Stayer Spare Parts for Vacuum Cleaner VVAC2200
search
  • Stayer Spare Parts for Vacuum Cleaner VVAC2200
  • Stayer Spare Parts for Vacuum Cleaner VVAC2200

Stayer Spare Parts for Vacuum Cleaner VVAC2200

€1.08
Tax included

Stayer Spare Parts for Vacuum Cleaner VVAC2200

STAYER Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Vacuum Cleaner VVAC2200.

ITEM CODE: 75405
Quantity
Usually Ships in: 10/15 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Stayer Spare Parts for Vacuum Cleaner VVAC2200

STAYER Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Vacuum Cleaner VVAC2200.

In the following table, look for the model of the VACUUM and respective parts of the code.
Stayer VVAC2200

VACUUM CLEANER VVAC 2200
# Part Num. Description
1 75405 SCREW
2 75406 TOP PANEL
3 75407 TORSION SPRING
4 75408 HINGE PIN
5 75409 HINGED COVER
6 75410 INTEGRATED SWITCHING SOCKET
7 75411 SCREW
8 75412 SUCTION POWER CONTROL DIAL
9 75413 RHEOSTAT
10 75414 SWITCH KNOB
11 75415 MAIN SWITCH-3 POSITION
12 75416 SPRING
13 75417 E-CLIP
14 75418 SCREW
15 75419 FLAT WASHER
16 75420 TOP HANDLE
17 75421 TANK COVER LID
18 75422 PLEATED MAIN FILTER
19 75423 FILTER FRAME
20 75424 SCREW
21 75425 FILTER SHAKER UNIT
22 75426 CATCH
23 75427 MAIN TANK COVER
24 75428 CONDUCTOR PIN
25 75429 DIAPHRAGM FILTER
26 75430 VENT COVER
27 75431 SCREW
28 75432 SCREW
29 75433 SCREW
30 75434 BODY
31 75435 SCREW
32 75436 BRACKET
32A 75437 BRACKET
33 75438 COPPER STRIP-FOR OVERFLOW SWITCH
34 75439 VACUUM CLEANER BAG
35 75440 HOSE PORT TUBE
36 75441 VACUUM HOSE (INCLUDING CONNECTORS)
37 75442 SCREW
38 75443 CARBON BRUSH
39 75444 BRUSH HOLDER
40 75445 HEX NUT-LEFT HAND THREAD
41 75446 FAN
42 75447 MOTOR HOUSING
43 75448 STATOR
44 75449 STATOR SCREW
45 75450 BEARING
46 75451 ARMATURE
47 75452 MOTOR FRONT COVER
48 75453 SPACER-SMALL
49 75454 TURBINE IMPELLER
50 75455 SPACER-LARGE
51 75456 EXHAUST HOUSING
52 75457 FLAT ALUMINUM WASHER
53 75458 HEX NUT
54 75459 INTAKE HOUSING
55 75460 SOUND DEADENING FOAM
56 75461 CHASSIS
57 75462 SCREW
58 75463 FLAT WASHER
59 75464 WHEEL-REAR
60 75465 SPRING
61 75466 WHEEL LOCK DISC
62 75467 WHEEL LOCK LEVER
63 75468 REAR WHEEL STUB AXLE
64 75469 ELECTRONICS BOARD
65 75470 CORD CLIP
66 - POWER SUPPLY CORD
67 75472 CORD ARMOR
68 75473 EXTERNAL CIRCLIP
69 75474 CASTOR SHAFT
70 75475 WHEEL-FRONT
71 75476 AXLE SHAFT
72 75477 CASTOR CARRIER
73 75478 THREE WAY CONNECTOR
74 75479 EARTH LEAD
75 75480 LEAD FOR SUCTION POWER CONTROL
76 75481 LEAD FOR FILTER SHAKER
77 75482 LEAD FOR INTEGRATED SWITCH APPLIANC
SOCKET
78 75483 LEAD FOR LIQUID OVERFLOW SWITCH
79 75484 SCREW
80 75485 SCREW
81 75486 HOSE STRAP
82 75487 STRAP HOOK
83 75488 PULL STRAP
84 75489 O-RING
