Lavor Original Parts for Pressure Cleaner LP 20 EHR 130R
€14.08
Tax included
Lavor Original Parts for Pressure Cleaner LP 20 EHR 130R
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner 8.028.0006 - LP 20 230/50 -G- EINHELL EHR 130R + ROTOX.Fix Your Pressure Cleaner. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner LP 20 EHR 130R
Fix Your Cold Water High Pressure Cleaner 8.028.0006 - LP 20 230/50 -G- EINHELL EHR 130R + ROTOX. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| 8.028.0006-3 - PRESSURE CLEANER LP 20 230/50 -G- EINHELL EHR 130R + ROTOX Pag.1 | ||
| # | Part Num. | Description |
| 1 | 4.008.0491 | LOWER SUPPORT LP |
| 2 | 3.002.0102 | AUTOTHREAD. SCREW TE 3,9X13 UN I 6949 ZNT |
| 3 | 4.007.0189 | CLAMPING BAND FOR MOTORPUMP |
| 4 | 4.013.0270 | YELLOW COVER LP (PANT.108C) |
| 5 | 4.006.0038 | TOP 100 FAIRING BLOCKAGE RING NUT |
| 6 | 4.008.0819 | PRESSURE REGULATOR KNOB BEST B LACK |
| 7 | 4.007.0114 | NOZZLE CLEANING PIN |
| 8 | 4.012.0149 | CABLE H05VV-F 3X1 MT.5,4 SCHUKO PLUG F/F |
| 9 | 3.099.0073 | CAP FOR WHEEL - BLACK |
| 10 | 3.099.0051 | LOCK FOR WHEEL BLOK 12 |
| 11 | 3.006.0023 | WHEEL D.150 HOLE 12 BLACK (SP 150) |
| 12 | 5.013.0051 | TROLLEY |
| 13 | 4.008.0444 | DETERGENT TRANSPARENT PIPE 6X9 L.340mm |
| 14 | 4.607.0128 | SPRING FOR SUCTION HOSE De.6,5 L=100 INOX |
| 15 | 5.011.0045 | TANK WITH PLUG |
| 16 | 4.008.0168 | EXTRACTIBLE HANDLE FOR CARRIAG E |
| 17 | 3.100.0082 | QUICK COUPLING INLET CONNECTOR (THREAD=11.5) |
| 18 | 4.018.0061 | HOSE 1/4 140BAR L.8000 1/4F-GI R.M22X1,5 D.15 |
| 19 | 6.001.0028 | GUN S'99 |
| 20 | 6.002.0191C | 1.10 S'99 HIGH LOW PRESS. ADJUSTABLE LANCE (GREEN) |
| 21 | 6.002.0327 | ROTOX LANCE S99 1.10 GREEN |
| 31 | 6.003.0049 | REINFORCED EXTENSION LANCE S'93 |
| 50010267-2 - MOTOPOMPA PARTNER'96 230/50 125H90V/COMP.C/REG.7'20 IN.1,8 X LP Pag.2 | ||
| 001 | 5.009.0213 | SWITCH WITH PROTECTION 12(10) |
| 002 | 3.406.0004 | CABLE TERMINAL PG.11 |
| 003 | 4.008.0897 | ELECT.BOX PART'96 WITH SWITCH FRAME |
| 004 | 3.002.0135 | SELF-TAPPING CROSS HEAD SCREW 2,9X13 UNI 6954 ZNT |
| 005 | 3.404.0022 | CAPACITOR 30mF 450V F/M |
| 006 | 4.008.0613 | ELECTRIC-BOX SEAL |
| 007 | 4.008.0583 | MOTOR FAN COVER '96 WITHOUT GRILL |
| 008 | 3.099.0049 | LOCKING RING D.23 FAN FB80 |
| 009 | 4.008.0092 | FAN FB80 WITH HOLE D.16,5 (PARTNER) |
| 010 | 5.002.0066 | HOUSING '96 D.125 H.90 230/50 2P |
| 011 | 3.001.0020 | RADIAL BEARING FOR MOTOR SHAFT 17X40X12 6203 2RS |
| 012 | 5.005.0027 | ROTOR SHAFT 125 '96 D.65 H.90 230/50 CIL |
| 013 | 3.002.0115 | SCREW TC M5X35 SWAGEFORM ZNT |
| 014 | 4.005.0102 | FRONTAL MOTOR FLANGE D.125 |
