Tanaka Spare Parts for Chainsaw TCS-3301S
€1.68
Tax included
Tanaka Spare Parts for Chainsaw TCS-3301S
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw TCS-3301S.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Chainsaw TCS-3301S
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw TCS-3301S.
In the following table, look for the model of the Chainsaw and the respective parts of the code.
| Chainsaw TCS-3301S | ||
| # | Part Num. | Description |
| 1 | 6687468 | SPARK PLUG CAP ASS'Y |
| 3 | 6685457 | CYLINDER SET |
| 4 | 6685724 | CYLINDER GASKET |
| 5 | 6685879 | PISTON SET |
| 6 | 6685078 | CIRCLIP |
| 7 | 6685331 | PISTON RING (XR1-1856) |
| 8 | 6686008 | PISTON PIN |
| 9 | 6684903 | HEX. HOLE BOLT M5X16/S |
| 10 | 6686171 | CRANKSHAFT |
| 11 | 6695592 | NEEDLE BEARING |
| 12 | 6687700 | IGNITION COIL COMP. |
| 14 | 6695407 | HIGH TENSION SCREW 4X18WS |
| 15 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 16 | 6692900 | CORD INSULATOR TUBE |
| 23 | 6685096 | BALL BEARING 6201 A2C3 |
| 25 | 6684668 | HEX.HOLE BOLT M5X20/S |
| 27 | 6685101 | D4E RETAINING RING |
| 28 | 6685105 | STARTER PAWL SPRING |
| 29A | 6685334 | STARTER PAWL |
| 30 | 6685103 | BOLT WASHER M7 |
| 31 | 6685104 | FLYWHEEL NUT |
| *32 | 6685098 | SHIM S T0.2 |
| *32 | 6685099 | SHIM S T0.3 |
| *32 | 6686475 | SHIM 0.4 |
| 33 | 6695222 | S.WASHER 7 |
| 40 | 6691365 | ENGINE CASE ASS'Y, VERMILION |
| 41 | 6685173 | AIR VENT VALVE (B) |
| 42 | 6697231 | AIR VENT VALVE SET |
| 43 | 6684634 | HEX.HOLE BOLT 5X20/PS |
| 44 | 6697602 | EARTH CORD 90M |
| 50 | 6686299 | AIRCLEANER COVER A SET, SPARE |
| 51 | 6689735 | CLEANER COVER BOLT |
| 52 | 6690064 | AIRCLEANER ELEMENT COMP. |
| 53 | 6689934 | CARBURETOR INSULATOR SET,SPARE C091000 |
| 53A | 6689935 | INSULATOR SET C091001 |
| 54 | 6689870 | INLET MANIFOLD GASKET |
| 54A | 6689871 | INSULATOR GASKET |
| 55 | 6690001 | CARBURETOR INSULATOR RUBBER |
| 56 | 6689805 | REED VALVE HOLDER |
| 56A | 6689806 | VALVE HOLDER |
| 57 | 6689802 | REED VALVE |
| 57A | 6689803 | REED VALVE |
| 60A | 6690667 | CARBURETOR SET,WT-760 |
| 61 | 6695350 | SCREW 5X45S |
| 63 | 6684864 | SMALL WASHER 5 |
| 66 | 6687344 | AIRCLEANER COVER B |
| 67 | 6684668 | HEX.HOLE BOLT M5X20/S |
| 68 | 6684864 | SMALL WASHER 5 |
| 69 | 6685224 | IDLE SPONGE |
| *70 | 6687978 | SPONGE H/L 10L |
| *70 | 6687978 | SPONGE H/L 10L |
| 71 | 6690355 | AIRCLEANER SPONGE |
| 72 | 6687182 | SEAL COVER |
| *81 | 6692447 | MUFFLER SET |
| 82 | 6692734 | MUFFLER GASKET |
| *83 | 6692626 | MUFFLER BODY B COMP. |
| 85 | 6692833 | MUFFLER COUPLING GASKET |
| 87 | 6695054 | HEX. HOLE BOLT 5X40 |
| 88 | 6684661 | WASHER 5 |
| 92 | 6692734 | MUFFLER GASKET |
| 94 | 6692833 | MUFFLER COUPLING GASKET |
| 98 | 6684661 | WASHER 5 |
| 99 | 6694906 | SCREW 5X40 |
| 101 | 6691121 | OIL PIPE B |
| 102 | 6692312 | CLIP 7 |
| 103 | 6684661 | WASHER 5 |
| 104 | 6690919 | OIL FILTER |
| 105 | 6685249 | OIL FILTER BODY ASS'Y |
| 106 | 6690974 | THROTTLE ROD |
| 107 | 6690982 | THROTTLE GUIDE |
| 108 | 6685139 | PRIMING PUMP COMP. |
| 110 | 6692292 | RUBBER PIPE |
| 113 | 6697846 | RETURN GROMMET |
| *115 | 6687956 | ADJUSTER CAP |
| *115 | 6687957 | ADJUSTER CAP |
| 116 | 6692590 | GROMMET |
| 117 | 6692513 | CHOKE BUTTON COMP. |
