Lavor Floor Scrubber Drier Fit 35B Li Parts
€296.27
Tax included
Lavor Floor Scrubber Drier Fit 35B Li Parts
Lavor original spare parts for to replace broken parts for to fix Floor Scrubber Drier Fit 35B Li 0.071.0001.Fix Your Floor Scrubber Drier Fit 35B Li Lavor Pro. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Floor Scrubber Drier Fit 35B Li Parts
Lavor original spare parts for to replace broken parts for to fix Floor Scrubber Drier Fit 35B Li 0.071.0001.Fix Your Floor Scrubber Drier Fit 35B Li Lavor Pro. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Floor Scrubber Drier Fit 35B Li 0.071.0001 | ||
| R00710001 - FIT35B GR.CH/GR.SC -LAVOR Pag.1 | ||
| # | Part Num. | Description |
| . | RCAA00710001 | FIT35B FRONT CASING |
| . | RCAP00710001 | FIT35B REAR CASING |
| . | RMAN00710001 | FIT35B HANDLE |
| . | RMOT00710001 | FIT35B SUCTION MOTOR |
| . | RPOM00710001 | FIT35B WATER PUMP GROUP |
| . | RSAP00710001 | FIT35B CLEAN WATER TANK |
| . | RSAS00710001 | FIT35B WASTE WATER TANK |
| . | RSPA00710001 | FIT35B BRUSH |
| . | RSQG00710001 | SQUEEGEE FIT35B |
| . | RTEL00710001 | FIT35B DECK |
| 001 | 0.971.0071 | BATTERY PACK 25.2V/161.28Wh/6400mAh Li |
| 002 | 7.700.0639 | MANUAL FIT35B -WORK- 7L A5 |
| 003 | 0.971.0135 | BATTERY CHARGER 100-240V 50-60Hz 24V-4A FIT35B-CPS35BX SCHUKO (XD2092021A120) |
| 004 | 0.971.0136 | BATTERY CHARGER 100-240V 50-60Hz 24V-4A FIT35B-CPS35BX UK (XD2092021A1201) |
| 005 | 0.971.0137 | CHARGER 100-240V 50-60Hz 24V-4A FIT35B-CPS35BX USA (XD2092021A1202) |
| 006 | 0.971.0139 | FIT35B COMPLETE HANDLE |
| RCAA00710001 - FRONT CASING FIT35B Pag.2 | ||
| # | Part Num. | Description |
| 001 | 0.971.0086 | FRONT COVER (XD2092021A0801) |
| 002 | 0.971.0087 | SPACER (XD2092021A0802) |
| 004 | 0.971.0088 | SMALL BRUSH (XD2092021A0804) |
| 005 | 0.971.0089 | CROSSBOW (XD2092021A0805) |
| 006 | 0.971.0090 | FRONT COVER RELEASE BUTTON (XD2092021A0806) |
| RCAP00710001 - REAR CASING FIT35B Pag.3 | ||
| # | Part Num. | Description |
| 002 | 0.971.0072 | GRIP LOCKING PLATE (XD2092021A0702) |
| 003 | 0.971.0073 | CENTRAL CASHIER (XD2092021A0703) |
| 004 | 0.971.0074 | SHAFTS FOR HANDLE (XD2092021A0704) |
| 005 | 0.971.0075 | CARRYING HANDLE (XD2092021A0705) |
| 007 | 0.971.0076 | WATER RELEASE INDICATOR (XD2092021A0707) |
| 009 | 0.971.0077 | WATER RELEASE BUTTON (XD2092021A0709) |
| 010 | 0.971.0078 | HANDLE COVER R (XD2092021A0710) |
| 011 | 0.971.0079 | HANDLE COVER L (XD2092021A0711) |
| 014 | 0.971.0080 | POWER SWITCH BUTTON (XD2092021A0714) |
| 016 | 0.971.0081 | POWER SWITCH INDICATOR (XD2092021A0716) |
