Lavor Pressure Cleaner EAGLE 28 Parts
search
  • Lavor Pressure Cleaner EAGLE 28 Parts
  • Lavor Pressure Cleaner EAGLE 28 Parts Drawing
  • Lavor Pressure Cleaner EAGLE 28 Parts Drawing - 1

Lavor Pressure Cleaner EAGLE 28 Parts

€30.37
Tax included

Lavor Original Parts for Pressure Cleaner EAGLE 28

Lavor original spare parts for to replace broken parts for to fix High Pressure Cleaner IDRO EAGLE 28 230/50 -G- TS EU AVV. 2L (20L) LWS - 8.030.0902.

Fix Your Pressure Cleaner EAGLE 28. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 5.X09.0587
Quantity
Usually Ships in: 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Lavor Original Parts for Pressure Cleaner EAGLE 28

Fix Your High Pressure Cleaner IDRO EAGLE 28 230/50 -G- TS EU AVV. 2L (20L) LWS - 8.030.0902. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
EAGLE 28 - 8.030.0902
IDRO EAGLE 28 230/50 -G- TS EU AVV. 2L (20L) LWS – 8.030.0902
Motor Pump Pag.1
# Part Num Description
8 5.X09.0587 FRONT FLANGE FOR PT'03 D.125H100 WITH THREADS
9 6.005.0251 KIT 234 LW FAN + RING
10 5.002.0134 '96 CASING D.125 H100 230/50 2P WITH TERMINAL (FOR MACHINE)
11 3.001.0020 RADIAL BALL BEARING 6203 2RS
12 5.005.0053 ROTOR SHAFT D.65 H.100 FOR PT'03 125 MOTOR 230-240/50
14 4.X05.0226 FRONT FLANGE FOR PT'03 MOTOR D.125H100 WITH THREADS
15 3.201.0001 SEAL RING 20/35/6/6.5 BABS L
16 3.001.0002 ANGLE BALL BEARING 20x52x15 7304 B
17 4.005.0225 12G PLATE FOR PT'03 THRUST BEARING BALLS
19 4.007.0416 EXT BALL THRUST BEARING 35X58X12 FOR PT'03 (180 BAR)
20 6.005.0254 EXT KIT 237 LW 3 PISTONS + SPRINGS PT'03
22 6.005.0226 ORD KIT 209 O-RINGS FOR PT'03
24 5.009.0745 PT'03 BRASS OUTLET VALVE CAP WITH O-RING
25 6.005.0079 ORD KIT 79 LW OIL SEAL RINGS FOR PARTNER D.12/FIBER
26 5.009.0744 PT'03 OUTLET VALVE FOR THREADED CAPS
27 4.006.0340 PT'03 BRASS HEAD WITH THREAD FOR VALVE CAPS WITHOUT PRESSURE GAUGE
28 6.005.0316 ORD KIT 288 BROWN WATER SEAL RINGS PT BRASS HEAD D.12
29 6.005.0134 KIT 125 LW BRASS SEAL RINGS + SPACERS PT D.12
30 4.005.0264 PT'03 PISTON GUIDE BODY WITH INLET HOLE, THREADED (FOR EAGLE) ESP0
31 5.006.0209 '99 ENGINE D.125 H100 230/50 2P WITH THERMAL PROTECTION, OBLIGED FOR PT'03
32 5.007.0232 PT'03 PISTON GUIDE BODY D.12 CERAMIC WITH TS-INLET (THREAD) M.17kg-HOLE
33 5.008.0234 PT'03 HEAD D.12 BRASS WITH THREADED CAPS (BLACK FABRIC SEALS)
34 5.009.0596 COMP. ASSEMBLY C/TS PT'03 CABLE L=530 17KG SPRING (GREEN COVER)
37 5.009.0534 INTAKE VALVE ASSEMBLY '03 HEAD
13A 6.005.0281 EXT KIT 256 LW CHECK VALVE ASSEMBLY W/O INTAKE PT'03C
13B 6.005.0210 EXT KIT 193 LW CHECK VALVE ASSEMBLY + BLIND HOLDER PT'03
Chassis Pag.2
2 4.008.0280 LANCE HOLDER WITH FOOT FOR SPA CE
3 4.008.0494 LMX-EAGLE BLOWN HANDLE
4 7.101.2477 EAGLE FAIRING ADHESIVE
5 4.008.0281 KW REGULATOR KNOB (SPACE)
6 5.009.0538 EXT SWITCH ASSEMBLY 0/1 + TRANSP. PROTECTION 14(14)
8 4.012.0150 H05VV-F CABLE 3X1.5 MT. 5.4 MT. SCHUKO SPLASHPROOF F/F
9 4.008.0967 MACH LOWER LANCE HOLDER
10 4.008.0278 INLET/OUTLET COVER FOR SPARK PARTNER VERSION
12 4.013.0300 EAGLE UPPER FAIRING WITHOUT ADJUSTMENT -G- PANT.108C
17 6.005.0242 EXTERNAL KIT 225 LW WHEELS + LOCK + EAGLE WHEEL COVER
19 4.007.0224 EAGLE WHEEL AXLE D.20 L=358
20 4.007.0287 ENGINE FIXING BAND D.125 UNLOADED
21 4.008.0514 EAGLE MOTOR PUMP SUPPORT FOOT, BLACK
22 5.611.0089 EAGLE LOWER FAIRING ASSEMBLY, BLACK + RUBBER + CAP WITH HOLES FOR WINDSCREEN
23 5.012.0060 CRANK HANDLE KIT + SCREW FOR EAGLE HOSE REEL
25 4.008.0517 HALF-CRANK CRANK SIDE
26 3.099.0158 IDLE RING 3/8 CH20 REF. E4890003
27 4.008.0516 HALF-CRANK CRANK INLET SIDE
28 5.609.0073 HOSE REEL PIN ASSEMBLY M14x1.5 CONNECTOR
34 4.018.0046 EXTERNAL HOSE 1/4 21MPa (210bar) L=600 ROTARY D.15 - M14
39 4.018.0052 EXTERNAL HOSE 1/4 160BAR L=8000 1/4 F.GI R.3/8 F.GIR.
40 6.001.0065 EXTERNAL S'01DM GUN, METAL PROTECTION, WITH PRESSURE GAUGE, WITH QUICK COUPLING,
41 6.002.0304 EXTERNAL PRESSURE REGULATOR LANCE, BLACK HANDLE, SY'03R, D. 1.15 (G-) (NARROW)*
42 6.002.0223 EXTERNAL ROTOX LANCE, S97, 1.20 (RED), BRASS
43 7.100.1438 HYDRO HOBBY A5 16F GENERAL MANUAL (IT-EN) - DIGITAL -
46 4.008.0622 EAGLE TOP FAIRING COVER, BLACK (2600W)
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
EAGLE 28 - 8.030.0902
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N LAVOR:
LAVOR S/N START WITH (8. ) and have 8 DIGITS
New

Download

Lavor EAGLE 28 Parts Drawing

Lavor EAGLE 28 Parts Drawing

Download (632.29KB)