| 015 | 3.201.0001 | OIL SEAL 20/35/6/6,5 BABSL |
| 016 | 3.001.0031 | ANTERIOR RADIAL FOR CASING 20X 52X15 - 6304 |
| 017 | 4.005.0079 | INCLINED PLATE 7.15 CYLINDR.HO LE |
| 018 | 3.001.0003 | DISK AS 4565 |
| 019 | 3.001.0025 | NEEDLE ROLLER CAGE Axk4565 -STTEL- |
| 020 | 4.007.0001 | THRUST SHOE D.65X30X6 (C10PB) FINISHED |
| 021 | 5.009.0090 | ASSEMBL.BOLT/PISTON D.14 RETIF IED |
| 022 | 3.200.0014 | O-RING GASKET 85X2,5 NITRILIC |
| 023 | 4.007.0025 | PISTON RECALL SPRING D.14-12 |
| 027 | 4.008.0538 | EXTENSION LEAD |
| 028 | 3.299.0008 | OR FOR ADAPTOR sp.2.7 D.int15 D.ext.24.5 |
| 029 | 5.009.0127 | ADJUSTING VALVE ROD ASSEMBLING |
| 032 | 4.006.0170 | SPACER FOR SEAL SEAT |
| 033 | 5.609.0061 | L2 VALVE SEAL SEAT INCLUSIVE OF OR |
| 035 | 3.005.0009 | BALL 11/32 INOX 420 B |
| 036 | 4.607.0095 | SPRING D.8X17 |
| 038 | 5.009.0278 | PRESSURE REGULATOR |
| 039 | 4.007.0157 | SEAT FOR REGULATOR |
| 040 | 3.200.0016 | O-RING 8,73X1,78 |
| 041 | 6.005.0030 | DETERG.INJECT.HOSE FITTING |
| 042 | 3.005.0001 | BALL INOX 420 DIAM.5 DEGREE OF ACCURACY G 500 |
| 043 | 4.007.0014 | DETERG.STOP VALVE SPRING 4X8 ESP.3 |
| 044 | 4.005.0140 | BODY GUIDE D.14 FOR COMPENSATED VALVE |
| 045 | 5.609.0041 | NON RETURN VALVE + OR ASSEMBLY |
| 046 | 4.007.0324 | STOP VALVE SPRING D.6X20 |
| 047 | 5.009.0334 | INJECTOR COUPLING D1.8 FOR ALLUM.HEAD WITH OR |
| 048 | 5.009.0333 | OUTLET COUPLING M22X1.5 COMPLETE OF OR |
| 049 | 3.200.0013 | O-RING 11,1X1,78 |
| 050 | 6.005.0019 | OIL SEALING RING DIAM.14X22X5/ 7 |
| 051 | 3.002.0094 | SCREW TCEI M6X30 ZNT |
| 052 | 3.107.0009 | PRESSURE GAUGE D.40 0/160 BAR 1/8 G |
| 054 | 3.200.0018 | OR-RING GASKET 9.92X2.62 SHORE 90 |
| 055 | 3.200.0019 | O-RING 12.4X1.78 SH.90 |
| 056 | 5.009.0101 | CAP VALVE SUCTION DELIVERY-OR MOUNTED |
| 057 | 5.009.0005 | DELIVERY SUCTION VALVE LAVOR 1 |
| 058 | 4.008.0031 | INLET WATER FILTER H2O D.16 CONICAL |
| 062 | 4.008.0348 | OIL SEAL SPACER |
| 063 | 4.006.0036 | SEALING HOLDER RING D.14 |
| 065 | 3.201.0009 | WATER SEAL N 14-12 D.14x22x6 |
| 066 | 5.009.0015 | COMPLETE SUCTION VALVE |
| 067 | 4.005.0156 | MANIFOLD PARTNER'93 DEEP SEATS |
| 068 | 4.007.0229 | SCREW TCEI M6X70 ZNT SWAGEFOR M |
| 083 | 5.008.0047 | PUMP HEAD '93 C/W PRESS.GAUGE |
| 084 | 5.007.0089 | CORPO GUIDA PIST.D.14 ACC.+IN. 1,8 VALV.COMP.C/REG.+PROL.X LP |
| 085 | 5.006.0092 | MOTOR '96 D.125 H.90 230/50 2P |
| 087 | 3.406.0011 | BUSHING FOR PG.11 CABLE TERMINAL |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor LP 20 EHR 130R 8.028.0006
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