| 017 | 0.971.0082 | POWER SWITCH (XD2092021A0717) |
| 018 | 0.971.0083 | RUBBER SUPPORT (XD2092021A0718) |
| 019 | 0.971.0084 | SEALING (XD2092021A0719) |
| 020 | 0.971.0085 | WATERPROOF SEAL (XD2092021A0720) |
| RPOM00710001 - WATER PUMP GROUP FIT35B Pag.4 | ||
| # | Part Num. | Description |
| 001 | 0.971.0125 | HOSE 1 (XD2092021A1101) |
| 002 | 0.971.0126 | T-CONNECTOR (XD2092021A1102) |
| 005 | 0.971.0127 | WATER INLET CONNECTOR (XD2092021A1105) |
| 006 | 0.971.0128 | WATER FILTER (XD2092021A1106) |
| 009 | 0.971.0129 | PUMP PRE HOSE (XD2092021A1109) |
| 010 | 0.971.0130 | PRE PUMP BRACKET (XD2092021A1110) |
| 013 | 0.971.0131 | PUMP AC24V16W (XD2092021A1113) |
| 014 | 0.971.0132 | PUMP BRACKET (XD2092021A1114) |
| 015 | 0.971.0133 | HOSE 2 (XD2092021A1115) |
| 016 | 0.971.0134 | SPRAYER (XD2092021A1116) |
| RMAN00710001 - FIT35B HANDLE Pag.5 | ||
| # | Part Num. | Description |
| 002 | 0.971.0105 | HANDLE (RIGHT) (XD2092021A1002) |
| 003 | 0.971.0106 | ALUMINUM TUBE (SU) (XD2092021A1003) |
| 004 | 0.971.0107 | ALUMINUM TUBE END (XD2092021A1004) |
| 006 | 0.971.0108 | CONNECTOR FOR ALUMINUM TUBE (XD2092021A1006) |
| 007 | 0.971.0109 | ALUMINUM TUBE (GIÙ) (XD2092021A1007) |
| 008 | 0.971.0110 | HANDLE LOCKING BRACKET (XD2092021A1008) |
| 009 | 0.971.0111 | SHOCK ABSORBER (XD2092021A1009) |
| 011 | 0.971.0112 | HANDLE HOLDER (DOWN) XD0301X20969163 |
| 012 | 0.971.0113 | POSITION FIXING SPRING (XD2092021A1012) |
| 013 | 0.971.0114 | POSITION FIXING (L&R) (XD2092021A1013) |
| 014 | 0.971.0115 | POSITION FIXING (F&B) (XD2092021A1014) |
| 015 | 0.971.0116 | HANDLE SHAFT XD0307X20910005 |
| 016 | 0.971.0117 | HANDLE CONNECTOR (DOWN) XD0301X20935163 |
| 017 | 0.971.0118 | RETAINING RING (XD2092021A1017) |
| 019 | 0.971.0119 | SPRING (XD2092021A1019) |
| 020 | 0.971.0120 | HOOK HANDLE (XD2092021A1020) |
| 022 | 0.971.0121 | POSITION LOCK (XD2092021A1022) |
| 023 | 0.971.0122 | AXIS CAPTURE BLOCK (XD2092021A1023) |
| 024 | 0.971.0123 | LOCK BLOCK (XD2092021A1024) |
| 025 | 0.971.0124 | HANDLE (LEFT) (XD2092021A1025) |
| RMOT00710001 - SUCTION MOTOR FIT35B Pag.6 | ||
| # | Part Num. | Description |
| 001 | 0.971.0037 | SHOCK ABSORBER (XD2092021A0301) |
| 002 | 0.971.0038 | ENGINE COVER (BOTTOM) (XD2092021A0302) |
| 003 | 0.971.0039 | VACUUM ENGINE MOUNT (X0305X20901205) |
| 004 | 0.971.0040 | AIR OUTLET SEAL (X0305X20901224) |
| 005 | 0.971.0041 | MOTOR FAN GASKET (XD2092021A0305) |
| 006 | 0.971.0042 | INTAKE MOTOR (XD2092021A0306) |
| 007 | 0.971.0043 | PRE ENGINE SEALING (XD2092021A0307) |
| 008 | 0.971.0044 | ENGINE COVER (UP) (XD2092021A0308) |
