Stiga Spare Parts for Edgetrimmer SHP 60
€1.41
Tax included
Stiga Spare Parts for Hedgetrimmer SHP 60
Distribution and Sale at attractive prices of STIGA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Hedgetrimmer SHP 60/252961002-14-2017.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Stiga Spare Parts for Hedgetrimmer SHP 60
Distribution and Sale at attractive prices of STIGA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Hedgetrimmer SHP 60/252961002-14-2017.
In the following table, look for the model of the Edgetrimmer and the respective parts of the code.
| Hedgetrimmer SHP 60/252961002-14-2017 Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 123120012/0 | Nut |
| 2 | 123878109/0 | Screw |
| 3 | 183082003/0 | Starter Cup |
| 7 | 118802744/0 | Flywheel |
| 8 | 123878081/0 | Screw |
| 9 | 123657017/0 | Washer |
| 10 | 123657013/0 | Washer |
| 11 | 119035164/0 | Seal Ring |
| 12 | 112610003/0 | Snap Ring |
| 13 | 123685020/0 | Crank Case |
| 14 | 114215222/0 | Ball Bearing |
| 16 | 123753003/0 | Pin |
| 17 | 123280077/0 | Crankcase Gasket |
| 18 | 123685021/0 | Crank Case |
| 19 | 119035165/0 | Seal Ring |
| 20 | 123657019/0 | Washer |
| 21 | 123445268/0 | Hub |
| 23 | 183215010/0 | Clutch Ass.Y |
| 25 | 123878111/0 | Screw |
| 26 | 123065045/0 | Spark Plug Cable |
| 27 | 123878081/0 | Screw |
| 28 | 123657013/0 | Washer |
| 29 | 123657017/0 | Washer |
| 30 | 118802743/0 | Ignition Ass'Y |
| 31 | 123160063/0 | Spacer |
| 32 | 123652505/0 | Washer |
| 33 | 123235008/0 | Needle Bearing |
| 34 | 183590007/0 | Piston Assy |
| 37 | 123204016/0 | Piston Ring |
| 38 | 123280078/0 | Cilynder Gasket |
| 39 | 123878081/0 | Screw |
| 40 | 118802742/0 | Muffler |
| 41 | 123280079/0 | Muffler Gasket |
| 42 | 123600078/0 | Guard |
| 44 | 123071023/0 | Cilynder |
| 45 | 123280080/0 | Intake Manifold Gasket |
| 46 | 123120013/0 | Nut |
| 47 | 118801419/0 | Intake Manifold |
| 48 | 112789195/0 | Screw |
| 49 | 118801420/0 | Spark Plug Cover |
| 50 | 123600080/0 | Cylinder Cover |
| 51 | 118801421/0 | Carburetor Gasket |
| 52 | 118801422/0 | Carburetor |
| 53 | 118801423/0 | Air Cleaner Base |
| 54 | 123878114/0 | Screw |
| 55 | 118801424/0 | Air Filter Element |
| 56 | 118801425/0 | Air Cleaner Cover,Yellow |
| 57 | 118802164/0 | Choke Lever, Black |
| Edgetrimmer SHP 60/252961002-14-2017 Engine Pag.2 | ||
| 1 | 123300014/0 | Front Handle |
| 2 | 123878121/0 | Screw |
| 3 | 118801428/0 | Muffler Cover,Yellow |
| 4 | 123430606/0 | Spring |
| 5 | 123657022/0 | Washer |
| 6 | 123657017/0 | Washer |
| 7 | 123878120/0 | Screw |
| 8 | 123784008/0 | Case |
| 9 | 123430607/0 | Spring |
| 10 | 118801431/0 | Cap,Grey |
| 10 | 123790023/0 | Spring Cap,Black |
| 11 | 123878121/0 | Screw |
| 12 | 123109588/0 | Cover |
| 13 | 118801432/0 | Knob |
| 14 | 123700065/0 | Left Handgrip substituted by 118804986/0 |
| 15 | 118801433/0 | Spring |
| 16 | 123315099/0 | Lever |
| 17 | 118801434/0 | Safety Lever,Black |
| 18 | 123430609/0 | Spring |
| 19 | 118801436/0 | Throttle Lever, Black |
| 20 | 123700066/0 | Right Handgrip |
| 21 | 123303007/0 | Switch |
| 22 | 123202008/0 | Retainer |
| 23 | 123878115/0 | Screw |
| 24 | 123657023/0 | Grommet |
| 25 | 123044223/0 | Bushing |
| 26 | 123878124/0 | Screw |
| 27 | 118801438/1 | Tank |
| 28 | 123275031/0 | Grommet |
| 36 | 183520009/0 | Intake Filter |
| 37 | 123867028/0 | Tube |
| 38 | 1232940080 | Fairlead Guide |
| 39 | 123878122/0 | Screw |
| 40 | 123867029/0 | Tube |
| 41 | 123275032/0 | Grommet |
| 42 | 118801440/0 | Starter Handle |
| 42A | 118804986/0 | Handle Assy SHP 60 |
| 43 | 123234007/0 | Starter Cord |
| 45 | 118801449/0 | Starter Assy Black |
| 46 | 123430610/0 | Starter Spring |
| 47 | 123604013/0 | Starter Pulley |
| 48 | 112728445/0 | Screw |
| 49 | 118801441/0 | Yellow Cylinder Cover |
| 50 | 112735654/0 | Screw |
| 51 | 118801444/0 | Yellow Cylinder Cover |
| 52 | 183065030/0 | Spark Plug Cable |
| 53 | 118801447/0 | Throttle Cable |
| 54 | 118801448/0 | Cable Retainer |
| 55 | 112726389/0 | Screw |
| Edgetrimmer SHP 60/252961002-14-2017 Trasmissione Pag.3 | ||
| 1 | 123050010/0 | Clutch Drum Assy |
| 2 | 123657013/0 | Washer |
| 3 | 123657017/0 | Washer |
| 4 | 123878117/0 | Screw |
| 5 | 123685022/0 | Upper Case |
| 6 | 123657013/0 | Washer |
| 7 | 123657017/0 | Washer |
| 8 | 123878081/0 | Screw |
| 9 | 123280082/0 | Crankcase Gasket |
| 10 | 123208418/0 | Flange - DISCONTINUED |
| 11 | 112379520/0 | Grease Dispenser |
| 12 | 114215222/0 | Ball Bearing |
| 13 | 123878117/0 | Screw |
| 14 | 112610003/0 | Snap Ring |
| 15 | 123570052/0 | Pinion |
| 16 | 114215222/0 | Ball Bearing |
| 17 | 123664000/0 | Gear Assy |
| 18 | 123041502/0 | Connecting Rod |
| 19 | 123753003/0 | Pin |
| 21 | 123685023/0 | Lower Case - INCL. 118804982/0 |
| 22 | 123878081/0 | Screw |
| 23 | 123280083/0 | Gasket |
| 24 | 123878118/0 | Screw |
| 25 | 123208419/0 | Plate |
| 26 | 123878110/0 | Screw |
| 27 | 123878113/0 | Screw |
| 28 | 123294006/0 | Blade Holder |
| 29 | 123044222/0 | Bushing |
| 30 | 123305004/0 | Blade |
| 31 | 123120014/0 | Nut |
| 32 | 123600081/0 | Blade Guard |
| 33 | 123294007/0 | Blade Holder |
| 34 | 123208420/0 | Bracket |
| 35 | 123085002/0 | Blade Cover |
| 36 | 118804982/0 | Engine Support Assembly |
