Milwaukee DCM2-350C Diamond Drill Parts
€101.14
Tax included
Milwaukee DCM2-350C Diamond Drill Spare Parts
Fix Your Milwaukee DCM2-350C Dry-Wet Diamond Drill. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Milwaukee DCM2-350C Diamond Drill Spare Parts
Fix Your Milwaukee DCM2-350C Wet Diamond Drill. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Drill Driver and their spare part.
| DCM2-350C DIAMOND DRILL IN2 Spare Parts 40044 - DCM2-350C - 4000384542 |
||
| # | Part Num. | Description |
| * | 49084220 | GREASE |
| 1 | 42900210 | FITTING |
| 2 | 45800060 | VALVE |
| 3 | 06571050 | NUT |
| 4 | 45881140 | WASHER |
| 5 | 43060160 | DISC |
| 6 | 43060150 | DISC - DISCONTINUED |
| 7 | 43760051 | THREADED SLEEVE - Discontinued |
| 8 | 40502150 | PRESSURE SPRING |
| 9 | 45060635 | SEAL RING |
| 10 | 45888565 | WASHER, Copper |
| 13 | 38506020 | SPINDLE - Discontinued |
| 16 | 34803800 | RING |
| 17 | 02202515 | BALL BEARING |
| 18 | 06829202 | SCREW |
| 19 | 28141870 | BODY |
| 20 | 45361520 | SPACER |
| 21 | 32753430 | SPINDLE GEAR |
| 22 | 02504830 | NEEDLE BEARING |
| 23 | 02041205 | BALL BEARING |
| 24 | 36663751 | SHAFT - Discontinued |
| 25 | 06421600 | KEY |
| 26 | 32401581 | GEAR |
| 27 | 40506300 | PRESSURE SPRING |
| 28 | 44700100 | PLUNGER |
| 30 | 45880520 | WASHER |
| 31 | 02801800 | THRUST BEARING |
| 32 | 32100060 | GEAR |
| 34 | 36140720 | SHAFT - Discontinued |
| 35 | 45880530 | WASHER |
| 36 | 02805000 | THRUST BEARING |
| 37 | 32100051 | GEAR BOX |
| 38 | 45880510 | WASHER |
| 39 | 02801200 | THRUST BEARING |
| 40 | 45980090 | YOKE |
| 41 | 14130210 | BEARING END PLATE |
| 42 | 30150272 | SLIDING SWITCH |
| 43 | 43440580 | GASKET |
| 44 | 06650840 | PIN |
| 45 | 25600056 | TRIGGER |
| 46 | 4931440556 | GROOVED BALL BEAR. |
| 47 | 16760325 | ARMATURE ASSEMBLY |
| 48 | 22840790 | FAN |
| 49 | 42140291 | AIR DEFLECTOR RING |
| 50 | 02041041 | BALL BEARING |
| 52 | 18740120 | ELECTRIC FIELD |
| 53 | 23161410 | ISOLATION MODULE |
| 54 | 22200680 | BRUSH HOLDER |
| 55 | 22180706 | CARBON BRUSH |
| 57 | 22560470 | TERMINAL - Discontinued |
| 58 | 22380140 | CLAMP |
| 59 | 31170200 | CLAMPING PIECE |
| 61 | 23370160 | CONTROL DEVICE |
| 63 | 12991815 | NAME PLATE |
| 64 | 22320350 | BRUSH COVER |
| 66 | 28506363 | HOUSING |
| 68 | 12983020 | INSTRUCTION PLATE - Discontinued |
| 70 | 4931472579 | CABLE HARNESS |
| 71 | 45360225 | SPACER |
| 101 | 22680200 | SWITCH COVER |
| 102 | 23661430 | SWITCH |
| 103 | 23949915 | CABLE SET - Discontinued |
| 104 | 22360150 | CABLE HARNESS |
| 105 | 22680210 | SWITCH COVER |
| 106 | 22330430 | CAPACITOR - Discontinued |
| 107 | 22740051 | ELECTRONIC ELEMENT - Discontinued |
| 108 | 22120200 | SWITCH COVER |
| 110 | 31170155 | CLAMPING PIECE |
| 111 | 44760140 | CABLE CLAMP |
| 112 | 22644075 | CABLE |
| 113 | 22680190 | COVER |
| 115 | 22645050 | CONNECTION CABLE - Discontinued |
| 117 | 22560480 | CLAMP |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Milwaukee websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to Milwaukee brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Milwaukee DCM2-350C
5 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK AEG S/N:
- AEG S/N START WITH (4) or (5) AND HAVE 10 DIGITS
