDUCTANCE | 169642 |
| 27 | TORCH CONNECTION PROTECTION | 312045 |
| 28 | HANDWHEEL | 312369 |
| 29 | HINGE SET | 312382 |
| 30 | HANDLE | 312420 |
| 31 | WIREFEEDER FRONT PANEL | 314220 |
| 32 | GENERATOR FRONT PANEL | 314221 |
| 33 | SLIDING SHUTTER | 322487 |
| 34 | RING NUT | 322671 |
| 35 | HANDLECOVER | 322848 |
| 36 | REEL | 322864 |
| 37 | FRONT PANEL | 322872 |
| 38 | BACK PANEL | 322873 |
| 39 | FRONT PANEL | 322880 |
| 40 | SPINDLE | 323000 |
| 41 | ARGON GAS BOTTLE IT ADAPTOR | 432036 |
| 42 | SPRING | 452138 |
| 43 | HANDLE | 641005 |
| 44 | BACK PANEL | 642020 |
| 45 | FRONT PANEL | 642021 |
| 46 | FRONT PANEL | 642085 |
| 47 | BACK PANEL | 642087 |
| 48 | TORCH HOOK | 644444 |
| 49 | BOTTOM | 645401 |
| 50 | BRAKET | 645406 |
| 51 | BOTTOM | 645447 |
| 52 | COVER | 651149 |
| 53 | COVER | 655963 |
| 54 | DOOR | 655964 |
| 55 | RIGHT SIDE PANEL | 656011 |
| 56 | LEFT SIDE PANEL | 656012 |
| 57 | BUSH | 681057 |
| 58 | WASHER | 681058 |
| 59 | TOLEDO 600 WORK CLAMP 600A | 712034 |
| 60 | SOCKET DX 70/95 | 712037 |
| 61 | PLUG DX 95 | 712088 |
| 62 | PLUG | 712112 |
| 63 | SOCKET DX 95 | 712096 |
| 64 | FEED ROLL D. 0,8-1 MM FE | 722227 |
| 65 | FEED ROLL D. 1,2-1,6 MM FE | 722241 |
| 66 | GAS REGULATOR 2 MANOMETERS | 722346 |
| 67 | MT40 MIG TORCH 3 M 500 A | 722798 |
| 68 | CABLE 70MMQ 3M-WORK CLAMP-DX 70 | 723032 |
| 69 | TORCH CONNECTION | 723067 |
| 70 | WIRE FEED ASSY | 723096 |
| 71 | ROLLERFIXING SCREW | 742397 |
| 72 | WIRE GUIDE INLET | 742064 |
| 73 | GEARBLOCKING SCREW | 742079 |
| 74 | WIRE GUIDE | 742121 |
| 75 | MOTOR DRIVE GEAR | 742155 |
| 76 | ADAPTER | 742166 |
| 77 | LEFT ANCHOR FOR PRESSURE ROLLER | 742167 |
| 78 | RIGHT ANCHOR FOR PRESSURE ROLLER | 742168 |
| 79 | GAS PIPE CONNECTOR KIT | 980548 |
| 80 | BLACK KNOB SET | 980772 |
| 81 | PANEL + CARD KIT | 981000 |
| 82 | INTERFACE CARD KIT | 980945 |
| 83 | PRIMARY PCB KIT | 981001 |
| 84 | INPUT FILTER CARD KIT | 980947 |
| 85 | POWER TRANSFORMER KIT | 981002 |
| 86 | SECONDARY PCB KIT | 981003 |
| 87 | INDUCTANCE CARD KIT | 981004 |
| 88 | PANEL + WIREFEEDER CARD KIT | 980952 |
| 89 | CONTROL PCB KIT | 980953 |
| 90 | KIT 10 DIODES | 981005 |
| 91 | FUSEHOLDER KIT | 990352 |
| 92 | CABLE BUSHING KIT | 990439 |
| 93 | KIT KNOB | 990661 |
| 94 | GAS HOSE KIT | 990873 |
| 95 | SWITCH KNOB SET | 323101 |
| 96 | COIL COVER KIT | 802595 |
| 97 | PLUG DX 70 | 712041 |
| TORCIA INVERPULSE 625 MIG/TIG/MMA 400V+ACC. 815490 Pag.2 | ||
| 1 | RING NUT | 722007 |
| 2 | LINER NUT | 722013 |
| 3 | WIRE GUIDE HOSE D. 1,2-1,6 MM 3 M | 722795 |
| 3 | WIRE GUIDE HOSE D. 1-1,2 MM 3 M | 722689 |
| 3 | WIRE GUIDE HOSE D. 1,6-2 MM 3 M AL | 722597 |
| 3 | WIRE GUIDE HOSE Ø 1,6-2MM 3M | 722814 |
| 3 | WIRE GUIDE HOSE D. 1-1,2 MM 3 M | 742164 |
| 4 | CONTACT TIP D. 1,6 MM FLUX | 722771 |
| 4 | CONTACT TIP D. 1,6 MM FE | 722587 |
| 4 | CONTACT TIP D. 1,2 MM FE | 722583 |
| 4 | CONTACT TIP D. 1,2 MM AL/FLUX | 722770 |
| 4 | CONTACT TIP D. 1 MM FE | 722582 |
| 4 | CONTACT TIP D. 2 MM AL/FLUX | 722772 |
| 4 | CONTACT TIP D.2,0 | 722586 |
| 4 | CONTACT TIP D. 0,8 MM FE | 722581 |
| 4 | CONTACT TIP D. 1 MM AL/FLUX | 722769 |
| 4 | CONTACT TIP D. 1 MM AL | 742159 |
| 4 | CONTACT TIP D. 1,2 MM AL | 742160 |
| 4 | CONTACT TIP D. 1,6 MM AL | 742161 |
| 5 | WIRE GUIDE LOCKING NIPPLES | 722598 |
| 5 | WIRE GUIDE LOCKING NIPPLES | 722599 |
| 6 | WIRE GUIDE LOCKING TUBE | 722600 |
| 7 | OR RING | 722601 |
| 7 | OR RING | 722606 |
| 8 | PUSHBUTTON | 722677 |
| 9 | SWAN NECK | 722801 |
| 10 | GAS DIFFUSER | 722802 |
| 14 | CONTACT TIP HOLDER | 722807 |
| 15 | CONICAL NOZZLE | 722808 |
| 15 | CYLINDRICAL NOZZLE | 722809 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Telwin INVERPULSE 625 - 815490
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM OR S/N CODE TELWIN:
- TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
