. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Air Compressor MCX 20.
In the following table, look for the type of the Air Compressor and the respective parts of the code.
| Air Compressor MCX 20 | ||
| 1 | 7152070000 | Motor Hull GRAY 7062-20LT.Vertical |
| 2 | 7152080000 | Hull Closing GREY 7062-20LT.Vertical |
| 3 | 7152100000 | SHIELD Blue Top Michelin-20LT.Vertical |
| 4 | 7152090000 | BLUE SHIELD LOWER MICHELIN-20LT.Vertical |
| 5 | 7151780000 | Hull Inner Plastic RAL9005 |
| 6 | 5153850008 | Tank 20lt |
| 7 | 7300310000 | Switch |
| 8 | 7110240000 | Manometer Ø40-1 / 8 " |
| 9 | 7100760000 | Pressure Reducer |
| 10 | 7084240000 | The Connection M1 / 4 "- Ø6 |
| 11 | 7088110000 | Fitting 1/4 MF |
| 12 | 7130570000 | Universal Tap M1 / 4 " |
| 13 | 7360420000 | Foot Rubber 20lt.Verticale |
| 14 | 7364550000 | Antivibration |
| 15 | 7083120000 | The Fitting 1/4-Pipe Ø8 |
| 16 | 7190290000 | Check Valve MM 1/4 " |
| 17 | 7083160000 | Fitting 1 / 4FXD.8 |
| 18 | 7422250000 | Group Umc V.230 / 50-60hz |
| 19 | 7422250010 | Kit Valve Plate |
| 20 | 7422250030 | Belt |
| 21 | 7422250040 | Kit Connecting Rod / Piston |
| 22 | 7422250020 | Cylinder |
| 23 | 7239610000 | Prol.Spia Oil Pipe Silent 400-500 |
| 24 | 7230030000 | Rilsan Tube Ø10X8 |
| 25 | 7018770000 | 20lt.Vertic.D.15 Axle X 330 |
| 26 | 7260290000 | Wheel Ø175 F.15 |
| 27 | 7042010000 | Seeger TYPE ZA 15 |
| 28 | 7261130000 | Wheel Cover |
| 29 | 7090030000 | Cap 1/2 |
| 30 | 7085200000 | Fitting 1 / 2-1 / 4 MM |
| 31 | 7130090000 | Bleeding Tap M1 / 4 " |
| 32 | 7230010000 | Rilsan Tube Ø6X4 |
| 33 | 7084220000 | Fitting DIR.M1 / 4 "-6 QUICK |
| 34 | 7192020000 | Safety Valve M1 / 4-8,5Bar |
| 35 | 7082050000 | Fitting "T" 1/4 FFM |
| 36 | 7090070000 | Cap M1 / 4 " |
| 37 | 7250740000 | Pressure Switch |
| 38 | 7012890000 | Screw Ø4,2X25 |
| 39 | 7327160000 | Power Cable |
| 40 | 7326860000 | Electrical Cable |
| 41 | 7310710000 | Condenser MF.0,22 + CABLES 20LT.VERTIC |
| 42 | 7012570000 | Screw 5,5X25 UNI-6956 |
| 43 | 7012490000 | Screw M6x40 UNI-7686 |
| 44 | 7012170000 | Screw M5X8 UNI-8112 |
| 45 | 7327140000 | Electrical Cable |
| 46 | 7500660000 | Rubber Cable F = 12 X-Mcx20 Cp.20 |
| 018A | 7422270000 | Group Umc V.120 / 50-60hz Csa |
| 018B | 7422280000 | Group Umc V.100 / 50-60hz |
| 039A | 7327130000 | Power Cable |
| 039B | 7327120000 | Power Cable |
| 039C | 7327080000 | Power Cable |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
