Michelin Spares for Pressure Cleaner MPX 170 HDC
€29.15
Tax included
Michelin Spares for Pressure Cleaner MPX 170 HDC - 24363
We have the original Spares Michelin for Pressure Cleaner MPX 170 HDC - 24363, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Pressure Cleaner MPX 170 HDC. All Spares are original and can be supplied at Cheap and discounted prices.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Michelin Spares for Pressure Cleaner MPX 170 HDC - 24363
We have the original Spares Michelin for Pressure Cleaner MPX 170 HDC - 24363, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table, look for the model of the Pressure Washer and the respective parts of the code.
| HPC Pressure Cleaner Michelin MPX 170 HDC 24363 | ||
| Casing Pag.1 | ||
| # | Part Num. | Description |
| 1 | 3600140 | Wheel |
| 2 | 3600180 | Washer |
| 3 | 3600010 | Guard |
| 4 | 3600020 | Guard |
| 5 | 2000110 | Screw |
| 6 | 3600040 | Guard |
| 7 | 3600190 | Vibration damper |
| 8 | 3600121 | Frame |
| 9 | 380240 | Nut |
| 10 | 3600200 | Guard |
| 11 | 2060200 | Screw |
| 12 | 2100300 | Screw |
| 13 | 3600320 | Guard |
| 14 | 2500330 | Detergent hose |
| 15 | 2360340 | Stud bolt |
| 16 | 3082130 | Water coupling kit |
| 17 | 50019 | Knob |
| 18 | 50037 | Screw |
| 19 | 1060120 | Nut |
| 20 | 2021780 | Screw |
| 21 | 3600030 | Guard |
| 22 | 3600290 | Casing |
| 23 | 850250 | Screw |
| 24 | 3600410 | Detergent hose |
| 25 | 42113 | Plug assembly |
| 26 | 3600250 | Tank |
| 27 | 2000230 | Filter |
| 28 | 3600070 | Accessories carrier |
| 29 | 2360360 | Screw |
| 30 | 2060200 | Screw |
| 31 | 3600060 | Accessories carrier |
| 32 | 2100300 | Screw |
| 33 | 3580090 | Knob |
| 34 | 3600130 | Frame |
| 35 | 3580180 | Knob |
| 36 | 3600050 | Accessories carrier |
| HPC Pressure Cleaner Michelin MPX 170 HDC 24363 | ||
| Pump Pag.2 | ||
| 1 | 3200110 | Plug |
| 2 | 1200690 | O-ring |
| 3 | 2769050 | Complete valve |
| 4 | 800410 | Screw |
| 5 | 1381550 | Washer |
| 6 | 3200020 | Head |
| 7 | 180101 | O-ring |
| 8 | 820361 | Plug |
| 9 | 51219 | Pressure switch |
| 10 | 3160510 | Fitting |
| 11 | 1780140 | Ring |
| 12 | 1780720 | Water seal |
| 13 | 3200130 | Piston guide |
| 14 | 3200142 | Gasket |
| 15 | 3200260 | Ring |
| 16 | 770590 | O-ring |
| 17 | 3200120 | Piston guide |
| 18 | 3200010 | Pump body |
| 19 | 1780490 | Bearing |
| 20 | 1260790 | Ring |
| 21 | 1780550 | Ring |
| 22 | 395081 | O-ring |
| 23 | 3200090 | Plate |
| 24 | 3200080 | Level gauge |
| 25 | 3200070 | Support |
| 26 | 1200430 | Screw |
| 27 | 880130 | Plug |
| 28 | 1260110 | Nut |
| 29 | 1260100 | Washer |
| 30 | 1260210 | Piston |
| 31 | 1260091 | Plate |
| 32 | 1260460 | Oil seal |
| 33 | 480480 | O-ring |
| 34 | 3200060 | Piston |
| 35 | 3200040 | Connecting-rod |
| 36 | 1780050 | Pin |
| 37 | 2760280 | O-ring |
