Tanaka Spare Parts for Hedge Trimmer THT-2530
€1.11
Tax included
Tanaka Spare Parts for Hedge Trimmer THT-2530
Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Engine Edge Trimmer THT-2530.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Hedge Trimmer THT-2530
Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Engine Edge Trimmer THT-2530.
In the following table, look for the model of the Edge Trimmer and the respective parts of the code.
| Hedge Trimmer THT-2530 | ||
| # | Part Num. | Description |
| 1 | 6687476 | SPARK PLUG CAP |
| 3 | 6685481 | CYLINDER ASS'Y |
| 4 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 4A | 6684668 | HEX.HOLE BOLT M5X20/S |
| 5 | 6685744 | CYLINDER GASKET |
| 6 | 6684588 | PISTON RING |
| 7 | 6685893 | PISTON ASS'Y |
| 8 | 6684591 | PISTON PIN |
| 9 | 6686028 | PISTON PIN CIRCLIP |
| 10 | 6686205 | CRANK SHAFT COMP. |
| 11 | 6695927 | IGNITION COIL ASS'Y |
| 13 | 6684597 | INSULATOR TUBE 50L |
| 15 | 6695939 | IGNITION COIL COMP |
| 22 | 6686720 | CRANK CASE GASKET |
| 25 | 6689177 | GEAR SHAFT SHIM 0.10 |
| 25 | 6689178 | GEAR SHAFT SHIM 0.15 |
| 25 | 6684604 | GEAR SHAFT SHIM 0.20 |
| 27 | 6684786 | HEX. SOCKET HD. BOLT M5X30 S |
| 28 | 6687389 | MAGNETO ROTOR COMP. |
| 29 | 6684611 | BOLT WASHER M8 |
| 30 | 6684971 | S.WASHER 8 |
| 32 | 6686771 | STUD BOLT 6X22 |
| 41 | 6689891 | INTAKE PIPE GASKET |
| 42 | 6689966 | CARB. INSULATOR SET,SPARE |
| 43 | 6695515 | HEX. HOLE BOLT 5X25WS |
| 44 | 6689839 | CARBURETOR GASKET |
| 46 | 6690119 | CLEANER BODY COMP. |
| 47 | 6690804 | COLLAR 7.5 |
| 48 | 6691274 | CHOKE VALVE |
| 48A | 6691272 | CHOKE VALVE |
| 48B | 6691274 | CHOKE VALVE |
| 49 | 6684658 | WAVE WASHER 8 |
| 50 | 6690843 | BLOW OVER CHECK BOARD |
| 51 | 6684662 | S.WASHER 5 |
| 52 | 6684660 | SCREW M5X60 |
| 53 | 6690364 | CLEANER SPONGE |
| 54 | 6690417 | CLEANER COVER ASS'Y |
| 55 | 6689737 | SPECIAL SCREW |
| 56B | 6690487 | CARBURETOR SET, WYL120 |
| 57 | 6685247 | SHIELD TUBE |
| 58 | 6685198 | CLIP D6 |
| 60 | 6697631 | TANK WHT |
| 60A | 6691582 | TANK WHT |
| 61 | 6692244 | COLLAR 5.8 |
| 62 | 6695505 | HEX. HOLE BOLT 5X18PS |
| 63 | 6691337 | SWIVEL CAP |
| 64 | 6691763 | TANK CAP D ASS'Y, BLACK |
| 65 | 6685139 | PRIMING PUMP COMP. |
| 66 | 6692347 | FUEL PIPE 2.5X4X80 |
| 67 | 6692346 | FUEL PIPE 2.5X4X70 |
| 68 | 6697846 | RETURN GROMMET |
| 71 | 6691272 | CHOKE VALVE |
| 81 | 6692799 | MUFFLER PROTECTOR |
| 82 | 6692744 | MUFFLER GASKET |
| 83 | 6687252 | HEAT SHIELD |
| 84 | 6692477 | MUFFLER ASS'Y |
| 85 | 6684661 | WASHER 5 |
| 86 | 6685114 | HEX. SOCKET HD. BOLT M5X50 |
| 87 | 6687010 | FAN CASE COMP., VERMILION |
| 88 | 6684675 | RECOIL SPRING |
| 89 | 6693066 | STARTER ROPE REEL |
| 90 | 6693633 | SET SCREW |
| 91 | 6693405 | STARTER PULLEY ASS'Y |
| 92 | 6688050 | GROMMET |
