Skil original spare parts for to replace broken parts for to fix Chopper 0770 - F015077001.
In the following table, look for the model of the Chopper the respective parts of the code.![]()
| Chopper 0770/F 015 077 001 | ||
| # | Part Num. | Description |
| 4 | 2610Z02565 | Switch Unit |
| 10 | 2610Z02561 | Carbon-Brush Set |
| 20 | 2610Z02549 | Hex Screw |
| 21 | 2610Z02550 | Toothed lock washer |
| 22 | 2610Z02551 | Flange clamp |
| 23 | 2610Z02552 | Screw |
| 24 | 2610Z02553 | Cutter Blade |
| 25 | 2610Z02554 | Blade Holder |
| 26 | 2610Z02555 | Driving Flange |
| 27 | 2610Z02556 | Plate DISCONTINUED |
| 28 | 2610Z02557 | Gear Box |
| 29 | 2610Z02558 | Drive Belt |
| 32 | 2610Z02562 | Nut Block |
| 33 | 2610Z02564 | Module Pcb |
| 35 | 2610Z02566 | Circuit breaker |
| 36 | 2610Z02567 | Pin |
| 37 | 2610Z02568 | Protective Cover |
| 38 | 2610Z02569 | Holder |
| 42 | 2610Z02573 | Main base plate |
| 651 | 2610Z01578 | Pusher Plate |
| 830 | 2610Z02559 | Belt Drive Gear |
| 831 | 2610Z02560 | Motor-gearbox assembly |
| 834 | 2610Z02563 | Switch Set |
| 839 | 2610Z02570 | Upper Housing |
| 840 | 2610Z02571 | Wheel Set |
| 841 | 2610Z02572 | Motor Housing |
