Telwin Spare Parts for Flux Welding Mastermig 300 - 827003
Telwin authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for welding machine Flux and Mig-mag Mastermig 300 - 827003.In the following table, look for the model of the welding machine and theirs spare parts codes.
| MASTERMIG 300 230-400V key 827003 Pag.1 | ||
| # | Description | Part Num. |
| 1 | RECTIFIER | 112170 |
| 2 | CHANGING VOLTAGE CARD | 112165 |
| 3 | RECTIFIER PROTECTION | 112182 |
| 4 | POTENTIOMETER | 112363 |
| 5 | POTENTIOMETER - 113574 | 112380 |
| 6 | TIMER CONTROL PCB KIT | 980714 |
| 7 | CONTACTOR | 122585 |
| 8 | SWITCH | 122517 |
| 9 | YELLOW PILOT LAMP | 122594 |
| 10 | ELECTRO-VALVE | 122682 |
| 11 | SWITCH | 122725 |
| 12 | THERMOSTAT | 122132 |
| 13 | SWITCH | 122802 |
| 14 | FUSE | 122879 |
| 15 | MAINS CABLE 4G2.5 2 M | 132244 |
| 16 | MOTOR | 152083 |
| 17 | FAN BLADE | 152113 |
| 18 | WIRE FEED MOTOR | 153033 |
| 19 | TRANSFORMER | 164089 |
| 20 | AUXILIARY TRANSFORMER | 164991 |
| 21 | REACTANCE | 169339 |
| 22 | TORCH CONNECTION PROTECTION | 312105 |
| 23 | REEL HANDWHEEL | 312137 |
| 24 | HANDLE KIT | 980082 |
| 25 | REEL | 322081 |
| 26 | SPACER | 322180 |
| 27 | WHEEL + SWIVEL SUPPORT | 322187 |
| 28 | WHEEL | 322772 |
| 29 | FRAME | 322736 |
| 30 | SWITCH KNOB SET | 323101 |
| 31 | WHEELS AXLE | 422020 |
| 32 | ARGON GAS BOTTLE IT ADAPTOR | 432036 |
| 33 | REEL SPRING | 452057 |
| 34 | TORCH HOOK | 644444 |
| 35 | BOTTLE HOLDER | 644447 |
| 36 | WIRE FEED HANDLE | 644449 |
| 37 | BOTTOM | 645102 |
| 38 | BACK PANEL | 645103 |
| 39 | DIAPHRAGM | 645105 |
| 40 | FRONT PANEL | 649768 |
| 41 | SIDE PANEL | 645236 |
| 42 | SIDE PANEL | 651059 |
| 43 | BOTTOM | 645235 |
| 44 | BACK PANEL | 645419 |
| 45 | DOOR KIT | 980918 |
| 46 | COVER KIT | 980866 |
| 47 | FRONT PANEL | 649829 |
| 48 | TOLEDO 300 WORK CLAMP | 712231 |
| 49 | SOCKET DX 50 | 712036 |
| 50 | PLUG DX 50 | 712040 |
| 51 | FEED ROLL D. 0,6-0,8 MM FE | 722225 |
| 52 | FEED ROLL D. 0,8-1 MM FE | 722227 |
| 53 | GAS REGULATOR 2 MANOMETERS | 722119 |
| 54 | WIRE CONDUIT Ø 2X5 | 742365 |
| 55 | TORCH CONNECTION | 723229 |
| 56 | CABLE 25MMQ 3M-WORK CLAMP-DX 50 | 713192 |
| 57 | WIRE FEED ASSY | 723198 |
| 58 | ROLLERFIXING SCREW | 742397 |
| 59 | MT25 MIG TORCH 3 M 270 A | 742183 |
| 60 | FEED ROLL D. 0,8-1 AL | 742304 |
| 61 | WIRE GUIDE INLET | 742064 |
| 62 | LEFT ANCHOR FOR PRESSURE ROLLER | 742307 |
| 63 | RIGHT ANCHOR FOR PRESSURE ROLLER | 742308 |
| 64 | 8 PIN PLUG KIT | 990226 |
| 65 | REEL KIT | 990264 |
| 66 | SWITCH KNOB KIT | 990328 |
| 67 | SOCKET KIT | 990330 |
| 68 | GAS HOSE KIT | 990097 |
| 69 | WHEEL CAP | 322773 |
| 70 | FEED ROLL D. 1,2-1,6 MM FE | 722241 |
| 71 | FEED ROLL D. 1-1,2 MM FE | 742366 |
| 72 | COVER | 322814 |
| 73 | ADAPTER | 742166 |
| 74 | MOTOR DRIVE GEAR | 742348 |
| 75 | GEAR | 742495 |
| TORCH MASTERMIG 300 230-400V Pag.2 | ||
| 1 | RING NUT | 722007 |
| 2 | LINER NUT | 722013 |
| 3 | TORCH CONNECTION | 742175 |
| 4 | CONTACT TIP D. 0,8 MM FE | 722680 |
| 4 | CONTACT TIP D. 0,6 MM FE | 722415 |
| 4 | CONTACT TIP D. 1 MM FE | 722681 |
| 4 | CONTACT TIP D. 1 MM AL/FLUX | 722552 |
| 4 | CONTACT TIP D. 1,2 MM FE | 722682 |
| 4 | CONTACT TIP D. 1,2 MM AL/FLUX | 722553 |
| 5 | WIRE GUIDE HOSE D. 0,6-0,8 MM 3 M | 722437 |
| 5 | WIRE GUIDE HOSE D. 1-1,2 MM 3 M | 722689 |
| 5 | WIRE GUIDE HOSE D. 1-1,2 MM 3 M AL | 722516 |
| 6 | CONICAL NOZZLE | 722685 |
| 6 | CYLINDRICAL NOZZLE | 722684 |
| 6 | THIN HEADED NOZZLE | 722686 |
| 6 | SPOT WELDING NOZZLE D. 18 MM | 722687 |
| 7 | WIRE GUIDE LOCKING NIPPLES | 722598 |
| 8 | OR RING | 722601 |
| 8 | OR RING | 722606 |
| 10 | WIRE GUIDE LOCKING TUBE | 722600 |
| 11 | GAS DIFFUSER | 722688 |
| 13 | NOZZLE SPRING | 722690 |
| 15 | TORCH CONNECTION INSULATION | 722693 |
| 16 | SWAN NECK | 722696 |
| 17 | TORCH ASSY | 722441 |
| 18 | TORCH RING NUT | 742171 |
| 19 | TORCH HOLDER + SPRING | 742173 |
| 20 | TORCH SPRING | 742174 |