| 93 | 6693168 | ROPE |
| 94 | 6693237 | STARTER HANDLE |
| 95 | 6684682 | HEX. HOLE BOLT 4X15/PS |
| 96 | 6688494 | CLUTCH |
| 97 | 6684636 | TAPPING SCREW D4.5X16 |
| 98 | 6695441 | BOLT 4X12PS |
| 99 | 6684684 | STARTER PAWL SPRING |
| 100 | 6693319 | STARTER PAWL |
| 111 | 6684698 | THROTTLE SET SCREW |
| 112 | 6684697 | SWIVEL |
| 113 | 6684696 | STOP RING |
| 114 | 6684883 | THROTTLE VALVE |
| 115 | 6684695 | O-RING |
| 116 | 6691885 | MAIN JET #41.5 |
| 117 | 6691457 | PUMP GASKET |
| 118 | 6684693 | PUMP DIAPHRAGM |
| 119 | 6684700 | INLET SCREEN |
| 120 | 6691432 | PUMP BODY COMP. |
| 121 | 6690837 | DIAPHRAGM GASKET |
| 121A | 6685220 | DIAPHRAGM PACKING-METERING |
| 122 | 6690827 | METERING DIAPHRAGM COMP. |
| 124 | 6691312 | SET SCREW |
| 131 | 6688672 | GEAR CASE A |
| 132 | 6695294 | RETAINING RING C-TYPE D26 |
| 134 | 6695526 | BALL BEARING #6000Z, 26MM/OD |
| 135 | 6688571 | CLUTCH HOUSING COMP. |
| 137A | 6688978 | GEAR 2 |
| 138 | 6686810 | CAM-ROD COMP. |
| 140 | 6688910 | GEAR CASE GASKET |
| 141 | 6684738 | BALL BEARING #608,22MM/OD |
| 142 | 6686655 | GREASE SEAL A |
| 143 | 6688293 | COLLAR |
| 144 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 145 | 6688643 | GREASE NIPPLE COMP. |
| 146 | 6695495 | HEX. HOLE BOLT 6X18/S |
| 147 | 6695079 | HEX HOLE BUTTON SCREW 6X15 |
| 148 | 6695183 | SMALL WASHER 6 |
| 149 | 6686467 | FIXING PLATE |
| 151 | 6685093 | HEX. SOCKET HD. BOLT M4X10 |
| 154 | 6695219 | S.WASHER 6 |
| 171A | 6687151 | CUTTER GUIDE 830L M6 |
| 172 | 6687287 | PROTECTION PLATE |
| 172A | 6687288 | PROTECTION PLATE |
| 172A | 6687288 | PROTECTION PLATE |
| 174 | 6684822 | SPECIAL WASHER B |
| 175 | 6687113 | CUTTER B 852L |
| 176 | 6687091 | CUTTER A |
| 177 | 6687187 | WASHER 7 BLACK |
| 178 | 6687160 | CUTTER FIXING BOLT A |
| 178A | 6687158 | FIXING BOLT A M6 |
| 179 | 6687181 | BLADE HOLDER |
| 179A | 6687180 | BLADE HOLDER |
| 180 | 6687167 | CUTTER FIXING BOLT B |
| 180A | 6687168 | FIXING BOLT B M6 |
| 181 | 6686311 | HANDLE B COMP. |
| 182A | 6684708 | HANDLE GRIP |
| 183 | 6687156 | CUTTER FIXING NUT |
| 183A | 6695170 | FLANGE NUT 6 |
| 184 | 6684639 | BOLT WASHER 6 |
| 185 | 6695219 | S.WASHER 6 |
| 186 | 6684639 | BOLT WASHER 6 |
| 187A | 6687308 | CUTTER COVER, L-773 |
| 203 | 6688229 | THROTTLE LEVER |
| 204 | 6688238 | SAFETY LEVER |
| 206 | 6687758 | STOP SWITCH COMP. |
| 207 | 6694585 | STOP BUTTON MARK |
| 208 | 6692681 | PUSH PIN CAP |
| 208A | 6693002 | CAP |
| 211A | 6686354 | HANDLE GRIP ASS'Y |
| 212 | 6686275 | HANDLE A COMP. |
| 213 | 6693877 | THROTTLE WIRE 270+49 |
| 217 | 6684913 | SCREW 3X10 |
| 218 | 6688366 | BUTTON STOP |
| 220 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 222 | 6686396 | HANDLE DUMPER RUBBER |
| 224 | 6686447 | STOPPER SPRING |
