Lavor MISTRAL PLUS 110 Parts
€130.42
Tax included
Lavor Original Parts for Pressure Cleaner MISTRAL PLUS 110
Lavor original spare parts for to replace broken parts for to fix Pressure Cleaner MISTRAL PLUS 110 220-240~50/60 -G- EU 1L LAVOR - 8.096.0004CFix Your Pressure Cleaner MISTRAL PLUS 110. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner MISTRAL PLUS 110
Lavor original spare parts for to replace broken parts for to fix Pressure Cleaner IDRO MISTRAL PLUS 110 220-240~50/60 -G- EU 1L LAVOR - 8.096.0004CIn the following tables, look for the spare part and its respective code.
| IDRO MISTRAL PLUS 110 220-240~50/60 -G- EU 1L LAVOR - 8.096.0004C | ||
| Pag.1 | ||
| # | Part Num | Description |
| 0 | 5.001.0839C | MTP.SP.PT03EVO 230/50 W/THERM.4'45 TS M.13KG (7630PF-KC) |
| 1 | 4.008.1186 | ENGINE HOUSING U76 (LIGHT) |
| 2 | 4.013.0665 | YELLOW FRONT HOUSING MISTRAL PANT.108C (P80.0580) |
| 3 | 4.008.0031 | WATER FILTER D.16 CONICAL |
| 4 | 4.008.1488 | ELECTRIC BOX COVER PW1-PW2-MISTRAL UL - BLACK - |
| 5 | 5.001.0839C | MTP.SP.PT03EVO 230/50 W/THERM.4'45 TS M.13KG (7630PF-KC) |
| 6 | 4.013.0664 | REAR FAIRING MISTRAL BLACK (P80.0580) |
| 7 | 3.401.0178 | 0/1 PULS. SWITCH BLACK PUSH/BUTTON IP55 12/10 |
| 8 | 4.008.1568 | YELLOW ACCESSORY HOLDER MISTRAL PANT. 108C |
| 9 | 4.008.1569 | BLACK MISTRAL CABLE REEL |
| 10 | 4.012.0174C | H05VV-F CABLE 2X1, 5.4M SPRING-PROOF SCHUKO F/F WITH REFLECTOR COVER |
| 11 | 7.100.1899 | MISTRAL MANUAL + CE LAVOR |
| 12 | 6.001.0106 | S'16 GUN WITH INTEGRATED QUICK COUPLING |
| 13 | 4.018.0106 | 1/4 HOSE 18MPA 3M ROTARY M22X1.5 D15 - QUICK COUPLING FOR S'09 SPIRAL HANDLE |
| 14 | 6.002.0360 | S'02V LANCE 0.85 (BROWN DOT) |
| 21 | 6.002.0259 | STANDARD FOAM DIFFUSER (D.4) WITH TRANSPARENT TANK |
| 22 | 3.100.0082C | 3/4 BLACK QUICK COUPLING WITH SEAL (THREAD L=9.5) |
| 23 | 4.008.1570 | BLACK MISTRAL HANDLE |
| 24 | 4.008.1571 | BLACK MISTRAL TROLLEY |
| 25 | 4.008.1003 | WHEEL FOR POWER TROLLEY |
| MTP.SP.PT03EVO 230/50 C/TERM.4'45 TS M.13KG(7630PF-KC) Pag.2 | ||
| 0 | 5.009.0837C | GUIDE GRID WITH 13KG BASE + HEAD (PT03EVO) |
| 1 | 5.009.0978 | MOTOR ASSEMBLY SP.03 230/50 WITH ANTI-DAMAGE-TERM.17AM-D 165H (U7630PF-KC) |
| 2 | 4.008.1164 | COLLAR REF. FOR BRUSH MOTOR FLANGE U96AF/U76 |
| 3 | 6.005.0311 | KIT 283 LW ROLLER CAGES FOR MTP.PT03 (U76) |
| 4 | 4.007.0205 | 10X70 PIN FOR PARTNER-ED BRUSHED '98 |
| 5 | 5.009.0728 | 4GR45' PLATE ASSEMBLY PT03 (U7630) WITH 62 Z CROWN |
| 6 | 4.007.0328 | BALL THRUST BEARING 35X55X12 FOR PT03 |
| 7 | 5.009.0837C | GUIDE CAGE WITH 13KG VALVE + HEAD (PT03EVO) |
| GR.C.GUIDA C/TS 13KG+TESTATA(PT03EVO) Pag.3 | ||
| 1 | 5.007.0248 | GUIDE CAGE PT03EVO PISTON D.12 WITH VALVE - COMP. VALVE WITHOUT SUCTI SPRING 13KG |
| 2 | 6.005.0380 | KIT 348 LW APPLIANCE RINGS PT03 SEAL D.12 |
| 3 | 5.008.0261 | PT'03EVO HEAD D.12 |
| C.GUIDA PT03EVO PIST.D.12 C/TS-VALV.COMP.S/ASP.MOLLA 13KG Pag.4 | ||
| 1 | 4.005.0299 | PT'03EVO PISTON GUIDE BODY |
| 2 | 5.009.0716 | COMP. VALVE ASSEMBLY WITH TS PT03 CABLE L=530 13KG SPRING (WHITE COVER) |
| 3 | 6.005.0181 | KIT 167 LW 3 PISTONS + SPRINGS PT03 |
| 4 | 6.005.0226 | O-RING KIT FOR PT03 |
| 5 | 6.005.0281 | KIT 256 LW CHECK VALVE ASSEMBLY WITHOUT SUCTION PT03C |
| 6 | 6.005.0079 | KIT 79 LW OIL SEAL RINGS FOR PARTNER D.12 / FIBER |
| 7 | 4.007.0314 | CYLINDRICAL PIN 3.5X30 ZNT |
| TESTATA PT'03EVO D.12 Pag.5 | ||
| 1 | 4.005.0298 | PT03EVO HEAD WASHER |
| 2 | 6.005.0133 | KIT 124 WATER SEAL RINGS PARTNER D.12 |
| 3 | 6.005.0588 | KIT LW VALVE ASP./MAND. + CAPS PT'03EVO |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor MISTRAL PLUS 110
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