| 010 | 0.971.0045 | ENGINE COVER GASKET (XD2092021A0310) |
| 011 | 0.971.0046 | AIR INLET GASKET (XD2092021A0311) |
| 012 | 0.971.0047 | WATER INLET SEAL (XD2092021A0312) |
| 014 | 0.971.0048 | AIR DUCT CONNECTOR (XD2092021A0314) |
| 015 | 0.971.0049 | AIR SQUEEQE CHANNEL (XD2092021A0315) |
| RSAP00710001 - CLEAN WATER TANK FIT35B Pag.7 | ||
| # | Part Num. | Description |
| 001 | 0.971.0050 | CHECK VALVE (XD2092021A0401) |
| 002 | 0.971.0051 | FRESH WATER TANK COVER (TOP) (XD2092021A0402) |
| 003 | 0.971.0052 | WATER TANK CAP (XD2092021A0403) |
| 004 | 0.971.0053 | FRESH WATER TANK COVER (BOTTOM) (XD2092021A0404) |
| 005 | 0.971.0054 | WATER TANK CURSOR (XD2092021A0405) |
| 006 | 0.971.0055 | SPRING (XD2092021A0406) |
| 007 | 0.971.0056 | VALVE COIL (XD2092021A0407) |
| 008 | 0.971.0057 | SEALING SPACER (XD2092021A0408) |
| 009 | 0.971.0058 | SEALING RING (XD2092021A0409) |
| 010 | 0.971.0059 | SOLUTION TANK CAP (XD2092021A0410) |
| RSAS00710001 - WASTE WATER TANK FIT35B Pag.8 | ||
| # | Part Num. | Description |
| 001 | 0.971.0060 | WATER TANK CAP (XD2092021A0501) |
| 003 | 0.971.0061 | RECOVERY TANK SPONGE COVER (XD2092021A0503) |
| 004 | 0.971.0062 | SEALING DIRTY WATER TANK (UP) (XD2092021A0504) |
| 005 | 0.971.0063 | FLOAT BASE (XD2092021A0505) |
| 006 | 0.971.0064 | DIRTY WATER TANK SEAL (DOWN) (XD2092021A0506) |
| 007 | 0.971.0065 | FLOAT SEAL SER. OF DIRTY WATER (XD2092021A0507) |
| 008 | 0.971.0066 | WASTE WATER TANK FLOAT (XD2092021A0508) |
| 009 | 0.971.0067 | DIRTY WATER TANK WATER INLET (XD2092021A0509) |
| 010 | 0.971.0068 | WASTE WATER TANK (UP) (XD2092021A0510) |
| 011 | 0.971.0069 | WATER CAP (XD2092021A0511) |
| 012 | 0.971.0070 | WASTE WATER TANK (BOTTOM) (XD2092021A0512) |
| 013 | 0.971.0140 | SPONGE FILTER |
| RSPA00710001 - FIT35B BRUSH Pag.9 | ||
| # | Part Num. | Description |
| 001 | 0.971.0024 | BRUSH COVER LOCK SPRING (XD2092021A0201) |
| 002 | 0.971.0025 | SCREW (XD2092021A0202) |
| 003 | 0.971.0026 | BRUSH COVER LOCK (XD2092021A0203) |
| 004 | 0.971.0027 | BRUSH COVER (XD2092021A0204) |
| 005 | 0.971.0028 | BRUSH BEARING SLEEVE (XD2092021A0205) |
| 006 | 0.971.0029 | LARGE WASHER (XD2092021A0206) |
| 008 | 0.971.0030 | BRUSH PP+30% CaCo2 (XD2092021A0208) |
| 011 | 0.971.0031 | MOTOR DRIVE CONNECTOR (XD2092021A0211) |
| 012 | 0.971.0032 | BRUSH MOTOR (XD2092021A0212) |
| 013 | 3.001.0093 | BALL BEARING 6303 2RS X ENG. EL. (17X47X14) |
| 014 | 0.971.0034 | BRUSH MOTOR SUPPORT (XD2092021A0215) |
| 015 | 0.971.0035 | CRANKSHAFT PRESS SUPPORT (XD2092021A0216) |
| 016 | 0.971.0036 | CABLE GLAND PLATE (XD2092021A0217) |
