Stayer Spare Parts for Band Saw SN1435B

€3.80
Tax included

Stayer Spare Parts for Band Saw SN1435B

We have the original Spares STAYER for Band Saw SN1435B the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Band Saw SN1435B. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.
ITEM CODE: 81011076
Quantity
Usually Ships in: 10/15 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Stayer Spare Parts for Band Saw SN1435B

Fix Your Band Saw SN1435B. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.

In the following table, look for the model of the Band Saw and the respective parts of the code.
Stayer SN1435B
Band Saw SN1435B
# Part Num. Description
1 81011076 SPEED ADJUSTING KNOB
1,1 81011077 OVERLOAD PROTECTOR
2 81011078 MOTOR HULL
3 81011079 PAN HEAD SCREW ST2.9X13
4 81011080 CIRCUIT BOARD
5 81011081 PAN HEAD SCREW M4X8
6 81011082 PAN HEAD SCREW M4X8
7 81011083 TOOTH WASHER 4
8 81011084 MOTOR COMPONENT
9 81011085 SOCKET HEAD BOLT M5X10
10 81011086 RING 1.8X5
11 81011087 STRAIN RELIEF
12,1 81011088 MIAN SWITCH
12,2 81011089 SWITCH COVER
13 81011090 CROSS HEAD SCREW ST2.9X9.5
14 81011091 SWITCH BOX
14,1 81011092 POWER LIGHT
15 81011093 FLAT WASHER 4
16 81011094 PAN HEAD SCREW ST2.9X16
17 PLUG CORD
18 81011095 WIRE
19 81011096 WIRE
20 81011097 SHAFT
21 81011098 FLAT KEY 5X5X10
22 81011099 RETAINING RING 15
23 81011100 SPIRAL GEAR 50T
24 81011101 BALL BEARING 6202
25 81011102 RETAINING RING 35
26 81011103 OIL SEAL 35X15X7
27 81011104 BALL BEARING 607
27,1 81011105 SPRING SPINOTTO 3X10
28 81011106 RETAINING RING 11
29 81011107 SPIRAL GEAR 43T
30 81011108 FLAT KEY 4X4X6
31 81011109 SPIRAL GEAR 10T
32 81011110 SOCKET HEAD BOLT M8X25
33 81011111 SPRING WASHER 8
34 81011112 GEAR BOX
35 81011113 FRAME COVER
36 81011114 PAN HEAD SCREW M5X8
37 81011115 FLAT WASHER 5
38 81011116 HANDLE 1
39 81011117 KNOB
40 81011118 SPRING
41 81011119 MICROSWITCH
42 81011120 CORD CLAMP
43 81011121 PAN HEAD SCREW M5X10
44 81011122 HANDLE 2
45 81011123 PAN HEAD SCREW ST2.9X9.5
46 81011124 CROSS HEAD SCREW M4X8
47 81011125 HANDSPIKE
48 81011126 BOARD
49 81011127 SOCKET HEAD BOLT M5X10
50 81011128 SOCKET HEAD BOLT M8X25
51 81011129 SPRING WASHER 8
52 81011130 SET SCREW M8X10
53 81011131 SKIDDING BASE
54 LAMA BAND 1435X12.7X0.65
55 81011133 BOARD
56 81011134 BALL BEARING 6201
57 81011135 RETAINING RING 32
58 81011136 PULLEY
59 81011137 SET SCREW M8X12
60 81011138 FLAT KEY 4X4X20
61 81011139 DRIVING PULLEY
62 81011140 AXLE BUMPER
63 81011141 SET SCREW M6X12
64 81011142 FRAME
65 81011143 SPRING WASHER Φ10.5XΦ20X1.2
66 81011144 HANDLE
67 81011145 STEEL CORD CLAMP
68 81011146 PAN HEAD SCREW M5X8
69 81011147 SET SCREW M6X8
70 81011148 HANDLE M6
71 81011149 FLAT WASHER 6
72 81011150 NUT M6
73 81011151 SPRING WASHER 6
74 81011152 FLAT WASHER 6
75 81011153 GUIDE BLOCK
76 81011154 BALL BEARING 625
77 81011155 FLAT WASHER 5
78,1 81011156 SPINOTTO 5X24
78,2 81011157 SPINOTTO 5X35
79 81011158 SOCKET HEAD BOLT M6X25
80 81011159 SPRING WASHER 6
81 81011160 BLADE COVER
82 81011161 FLAT WASHER 6
83 81011162 BALL BEARING 607
84 81011163 BEARNG SHAFT
85 81011164 FLAT WASHER 6
86 81011165 SPRING WASHER 6
87 81011166 SOCKET HEAD BOLT M6X25
88 81011167 SOCKET HEAD BOLT M5X10
89 81011168 FLAT WASHER 5
90 81011169 COVER
91 81011170 GUIDE BASE ( SELECT CODE 81011215 )
93 81011171 NUT M6
94 81011172 BULLONE M6X25
98 81011173 HANDLE M10
99 81011174 FLAT WASHER 10
101 81011175 FRAME HOLDER
109 81011176 BULLONE M6X25
110 81011177 NUT M6
111 81011178 SOCKET HEAD BOLT M6X35
112 81011179 FLAT WASHER 6
113 81011180 SOCKET HEAD BOLT M5X10
114 81011181 LIMIT WASHER
115 81011182 LOCATING SLEEVE
116 81011183 RETAINING RING 8
117 81011184 LOCATING SPINOTTO
118 81011185 SEAL
119 81011186 PAN HEAD SCREW M4X8
120 81011187 SCALE
121 81011188 BASE
122 81011189 FOOT
123 81011190 BOLT M10X40
124 81011191 FLAT WASHER 6
125 81011192 LOAKING NUT M6
145 81011207 LIMIT POLE
146 81011208 LOCATOR
147 81011209 HANDLE M6
148 81011210 BULLONE M6X25
149 81011211 HEX NUT M16X15
150 81011212 SHAFT
151 81011213 SPRING
152 81011214 FLAT WASHER 12
72-91 81011215 FRONT BLOCK
72-84 81011217 BACK BLOCK
131-136 81011198 CLAMP SET
126-144 81011227 COMPLETE HANDLE
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stayer websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stayer brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Stayer SN1435B
11 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS APPROX.
MORE INFO:
info@bricoutensili.com
New

Download

Diagram Stayer SN1435B

Diagram Stayer SN1435B

Download (194.93KB)
