Metabo Spare Parts for Jig Saw STE 65 SP
METABO Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Jig Saw STE 65 SP - 00362000.
In the following table, look for the model of the Jig Saw and the respective parts of the code.
| Jig Saw STE 65 SP/00362000 | ||
| # | Part Num. | Description |
| 1 | 34220057 | Protective strap |
| 2 | 14111602 | Self-tap fill h screw |
| 3 | 31603045 | Housing cpl. |
| 4 | 33804764 | Rating plate |
| 5 | 34337501 | Dummy plug |
| 6 | 34340831 | Electronic switch |
| 7 | 34151386 | Cylindrical pin |
| 8 | 31602988 | Supporting lever |
| 9 | 33912050 | Sliding sheet |
| 10 | 34407004 | Felt |
| 11 | 34202168 | Pressure spring |
| 12 | 33912932 | Guide plate |
| 13 | 34100261 | Needle bearing |
| 14 | 33912549 | Washer |
| 15 | 31603008 | Spur gear cpl. |
| 16 | 14311143 | Needle sleeve |
| 17 | 33912929 | Balancing plate |
| 18 | 33912936 | Pressure spring |
| 19 | 31603009 | Bearing support cpl. |
| 20 | 34409758 | Rubber plug |
| 21 | 34338006 | Cover brush |
| 22 | 14311340 | Ball bearing, 8x22x7 |
| 23 | 31000791 | Armature cpl. 230 V |
| 24 | 14311566 | Ball bearing, 6x19x6 |
| 25 | 34409255 | Rubber stopper |
| 26 | 31100994 | Field coil 230V / 120 V |
| 27 | 31604052 | Brush holder module |
| 28 | 31603396 | Carbon brush cpl. |
| 29 | 31603256 | Oscillating guide |
| 30 | 34107031 | Cover plate |
| 31 | 14319470 | O-ring |
| 32 | 33901052 | Sealing washer |
| 33 | 33912945 | Connecting link |
| 34 | 14112055 | Countersunk screw |
| 35 | 34105613 | Ram |
| 36 | 14116364 | Cylindrical pin |
| 37 | 14116077 | Spiral tightening pin |
| 38 | 34220052 | Drift key |
| 39 | 14116081 | Tightening pin |
| 40 | 34107026 | Clamping piece |
| 41 | 34107028 | Clamping lever |
| 42 | 34202154 | Tension spring |
| 43 | 31603257 | Ram with guide |
| 44 | 14118181 | Circlip |
| 45 | 34339548 | Anti-splintering insert |
| 46 | 31602962 | Base plate cpl. |
| 47 | 33912931 | position plate |
| 48 | 14113137 | Square nut |
| 49 | 34409142 | Rubber plug |
| 50 | 34410114 | Cable sleeve |
| 51 | 34448588 | Cable with plug |
| 52 | 34416153 | Hexagonal key |
| 53 | 14112230 | Cap screw |
| 54 | 33900562 | Champing claw |
| 55 | 34105586 | Shift axle |
| 56 | 31603014 | Shift lever |
| 57 | 33812216 | M-Label,08 52x22 |
| 58 | 34325378 | Interference suppr. cond. |
| 880 | 34413093 | Grease 50Gr 1,8oz |
