Metabo original replacement parts for to replace broken parts for to fix Mitre Saw KS 254 Plus - 0102540100 10.
In the following table, look for the model of the Mitre Saw and the respective parts of the code.![]()
| Mitre Saw KS 254 Plus/0102540100 10 | ||
| # | Part Num. | Description |
| 1 | 1010737598 | Moving guard compl. KS 254 |
| 2 | 1010737610 | Linkage compl. KS 254 |
| 3 | 1010737997 | Torsion Spring compl. KS 254 |
| 4 | 1385738036 | Bevel cam shaft KS 254/305 |
| 5 | 1381700786 | PLASTIC WASHER RD22/16X1,2 |
| 6 | 6202002305 | HEXAGON NUT, PREV. TORQUE TYPE |
| 7 | 14115134 | Washer |
| 8 | 7006738049 | Clamping lever compl. KS 254/305 |
| 10 | 6121102640 | HEXAGON SOCKET HEAD CAP SCREW |
| 11 | 1010738063 | Return spring compl. KS 254/305 |
| 12 | 1010737687 | Extraction channel compl. KS 254 |
| 13 | 1381691566 | DUST EXTRACTION PORT 44/35-44/32 |
| 14 | 1388737529 | Dust bag KS 254/305 |
| 15 | 14111647 | Grub screw |
| 16 | 6205084779 | HEXAGON THIN NUT |
| 17 | 6202128341 | HEXAGON NUT, PREV. TORQUE TYPE |
| 18 | 1010738055 | Front back block compl. KS 254/305 |
| 19 | 6121023081 | Cap screw |
| 20 | 1010737865 | Transportation lock compl. KS 254/305 |
| 21 | 1010738020 | Pivot compl. KS 254/305 Plus |
| 23 | 1010738012 | Sliding sheet compl. KS 254/305 |
| 30 | 1010737369 | Motor compl. KS 254 |
| 31 | 6172015687 | CROSS REC'D PAN HEAD TAP.SCREW |
| 32 | 6120015468 | SLOTTED CHEESE HEAD SCREW M 6X40 VERZ. |
| 33 | 1010737385 | Carbon brush 230V compl. KS 254/305 |
| 34 | 1010737342 | Amature 230V compl. KS 254/305 |
| 35 | 14115097 | Washer ZN5BK |
| 36 | 14115042 | Serrated lock washer |
| 37 | 6122151520 | HEXAGON SOCKET HEAD CAP SCREW M 6X16 VER |
| 38 | 7100067433 | DEEP GROOVE BALL BEARING 15X35X11 6202-2 |
| 39 | 7100695361 | Rillenkugellager 608-2Z C3 (8x22x7) |
| 40 | 1010737784 | Pointer compl. KS 254/305 |
| 41 | 1010737733 | Table insert compl. KS 254/305 |
| 42 | 1010737776 | Bevel detent knob compl KS 254/305 |
| 44 | 1010737725 | Turntable compl. KS 254/305 |
| 45 | 6103001178 | Hex head screw |
| 46 | 1010737768 | Saw blade cover KS 254/305 |
| 47 | 1381737752 | GLIDE SEGMENT KS 254/305 |
| 48 | 1010737741 | Mitre detent compl. KS 254/305 |
| 50 | 1010736427 | Rip Fence compl. |
| 51 | 6131009460 | CROSS RECESSED FLAT HEAD SCREW |
| 52 | 1010737440 | Work clamb assy compl. KS Plus |
| 54 | 9102689833 | ALLEN HEXAGON KEY |
| 55 | 1010737210 | Auxiliary guide compl. |
| 56 | 1010737482 | Extension left compl. KS 254 |
| 57 | 1010737539 | Base compl. KS 254/305 |
| 58 | 1010737547 | Rubber foot KS 254/305 |
| 59 | 1010737555 | Extension detent compl. KS 254/305 |
| 60 | 1010737490 | Extension right compl. KS 254 |
| 80 | 1010737660 | Wheel guard compl. KS 254 |
| 81 | 1010737822 | Saw blade shaft compl. KS 254 |
| 82 | 1010737962 | Locking Safety guard compl. KS 254 |
| 83 | 1010737954 | Cover sheet compl. KS 254/305 |
| 84 | 1010737938 | spring guide KS 254/305 |
| 85 | 1010737946 | Stop Safety guard compl. KS 254/305 |
| 86 | 1010740238 | Handle compl. |
| 87 | 1010737580 | Cable box assy KS 254/305 |
| 88 | 1010737989 | Turning lever bracket compl. KS 254/305 |
| 89 | 1010737873 | Belt pulley compl. KS 254 |
| 90 | 1010737903 | Belt protection tube compl. KS 254/305 |
| 91 | 1010737814 | Laser compl. KS 254/305 |
| 92 | 1010738519 | Power supply pack compl. |
| 93 | 1010737911 | Motor bracket compl. KS 254 |
| 94 | 1010737890 | Saw blade arrest compl. KS 254/305 |
| 95 | 7233736362 | V-belt pulley 220J KS 254 Plus |
| 96 | 1010737296 | Belt Guard compl.KS 254 |
| 97 | 6163121261 | Grub screw |
| 98 | 1010737636 | Flange compl. KS 254 |
| 99 | 8111737712 | On-off switch KS 254/305 |
| 100 | 8402740249 | Cable with plug CEE-Stecker |
| 101 | 1010737849 | Housing saw blade shaft KS 254 |
| 102 | 7100198490 | DEEP GROOVE BALL BEARING 17X35X10 6003-2 |
| 103 | 6143088225 | HEX. HEAD THREAD ROLLING SCREW M 4X8 (GE |
| 104 | 14115043 | Serrated lock washer |
| 105 | 14115041 | Serrated lock washer |
