Lavor Pressure Cleaner Prime 165 Parts
€28.03
Tax included
Lavor Pressure Cleaner Prime 165 Spare Parts
Fix Your Cold Water High Pressure Cleaner PRIME 165 220-240V~50/60Hz -N/GR-TS EU 2L +SP.ROT+L28 +SPURG.-LAVOR. 8.097.0002C. All Spares can be supplied at discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Pressure Cleaner Prime 165 Spare Parts
Fix Your Cold Water High Pressure Cleaner PRIME 165 220-240V~50/60Hz -N/GR-TS EU 2L +SP.ROT+L28 +SPURG.-LAVOR. 8.097.0002C. All Spares can be supplied at discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| IDRO PRIME 165 220-240V~50/60Hz -N/GR-TS EU 2L +SP.ROT+L28 +SPURG.-LAVOR- | ||
| R80970002C-1 - CHASSIS Pag.1 | ||
| Pos. | Codice | Description |
| 001 | 4.008.1607 | PRIME FRONT COVER -GR- RAL.7046 |
| 002 | 4.008.1539 | ADAPTER FOR PRIME BRUSHED MOTOR |
| 005 | 4.013.0640 | VERTIGO BLACK FRONT FAIRING |
| 006 | 4.008.1432 | VERTIGO BLACK SWITCH KNOB |
| 007 | 3.401.0202 | ROTARY SWITCH BIPOLAR 16A (0-1) W/PIN L=11.5 |
| 009 | 4.008.1437 | VERTIGO ELECTRIC BOX COVER - BLACK- |
| 010 | 4.008.0721 | RIGHT MOTOR CONVEYOR (NOT FOR U96 FL.ALL./9655) |
| 011 | 4.008.1425 | VERTIGO HANDLE - BLACK- |
| 012 | 4.008.1614 | VERTIGO CABLE REEL - GR- RAL.7046 (PANT.430C) |
| 013 | 4.008.0095 | BLACK DETERGENT TANK CAP WITH HOLE D.9 |
| 014 | 4.008.1431 | TANK FOR VERTIGO |
| 015 | 4.013.0639 | VERTIGO BLACK REAR FAIRING |
| 016 | 4.008.1433 | VERTIGO BLACK WHEEL |
| 017 | 4.012.0235 | H05VV-F CABLE 2X1.5 MT.5.4 SP.SCHUKO ANTI-SPLASH F/F |
| 018 | 6.001.0073 | S'09 GUN W/INTEGR. QUICK CONNECTOR W/LEVER -G- PANT.108C LAVOR |
| 019 | 4.018.0096 | HOSE 1/4 180BAR L=8000 M22x1,5 D.15-RAPID FIX |
| 022 | 6.002.0340 | LANCE S'12 WITHOUT NOZZLE HEAD WITH QUICK COUPLING/COGETIL |
| 023 | 6.002.0343 | HEAD LANCE S'12 D.1.00 (LIGHT BLUE) W/RAP.ATT. (FAN JET) |
| 024 | 6.002.0346 | ROTOX NOZZLE HEAD LANCE S'12 D.1,025 WITH QUICK COUPLING |
| 026 | 3.601.0066 | ROTARY HYDRO BRUSH FIXED HANDLE COG.RINF.(5116 ECON.) |
| 029 | 3.100.0082 | QUICK CONNECTOR 3/4 BLACK WITH SEAL (THREAD L=11.5) |
| 030 | 7.100.2136 | SPECIFIC PRIME MANUAL + CE LAVOR 27L A5 16F |
| 032 | 6.005.0450 | KIT 380 PRIME HOSE REEL (W/HOSE) |
| 033 | 3.601.0102 | FLOOR BRUSH L28 WITH EXTENSION -G/N- (D.1,2) |
| 034 | 6.003.0037 | DRAIN CLEANING PROBE MT.6+COGET+NOZZLE |
| R50010750C-1 - MOTOP.SPAZZ.PT'03 230/50 7'10TS C/ASP. M.13KG TEST.T.FIL.SE Pag.2 |
||
| Pos. | Codice | Description |
| 000 | 5.001.I763C | MTP.SP.PT'03 230/50 7GR10AL TS 13KG C/ASP. TEST.T.FIL.SEDE PL.(8850) |
| 001 | 5.009.0582 | ASS.MOT.A SPAZZ.'03 230/50 C/F L.INT.+PIGN.F.L=600 C/ANTID.(8850) |
| 002 | 6.005.0180 | KIT 166 FOOTSTEP BEARING 3047 PT' 03-SD |
| 003 | 4.007.0205 | PIN 10X70 |
| 004 | 5.009.0742 | 7'10 WOBBLE PLATE ASSEMBLY W/PLASTIC INSERT+RING GEAR Z 50 |
| 005 | 4.007.0328 | BALL THRUST BEARING 35X55X12 FOR PT'03 |
| 006 | 6.005.0181 | KIT 167 LW PISTON |
| 007 | 6.005.0226 | KIT 209 O-RING |
| 008 | 6.005.0449 | KIT VALV.ASP./MAND.(P.O.M.)+PLUGS ALLUM.FIL.PT' 03 |
| 009 | 4.005.0296 | HEAD PT'03 WASHED W/THREAD FOR VALVE CAPS |
| 010 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 011 | 6.005.0282 | KIT 257 O-RING SEA |
| 012 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 015 | 4.005.0263 | PISTON BODY GUIDE PT'03 WITH SUCTION VALVE |
| 016 | 5.009.0716 | ASSEMBLY V.COMP. C/TS PT'03 CABLE L=530 SPRING 13KG (WHITE COVER) |
| 017 | 5.007.0187C | GUIDE BODY PT'03 PIST.D.12 C/ TS-ASP.-VALV.COMP.-M.13KG |
| 018 | 5.008.0265C | HEAD PT'03 D.12 C/PLUGS THREADED-VALVE SEAT |
| 13B | 6.005.0277 | KIT 252 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor Prime 165 - 80970002C
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
