Stiga Parts for Ion Battery Lawnmower COMBI 40 AE
€1.74
Tax included
Stiga Parts for Ion Battery Lawnmower COMBI 40 AE
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Ion Battery Lawnmower COMBI 40 AE - 294385068.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Stiga Parts for Ion Battery Lawnmower COMBI 40 AE
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Ion Battery Lawnmower COMBI 40 AE - 294385068/S15-2015.
In the following table, look for the model of the Lawnmower and the respective parts of the code.
| Battery Lawnmower COMBI 40 AE - 294385068/S15-2015 | ||
| Chassis And Cutting Height Adjustment Pag.1 | ||
| # | Part Num. | Description |
| 1 | 322066783/0 | Gray STIGA Chassis |
| 2 | 322785387/0 | Wheel Support |
| 2 | 322785450/0 | Wheel Support |
| 3 | 322686105/0 | Wheel |
| 4 | 322110684/0 | Gray hubcap |
| 5 | 112604903/0 | Washer |
| 6 | 122033425/0 | Rear Wheel Axle |
| 7 | 322545142/0 | Plate |
| 8 | 112728714/0 | Screw |
| 9 | 322785414/0 | Height Adjustment Lever |
| 9 | 322785414/1 | Height Adjustment Lever |
| 9 | 322785414/2 | Height Adjustment Lever |
| 10 | 322524354/0 | Pin |
| 11 | 122446195/0 | Spring |
| 12 | 322869680/0 | Height Adjustment Control Rod |
| 12 | 322869690/0 | Height Adjustment Control Rod from 01-September-2014 |
| 13 | 322785415/0 | Plate |
| 14 | 122033424/0 | Rear Wheel Axle |
| 15 | 322785386/0 | Wheel Support |
| 15 | 322785438/0 | Wheel Support |
| 16 | 322686104/0 | Wheel |
| 17 | 322110683/0 | Gray hubcap |
| 18 | 322785385/0 | Wheel Support |
| 18 | 322785449/0 | Wheel Support |
| Chassis Pag.2 | ||
| 1 | 322055252/0 | Front plate |
| 2 | 322055528/0 | Yellow Hood |
| 3 | 322109565/0 | Left Side Cover |
| 4 | 322109899/0 | Right side cover |
| 5 | 112728714/0 | Screw |
| 6 | 122450470/0 | Spring |
| 7 | 322524356/0 | Pin |
| 8 | 322600288/0 | Stoneguard Gray |
| 9 | 322486393/0 | Bag, Lower Side Right |
| 10 | 322486394/0 | Bag, Lower Side Left |
| 11 | 322486323/0 | Bag, Upper Side |
| 12 | 322393718/0 | Handle |
| 13 | 322393719/0 | Handle |
| 17 | 322076570/1 | Key Security Battery |
| 18 | 322140242/0 | Mulching cap |
| 19 | 322545222/0 | Plate |
| 20 | 322055165/0 | Cover |
| 21 | 122450473/0 | Spring |
| 22 | 113300215/0 | Scraper |
| 23 | 122450472/0 | Spring |
| 24 | 322524355/0 | Pin |
| 25 | 118210028/0 | Security Key Kit |
| Upper Half Handle Pag.3 | ||
| 1 | 322291032/0 | Upper Half Handle |
| 1 | 322291034/0 | Upper Half Handle |
| 1 | 322291034/1 | Upper Half Handle |
| 1 | 322291070/0 | Upper Half Handle |
| 2 | 381600524/0 | Motor protection |
| 2 | 381600524/1 | Motor protection |
| 2 | 381600557/0 | Motor protection |
| 3 | 322291033/0 | Lower Half Handle |
| 3 | 322291035/0 | Lower Half Handle |
| 3 | 322291071/0 | Lower Half Handle |
| 4 | 112728713/0 | Screw |
| 5 | 381007514/1 | Handle, Upper Side |
| 5 | 381007515/0 | Handle, Lower Side |
| 6 | 122192000/1 | Clamp |
| 7 | 112523050/0 | Washer |
| 8 | 122524352/0 | Pin |
| 9 | 322319519/0 | Handle Fix Lever |
| 9 | 322319519/1 | Handle Fix Lever |
| 10 | 122943016/0 | Screw |
| 11 | 322246100/0 | Joint |
| 11 | 322246102/0 | Joint |
| 12 | 122430210/0 | Bearing |
| 13 | 322745052/0 | Right Joint |
| 13 | 322745055/0 | Right Joint |
| 14 | 112728714/0 | Screw |
| 15 | 322745051/0 | Left Joint |
| 15 | 322745056/0 | Left Joint |
| 16 | 122943017/0 | Screw |
| 18 | 118566112/0 | Polyethylene tip |
| 19 | 381007513/0 | Handle, Lower Side |
| 20 | 381007514/0 | Handle, Lower Side right |
| 20 | 381007514/1 | Handle, Upper Side |
| 21 | 112521320/0 | Washer |
| Blade Pag.4 | ||
| 1 | 381004352/1 | Screw |
| 2 | 181004156/0 | Blade |
| 2 | 181004162/0 | Blade |
| 3 | 322465644/0 | Hub |
| 3 | 322465644/1 | Hub |
| 4 | 112728699/0 | Screw |
| 5 | 322207227/0 | Cable clip |
| 6 | 118563516/0 | Motor Battery |
| 6 | 118563516/1 | Motor Battery |
| 6 | 118563516/2 | Motor Battery |
| 7 | 118206003/0 | Controller |
| 7 | 118206008/0 | Controller |
| 8 | 112728714/0 | Screw |
| 9 | 322393686/0 | Engine Flange Left Battery |
| 10 | 322393685/0 | Motor Battery Flange Right |
| Battery Pag.5 | ||
| 1 | 270482518/S15 | 48V battery - 2.5Ah |
| 1 | 270485018/S15 | 48V battery - 5Ah |
| 2 | 270480028/S15 | 48V Battery Charger - EU plug |
| 2 | 270480128/S16 | 48V Rapid Battery Charger - EU plug |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stiga websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stiga brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
COMBI 40 AE - 294385068/S15-2015
