Telwin Parts for Inverter SUPERIOR TIG 311 DC-HF/LIFT 400V
TELWIN Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Inverter Welding SUPERIOR TIG 311 DC-HF/LIFT 400V - 816015
In the following table, look for the model of the Welding and the respective parts of the code.
| SUPERIOR TIG 311 DC-HF/LIFT 400V - 816015 Pag.1 | ||
| # | Part Num. | Description |
| 2 | 112048 | RESISTANCE |
| 4 | 112342 | RELAY ' |
| 5 | 981215 | BOARD KIT FILTER HF |
| 6 | 112514 | CAPACITOR |
| 7 | 116066 | RECTIFIER |
| 8 | 980732 | BOARD KIT HF |
| 9 | 120513 | WIRING CONTROL |
| 10 | 121006 | FUSE |
| 11 | 121029 | SOLENOID |
| 13 | 323101 | TOGETHER FOR SWITCH KNOB |
| 14 | 122508 | THERMOSTAT |
| 15 | 121523 | SWITCH |
| 17 | 123503 | WIRING INTAKE |
| 18 | 132026 | CABLE ALIM. 4G2.5 2 M |
| 20 | 152214 | FAN |
| 21 | 152231 | CURRENT TRANSFORMER TA |
| 22 | 152232 | TRANSFORMER PULSE |
| 23 | 980294 | KIT HF TRANSFORMER |
| 24 | 980160 | KIT TRANSFORMER |
| 25 | 322508 | FRAME - FRONT PANEL |
| 26 | 602052 | WATER CONNECTION |
| 27 | 322408 | BELT |
| 28 | 644793 | FUND |
| 29 | 981045 | KIT COAT |
| 30 | 712036 | SOCKET DX 50 |
| 31 | 990046 | GLAND NUT KIT + |
| 32 | 990120 | CONNECTION KIT INLET GAS |
| 33 | 990287 | DATA ENTRY FILTER KIT |
| 34 | 990298 | BOARD KIT PRIMARY |
| 35 | 990328 | KIT WHEEL |
| 36 | 980164 | KIT FORM SECONDARY |
| 37 | 990609 | KIT + TRANSFORMER INDUCTANCE |
| 38 | 980411 | KIT CONTROL BOARD |
| 39 | 980165 | KIT 5 DIODES 400V 150A |
| 40 | 990625 | KIT IGBT |
| 41 | 322065 | BUCKLE FOR BELT |
| TORCH FOR SUPERIOR TIG 311 DC-HF/LIFT 400 - 816015 Pag.2 | ||
| 1 | 802247 | KIT 10 CERAMIC NOZZLES NR.8 |
| 1 | 802248 | KIT 10 CERAMIC NOZZLES NR.10 |
| 1 | 802245 | KIT 10 CERAMIC NOZZLES NR.6 |
| 1 | 802246 | KIT 10 CERAMIC NOZZLES NR.7 |
| 1 | 802244 | KIT 10 CERAMIC NOZZLES NR.4 |
| 2 | 722248 | INSULATION |
| 4 | 802222 | KIT 10 ELETTR.TUNGSTENO CERIUM D.1,6 MM |
| 4 | 802233 | KIT 10 ELETTR.TUNGSTENO CERIUM D.3,2 MM |
| 4 | 802220 | KIT 10 ELETTR.TUNGSTENO CERIUM D.1 MM |
| 4 | 802235 | KIT 10 ELETTR.TUNGSTENO PURE D.1,6 MM |
| 4 | 802236 | KIT 10 ELETTR.TUNGSTENO PURE D.2,4 MM |
| 4 | 802238 | KIT 10 ELETTR.TUNGSTENO PURE D. 4 MM |
| 4 | 802232 | KIT 10 ELETTR.TUNGSTENO CERIUM D.2,4 MM |
| 4 | 802237 | KIT 10 ELETTR.TUNGSTENO PURE D.3,2 MM |
| 5 | 802241 | KIT 3 CLAMP ELECTRODE D.2,4 MM SERRA |
| 5 | 802240 | KIT 3 CLAMP ELECTRODE D.1,6 MM SERRA |
| 5 | 802239 | KIT 3 CLAMP ELECTRODE D.1,0 MM SERRA |
| 5 | 802243 | KIT 3 CLAMP ELECTRODE D.4 MM SERRA |
| 5 | 802242 | KIT 3 CLAMP ELECTRODE D.3,2 MM SERRA |
| 6 | 722192 | HOOD SHORT |
| 7 | 722193 | HOOD LONG |
| 9 | 981443 | KIT CONNECTION 50 |
| 12 | 722999 | PLUG 3P |
| 14 | 452089 | CONTACT BUTTON |
| 16 | 722061 | RING OR |
| 17 | 742042 | BUTTON |
| 18 | 722944 | BODY TORCH |
| 19 | 802250 | KIT 3 SPEAKER ELECTRODE D.1,6 MM |
| 19 | 802251 | KIT 3 SPEAKER ELECTRODE D.2,4 MM |
| 19 | 802253 | KIT 3 SPEAKER ELECTRODE D.4 MM |
| 19 | 802252 | KIT 3 SPEAKER ELECTRODE D.3,2 MM |
| 19 | 802249 | KIT 3 SPEAKER ELECTRODE D.1 MM |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