| 118 | 6687976 | GROMMET |
| 120 | 6692159 | OIL TANK CAP ASS'Y |
| 121 | 6692121 | TANK CAP ASS'Y |
| 131 | 6692909 | RECOIL STARTER ASS'Y OR |
| 132 | 6686950 | FAN CASE COMP. OR |
| 134 | 6693168 | ROPE |
| 135 | 6693138 | RECOIL SPRING |
| 136 | 6693094 | SPRING CASE ASS'Y |
| 137 | 6693061 | STARTER PULLEY |
| 138 | 6687947 | SPECIAL WASHER 5.2X15 |
| 139 | 6685275 | TAPPING SCREW D5X14 |
| 140 | 6685191 | TAPPING SCREW D4.5X20 |
| 141 | 6687326 | AIR DEFLECTOR |
| 143 | 6693230 | STARTER HANDLE |
| 145 | 6685183 | DAMPER SPRING |
| 146 | 6685185 | SPRING CASE SET |
| 147 | 6685184 | STARTER PULLEY |
| 148 | 6684679 | SET SCREW |
| 149 | 6685182 | CAM PLATE |
| 161 | 6684700 | INLET SCREEN |
| 163 | 6685210 | SCREW |
| 164 | 6685212 | PUMP GASKET |
| 165 | 6685213 | PUMP DIAPHRAGM |
| 167 | 6692048 | HIGH/LOW ADJUST SPRING |
| 168 | 6685217 | CONTROL LEVER |
| 169 | 6685218 | HINGE PIN SET SCREW |
| 171 | 6685219 | HINGE PIN |
| 173 | 6690827 | METERING DIAPHRAGM COMP. |
| 174 | 6685220 | DIAPHRAGM PACKING-METERING |
| 175 | 6685215 | NEEDLE VALVE |
| 176 | 6685297 | IDLE ADJUST SPRING |
| 177 | 6685298 | IDLE ADJUST SCREW |
| 179 | 6690897 | HIGH ADJUSTMENT SPRING |
| 180 | 6685223 | SET SCREW |
| 192 | 6686763 | OIL PUMP COVER |
| 193 | 6691223 | OIL PIPE A |
| 194 | 6686645 | SCREW GEAR |
| 195 | 6691400 | AIR VENT SPONGE |
| 196 | 6687324 | OIL PUMP ASS'Y |
| 197 | 6690956 | OIL ADJUST GROMMET |
| 198 | 6691070 | OIL PUMP ADJUSTER |
| 200 | 6686681 | OIL PUMP CASE SET, SPARE |
| 202 | 6685275 | TAPPING SCREW D5X14 |
| 203 | 6685154 | FUEL PIPE |
| 204 | 6685155 | CHAIN CATCHER |
| 221 | 6685166 | NUT |
| 221A | 6687105 | CHAIN BAR CLAMP NUT |
| 222 | 6685142 | CLUTCH COMP. |
| 223 | 6685143 | NEEDLE BEARING |
| 224 | 6685144 | CLUTCH HOUSING COMP. |
| 225 | 6685145 | CLUTCH WASHER |
| 226 | 6685161 | TAPPING SCREW D4X10 |
| 227 | 6690790 | PLATE |
| 228 | 6685146 | CRANK SHAFT COLLAR |
| 229 | 6685161 | TAPPING SCREW D4X10 |
| 231 | 6690756 | GUIDE PLATE B |
| 234 | 6685168 | GEAR (A) |
| 235 | 6697958 | BRAKE HANDLE COMP. |
| 236 | 6689712 | BRAKE LINK COVER, BLACK |
| 238 | 6685119 | BRAKE SUPPORT PLATE COMP. |
| 239 | 6685141 | NEEDLE ROLLER 3X9.8 |
| 240 | 6685388 | BRAKE LINK |
| 241 | 6689728 | BRAKE BAND |
| 242 | 6690805 | CLEANER FIXING COLLAR |
| 243 | 6685120 | COLLAR |
| 245 | 6685122 | BRAKE LEVER SPRING |
| 246 | 6685148 | TAPPING SCREW D4X15 |
| 247 | 6687071 | TENSION ADJUSTMENT BOLT ASS'Y |
| 262 | 6695108 | TAPPING SCREW 5X40 |
| 263 | 6688480 | DAMPER COLLAR A |
| 264 | 6688117 | DAMPER A |
| 266 | 6685645 | REAR HANDLE B COMP. |
| 267 | 6692680 | PUSH PIN CAP |
| 268 | 6686447 | STOPPER SPRING |
| 269 | 6686430 | PUSH PIN |
| 270 | 6688363 | TRIGGER LOCKOUT VERMILION |
| 271 | 6686392 | THROTTLE LEVER |
| 272 | 6686416 | THROTTLE LEVER SPRING |
| 273 | 6685620 | REAR HANDLE |
| 274 | 6695107 | TAPPING SCREW 5X35 |
| 275 | 6685148 | TAPPING SCREW D4X15 |
| 276 | 6688083 | FRONT HANDLE |
| 277 | 6688412 | DAMPER B |
| 278 | 6688485 | DAMPER COLLAR B |
| 279 | 6695107 | TAPPING SCREW 5X35 |
| 502 | 6685256 | CHAIN COVER 14" |
| 505 | 6686632 | 4X50 MINUS DRIVER |
| 506 | HGA781234 | Bar + Chain Set cm 35 14'' - 3/8'' LP - 52 M. 1,3 mm/0.50'' |