| 017 | 0.971.0033 | BEARING SLEEVE (XD2092021A0214) 0.971.0033 |
| RSQG00710001 - SQUEEGEE FIT35B Pag.10 | ||
| # | Part Num. | Description |
| 001 | 0.971.0091 | SQUEEGEE MAIN BRACKET (XD2092021A0901) |
| 002 | 0.971.0092 | LEFT SQUEEGEE HEIGHT ADJUSTMENT (XD2092021A0902) |
| 003 | 0.971.0093 | SQUEEGEE HEIGHT ADJUSTMENT SEAL (XD2092021A0903) |
| 004 | 0.971.0094 | ROTARY SQUEEGEE KNOB (XD2092021A0904) |
| 006 | 0.971.0095 | FRONT BLADE (XD2092021A0906) |
| 007 | 0.971.0096 | REAR BLADE (XD2092021A0907) |
| 008 | 0.971.0097 | SQUEEGEE SEALING BRACKET (XD2092021A0908) |
| 009 | 0.971.0098 | SQUEEGEE SEAL (XD2092021A0909) |
| 011 | 0.971.0099 | SQUEEGEE WHEEL (XD2092021A0911) |
| 012 | 0.971.0100 | SQUEEGEE WHEEL SLEEVE (XD2092021A0912) |
| 013 | 0.971.0101 | RIGHT SQUEEGEE HEIGHT ADJUSTMENT (XD2092021A0913) |
| 014 | 0.971.0102 | SQUEEGEE LOCK (XD2092021A0914) |
| 015 | 0.971.0103 | SQUEEGEE LOCKING SPRING (XD2092021A0915) |
| 016 | 0.971.0104 | SQUEEGEE LOCKING SCREW (XD2092021A0916) |
| RTEL00710001 - FIT35B DECK Pag.11 | ||
| # | Part Num. | Description |
| 001 | 0.971.0001 | WHEEL PIN (XD2092021A0101) |
| 002 | 0.971.0002 | GLOSSY GRAY WHEEL COVER (XD2092021A0102) |
| 003 | 0.971.0003 | WHEEL (XD2092021A0103) |
| 004 | 0.971.0004 | FRONT COVER PATH LIMIT (XD2092021A0104) |
| 006 | 0.971.0005 | ROUTE LIMIT ROUTE (XD2092021A0106) |
| 007 | 0.971.0006 | DECK (XD2092021A0107) |
| 008 | 0.971.0007 | BEARING SPIDER (XD2092021A0108) |
| 012 | 0.971.0008 | COVER FOR BATTERY CABIN (XD2092021A0112) |
| 013 | 0.971.0009 | BATTERY PACK PLUG (XD2092021A0113) |
| 015 | 0.971.0010 | SLIDER (XD2092021A0115) |
| 017 | 0.971.0011 | PCB (XD2092021A0117) |
| 018 | 0.971.0012 | SUPPORT FOR CABLE OUTLET (XD2092021A0118) |
| 019 | 0.971.0013 | PUMP COVER (XD2092021A0119) |
| 021 | 0.971.0014 | ENGINE COVER (XD2092021A0121) |
| 024 | 0.971.0015 | AIR OUTLET COVER (XD2092021A0124) |
| 025 | 0.971.0016 | FILTER 2 (XD2092021A0125) |
| 026 | 0.971.0017 | FILTER 1 (XD2092021A0126) |
| 027 | 0.971.0018 | BRUSH HOLDER (XD2092021A0127) |
| 028 | 0.971.0019 | BRUSH HOLDER SPRING (XD2092021A0128) |
| 029 | 0.971.0020 | ENGINE COVER BUFFER (XD2092021A0129) |
| 030 | 0.971.0021 | LIGHT (XD2092021A0130) |
| 031 | 0.971.0022 | FRONT COVER ALIGNMENT SCREW (XD2092021A0131) |
| 033 | 0.971.0023 | FRAME FIXING PART (XD2092021A0133) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor Fit 35B Li - 0.071.0001
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- MORE INFO:
- ATTENTION! FOR CODES NOT IN THE PRICE LIST, CONTACT US FOR A QUOTE
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