| 38 | 3200030 | Cover |
| 39 | 820510 | O-ring |
| 40 | 880581 | Plug |
| 41 | 3200220 | Screw |
| 42 | 3200270 | Shaft |
| 43 | 3200230 | Key |
| 44 | 1321190 | Bearing |
| 45 | 1260750 | Ring |
| 46 | 3209200 | Head assembly |
| 47 | 23081 | Pump assembly |
| 48 | 3200430 | Plug |
| 49 | 40741 | Pressure gauge |
| 50 | 123960 | Fitting |
| A | 2186 | Valve kit |
| B | 42467 | Piston kit |
| C | 42468 | Oil seal kit |
| E | 42469 | Water seal kit |
| F | 42470 | Gasket kit |
| G | 2745 | Support ring kit |
| HPC Pressure Cleaner Michelin MPX 170 HDC 24363 | ||
| Valve Pag.3 | ||
| 1 | 1560580 | Plug |
| 2 | 540290 | Screw |
| 3 | 1660210 | Nut |
| 4 | 1560400 | Knob |
| 5 | 1560420 | Screw |
| 6 | 1080070 | Pin |
| 7 | 2260330 | Guide |
| 8 | 2260140 | Wobble plate |
| 9 | 1560350 | Spring |
| 10 | 2260340 | Wobble plate |
| 11 | 2260060 | Piston |
| 12 | 2260100 | O-ring |
| 13 | 2260040 | Piston guide |
| 14 | 740290 | O-ring |
| 15 | 394280 | O-ring |
| 16 | 2260450 | Shutter |
| 17 | 2260190 | O-ring |
| 18 | 2260080 | Seat |
| 19 | 1260740 | O-ring |
| 20 | 390080 | O-ring |
| 21 | 1540272 | Screw |
| 22 | 1560150 | O-ring |
| 23 | 1560100 | Shutter |
| 24 | 1560140 | Spring |
| 25 | 180101 | O-ring |
| 26 | 24246 | Valve |
| 27 | 2260170 | Valve body |
| 28 | 390080 | O-ring |
| 29 | 1540471 | Suction fitting |
| 30 | 880270 | O-ring |
| 31 | 2260420 | Screw |
| 32 | 480440 | O-ring |
| 33 | 1560900 | Fitting |
| 34 | 1540630 | O-ring |
| 35 | 1560510 | Nut |
| 36 | 1560500 | Fitting |
| 37 | 1560520 | Spring |
| 38 | 1250280 | Ball |
| 39 | 480480 | O-ring |
| 40 | 1560490 | Hose tail |
| F | 42598 | Gasket kit |
| HPC Pressure Cleaner Michelin MPX 170 HDC 24363 | ||
| Motor Pag.4 | ||
| 1 | 1381980 | Guard |
| 2 | 1682270 | Switch |
| 3 | 1261570 | Screw |
| 4 | 1261560 | Screw |
| 5 | 1080190 | O-ring |
| 6 | 1760640 | Cable |
| 7 | 1382380 | Cable gland |
| 8 | 1701070 | Box |
| 9 | 1700590 | Nut |
| 10 | 880270 | O-ring |
| 11 | 2021480 | Gland |
| 12 | 1269100 | Clamp |
| 13 | 1940410 | O-ring |
| 14 | 1470130 | Screw |
| 15 | 1700080 | Plate |
| 16 | 50068 | Gasket |
| 17 | 44511 | Motor |
| 18 | 2360950 | Mini-contactor |
| 19 | 1381940 | Frame |
| 20 | 1261551 | Screw |
| HPC Pressure Cleaner Michelin MPX 170 HDC 24363 | ||
| Standard Accessories Pag.5 | ||
| 1 | 41046 | Gun |
| 2 | 3600650 | Lance |
| 3 | 3600480 | Nozzle (0°) |
| 4 | 3600490 | Nozzle (15°) |
| 5 | 3600500 | Nozzle (25°) |
| 6 | 3600510 | Nozzle (40°) |
| 7 | 3600400 | Nozzle (low pressure) |
| 8 | 1271960 | High pressure hose |
| 9 | 2000770 | O-ring |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi&Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi&Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Michelin MPX 170 HDC - 24363
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
