Metabo Spare Parts for Reciprocating Saw PSE 1200
€1.84
Tax included
Metabo Spare Parts for Reciprocating Saw PSE 1200
Fix Your Reciprocating Saw PSE 1200 - 01301000. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Reciprocating Saw PSE 1200
Fix Your Reciprocating Saw PSE 1200 - 01301000. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Reciprocating Saw and the respective parts of the code.
| Reciprocating Saw PSE 1200/01301000 | ||
| # | Part Num. | Description |
| 1 | 31603779 | Saw guide |
| 2 | 33913225 | Circlip |
| 3 | 34409699 | Insulation cover |
| 4 | 34101328 | Excentric setting ring |
| 5 | 34202241 | Torsion spring |
| 6 | 34170377 | Tap tite screw TORX 20 x 10 |
| 7 | 33913221 | Retraining sheet |
| 8 | 34170376 | Tight fit srew Torx 20 x 58 |
| 9 | 34409701 | Rubber packing |
| 10 | 34170372 | Screw |
| 11 | 31510437 | Gear Cover |
| 12 | 34407082 | Felt ring |
| 13 | 32005053 | Ball bearing, 15x32x9 |
| 14 | 33913223 | Retaining ring |
| 15 | 34105751 | Spacer |
| 16 | 33913224 | Retaining ring |
| 17 | 34109003 | Wobble assy |
| 18 | 34105749 | Suppor+D15097t sleeve |
| 19 | 34100619 | Ball w. recess |
| 20 | 34121084 | Ram |
| 21 | 32005052 | Ball bearing, 8x22x7 |
| 22 | 34105752 | Drive shaft |
| 23 | 34001245 | Spur gear |
| 24 | 34339385 | Handle with cover |
| 25 | 34170373 | Screw TORX 20 x 18 |
| 26 | 34340763 | Conversion kit + switch 230 V |
| 29 | 31603781 | Guide lever |
| 30 | 34152009 | Tigthening pin |
| 31 | 34407081 | Felt ring |
| 32 | 33900682 | Washer |
| 33 | 33913222 | Guide locking plate |
| 34 | 34170355 | Allen head screw |
| 35 | 34170371 | Screw w. Bearing pin |
| 36 | 34325427 | Condenser |
| 38 | 33811862 | Metabo plate |
| 39 | 34305023 | Terminal |
| 40 | 31603784 | Brush set cpl. 120/230 V |
| 41 | 34170374 | Plastite screw TORX 20 X 18 |
| 42 | 34407083 | Felt ring |
| 43 | 34170378 | Tap tite screw TORX 20 x 9 |
| 44 | 33000166 | Fan |
| 45 | 31000869 | Armature cpl. 230 V |
| 46 | 34409704 | Rubber bushing |
| 47 | 34205079 | Spring |
| 48 | 31520225 | Intermediate flange |
| 49 | 32005054 | Ball bearing, 10x26x8 |
| 50 | 34407084 | Felt ring |
| 51 | 31603780 | Oscillating switch |
| 53 | 34170368 | Srew 5,3x50 TX 20 |
| 54 | 31101033 | Field coil assembly w.field coil,230V |
| 55 | 33804555 | NAME PLATE |
| 56 | 34339059 | Motor housing |
| 57 | 33901147 | Holder insulation |
| 58 | 34339069 | FET holder |
| 59 | 34114775 | Plastic strip |
| 60 | 34305018 | nut |
| 63 | 34448835 | Cable with plug |
| 64 | 34409703 | Cable sleeve |
| 69 | 34300089 | Brush holder |
| 75 | 14118009 | snap ring |
| 880 | 34413111 | Grease 100Gr |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
