Michelin MPX 140HL Pressure Washer Spare Parts
Fix Your Pressure Washer MPX 140HL - 24331. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of the Pressure Washer and the respective parts of the code.
| Michelin MPX 140HL Pressure Washer - 24331 Spare Parts | ||
| Casing Pag.1 | ||
| # | Part Num. | Description |
| 1 | 3520090 | Casing |
| 2 | 3520080 | Casing |
| 3 | 3520520 | Base |
| 4 | 3520260 | Gland |
| 5 | 3520230 | Wheel |
| 6 | 3520240 | Washer |
| 7 | 3520252 | Guard |
| 8 | 3520170 | Tank |
| 9 | 3520180 | Plug |
| 10 | 3520190 | Handle |
| 11 | 3520200 | Support |
| 12 | 3520210 | Support |
| 13 | 3520870 | Cable |
| Pump Pag.2 | ||
| 1 | 2909137 | Head assembly |
| 2 | 2900430 | Head |
| 3 | 740290 | O-ring |
| 4 | 2900100 | Fitting |
| 5 | 1460430 | O-ring |
| 6 | 2901070 | Shutter |
| 7 | 1080091 | Spring |
| 8 | 800560 | O-ring |
| 9 | 2901060 | Injector |
| 10 | 620301 | Plug |
| 11 | 1460430 | O-ring |
| 12 | 880581 | Plug |
| 13 | 2840150 | Seat |
| 14 | 600180 | O-ring |
| 15 | 2909005 | Spring assembly |
| 16 | 740290 | O-ring |
| 17 | 2900130 | Fitting |
| 18 | 2022201 | Fork |
| 19 | 2029753 | TSS box assembly |
| 20 | 2849051 | Complete valve |
| 21 | 740290 | O-ring |
| 22 | 840130 | Plug |
| 23 | 2900350 | Plug |
| 24 | 2840470 | Screw |
| 25 | 2200141 | Water seal |
| 26 | 770590 | O-ring |
| 27 | 2840550 | Bushing |
| 28 | 2840540 | Bushing |
| 29 | 1683500 | Oil seal |
| 30 | 2900020 | Piston guide |
| 31 | 2900500 | Screw |
| 32 | 480560 | O-ring |
| 33 | 800220 | Screw |
| 34 | 2901170 | Spring |
| 35 | 2840530 | Piston |
| 36 | 2840050 | Lock |
| A | 2233 | Valve kit |
| B | 2313 | Piston kit |
| C | 42124 | Oil seal kit |
| F | 42438 | Gasket kit |
| Motor Pag.3 | ||
| 1 | 24230 | Electric pump assembly |
| 2 | 44518 | Motor |
| 3 | 3520050 | Pressure switch |
| 4 | 2900170 | Bearing |
| 5 | 2900520 | Wobble plate |
| 6 | 1780490 | Bearing |
| 7 | 3040270 | O-ring |
| 8 | 2900010 | Pump body |
| 9 | 2320090 | Screw |
| 10 | 1462400 | Stud bolt |
| 11 | 1460530 | Oil seal |
| 12 | 1460590 | Bearing |
| 13 | 1460040 | Shield |
| 14 | 1461200 | Oil seal |
| 15 | 394280 | O-ring |
| 16 | 1460370 | Fan |
| 17 | 1460340 | Conveyor |
| 18 | 1680960 | Washer |
| 19 | 1460460 | Screw |
| 20 | 660170 | O-ring |
| 21 | 2320131 | Box |
| 22 | 1262400 | Washer |
| 23 | 3523500 | Connector |
| 24 | 1260490 | Washer |
| 25 | 2020570 | Screw |
| 26 | 2320271 | Cover |
| 27 | 1462900 | Gland |
| 28 | 1982590 | Capacitor |
| 29 | 2320640 | O-ring |
| Electric Circuit Pag.4 | ||
| 1 | 3520270 | Knob |
| 2 | 3520280 | Shim |
| 3 | 3520300 | Element |
| 4 | 3520290 | O-ring |
| 5 | 3520350 | Fuse holder |
| 6 | 3520340 | O-ring |
| 7 | 3520850 | Switch |
| 8 | 3520840 | Board |
| Water Circuit Pag.5 | ||
| 1 | 3520570 | Screw |
| 2 | 3520580 | Washer |
| 3 | 3520400 | Pipe |
| 4 | 3520410 | O-ring |
| 5 | 3520490 | Fork |
| 6 | 3520420 | Fitting |
| 7 | 3520430 | Piston |
| 8 | 3520440 | Spring |
| 9 | 3520450 | Bushing |
| 10 | 3520460 | O-ring |
| 11 | 3520470 | O-ring |
| 12 | 3520480 | Plug |
| 13 | 3520510 | Fork |
| 14 | 3520930 | Thermostat |
| 15 | 3520530 | Fitting |
| 16 | 3520500 | O-ring |
| 17 | 3520540 | Ring |
| 18 | 3520240 | Washer |
| 19 | 3520360 | Fitting |
| 20 | 3520370 | Fitting |
| Fuel Circuit Pag.6 | ||
| 1 | 3522760 | Pump |
| 2 | 3520730 | Hose tail |
| 3 | 3520740 | Clamp |
| 4 | 3520750 | Pipe |
| 5 | 3520760 | Filter |
| 6 | 3520750 | Pipe |
| Boiler Pag.7 | ||
| 1 | 3520630 | Pipe coil |
| 2 | 3520620 | Pin |
| 3 | 3520610 | Clamp |
| 4 | 3520600 | Plate |
| 5 | 3520590 | Plate |
| 6 | 3520330 | Cover |
| 7 | 3520790 | Valve |
| 8 | 3524390 | Fan kit |
| 9 | 3520310 | Cover |
| 10 | 3521300 | Boiler |
| 11 | 3520860 | Transformer |
| 12 | 3520770 | Cable |
| 13 | 3520650 | Gasket |
| 14 | 3520660 | Element |
| 15 | 3520670 | Support |
| 16 | 3520680 | Nozzle |
| 17 | 3520690 | Flange |
| 18 | 3520710 | Plate |
| 19 | 3520700 | Electrode |
| 20 | 3520770 | Cable |
| 21 | 3520820 | Cover |
| Standard Accessories Pag.8 | ||
| 1 | 41047 | Gun |
| 2 | 1080640 | Ring |
| 3 | 391000 | O-ring |
| 4 | 50690 | Lance |
| 5 | 3729 | Nozzle |
| 6 | 40320 | Tank |
| 7 | 2000570 | O-ring |
| 8 | 3164470 | High pressure hose |
